Advances in Nanoparticle-Based Drug Delivery Systems: A Comprehensive Review of Pharmaceutical Formulations

Abstract

A principal drawback of conventional drug delivery approaches lies in their limited capacity to achieve selective targeting, often resulting in diminished therapeutic efficacy and increased systemic toxicity. Nanoparticle-mediated drug delivery systems (DDS) have emerged as a robust alternative, enabling accurate, site-specific transport of pharmacologically active agents while improving their physicochemical stability and bioavailability. This review provides an in-depth examination of the foundational concepts of nanoparticles, their classifications, and their incorporation into various pharmaceutical dosage forms. It encompasses a broad spectrum of nanoparticulate formulations, including tablets, injectables, suspensions, gels, creams, dry powder inhalers, and capsules. Each dosage form leverages distinct classes of nanoparticles—such as polymeric, lipidic, and inorganic carriers—engineered to address specific therapeutic challenges. The convergence of nanotechnology with drug delivery innovations has substantially enhanced drug solubilization, modulated release kinetics, and improved patient adherence. This review emphasizes the expanding utility of nanocarrier systems in pharmaceutical technology and their transformative potential in the advancement of personalized and targeted therapeutic interventions.

Keywords

Nanoparticles, Drug delivery systems, Targeted drug delivery, Nanotechnology, Nanoparticle-based formulations, Controlled release, Bioavailability enhancement, Pharmaceutical nanocarriers

Introduction

One of the major challenges in treating various diseases is ensuring that therapeutic agents reach their intended target site. Traditional drug administration often suffers from limited efficacy, uneven distribution throughout the body, and poor selectivity¹. These issues can be addressed through the use of controlled drug delivery systems (DDS), which direct the drug specifically to the site of action. This targeted approach helps minimize unwanted side effects and reduces the impact on healthy tissues. Moreover, DDS can protect the drug from premature breakdown or elimination, increasing its concentration at the desired location and allowing for the use of smaller doses. Such advanced therapeutic strategies are especially valuable when there is a mismatch between the administered dose and the desired therapeutic or adverse effects². Nanotechnology, a comparatively recent scientific discipline, has attracted significant interest over the past two decades and is swiftly transitioning from academic research to industrial applications³. Nanotechnology involves the deliberate design and manipulation of matter at the nanoscale, specifically between 1 and 100 nanometers, enabling the creation or reconfiguration of nano systems with enhanced functionalities. Nanoparticles represent the culmination of advanced physicochemical manipulation of matter at the molecular level, typically exhibiting dimensions only marginally larger than individual atoms. Arising from precise molecular engineering, these nanostructures demonstrate superior physicochemical properties, including intrinsic thermodynamic stability and self-assembling capabilities^4,5 Their high degree of tunability allows for functionalization to impart targeted characteristics, such as an increased surface-area-to-volume ratio, surpassing that of conventional bulk materials⁶. Nanoparticles possess the capability to significantly enhance the therapeutic effectiveness of drugs by ensuring greater stability and enabling precise delivery to targeted sites of action. A wide range of nanoparticle types— including polymer-based, inorganic, and lipid-based systems—have shown considerable promise in drug delivery applications⁷. The formulation of nanoparticles represents a critical initial step; however, a more significant challenge involves their integration into suitable pharmaceutical dosage forms, followed by the physicochemical and biological characterization of the final nanoparticulate formulation. This review primarily focuses on providing comprehensive information on nanoparticle-based formulations.

The Basic Necessity and Types of Nanoparticles.

Owing to their unique physicochemical properties, nanoparticles have emerged as effective carriers for delivering a wide range of therapeutic molecules to specific targets within the body. These site-specific nanomedicines can enhance the therapeutic index of drugs by improving their effectiveness and/or increasing their biocompatibility. Furthermore, nanotechnology offers advantages such as enhancing the solubility and bioavailability of poorly water-soluble drugs, protecting active agents from physiological barriers, facilitating the development of novel bioactive macromolecular therapeutics, and enabling the delivery of large drug payloads⁸. Nanotechnology is primarily divided into two categories: nanodevices and nanomaterials. Nanodevices include advanced components such as respirocytes and NEMS/MEMS (Nanoelectromechanical Systems/Microelectromechanical Systems), which are designed for specific biomedical applications. On the other hand, nanomaterials are further classified into nanostructured and nanocrystalline forms. Nanostructured materials are subdivided into polymeric and non-polymeric systems. Polymeric nano systems consist of nanoparticles, dendrimers, micelles, and drug conjugates, all of which are widely utilized for drug delivery and therapeutic purposes. Non-polymeric nano systems include carbon nanotubes, metallic nanoparticles, silica nanoparticles, and quantum dots, which offer unique physicochemical properties for diagnostic and therapeutic use⁹. Nanocrystalline materials represent another form of nanomaterials characterized by their crystalline structure at the nanoscale. Collectively, these nano systems play a crucial role in advancing pharmaceutical research and improving drug delivery efficiency. The initial generation of clinically approved nanotechnology-based products primarily consists of liposomal formulations and polymer–drug conjugates. These systems are structurally simple and generally do not possess advanced functionalities such as active targeting capabilities or mechanisms for controlled drug release. In recent years, several innovative and advanced nanoparticle-based techniques for cancer detection have been developed. These engineered nanostructures serve multiple roles, including functioning as fluorescent markers, contrast agents, targeted drug carriers linked with antibodies, and tools for molecular research. Modern advancements in nanoparticulate systems such as quantum dots, paramagnetic nanoparticles, nanosomes and nanoshells are increasingly being utilized in various diagnostic applications¹⁰.

Nanoparticle Based Formulations

Nanoparticle Based Tablet

Porous carriers offer a promising way to stabilize amorphous drugs and improve dissolution of poorly soluble compounds. The study aimed to enhance the solubility, dissolution rate, and loading of silymarin by incorporating it into mesoporous silica nanospheres in a lyophilized tablet. Mesoporous silica nanospheres (MSNs) with a 3D-dendritic pore structure were synthesized using a modified one-pot biphase stratification method involving controlled hydrolysis and condensation of a silica precursor. The resulting MSNs were purified, dried, and stored for further physicochemical characterization, including particle size, zeta potential, pore structure, and morphology. The SLM was incorporated into the MSNs through the solvent evaporation technique. A polymeric solution of PVA, sucrose, and PEG was prepared in water, into which the drug-loaded MSNs were added and sonicated until homogeneous. The mixture was poured into blister packs, frozen, lyophilized, and the resulting MSN-based tablets were stored in sealed containers at room temperature¹¹. Similarly, a study aimed to develop oral dispersible tablets containing prednisolone-loaded chitosan nanoparticles using Microcrystalline cellulose 101, lactose, and croscarmellose sodium. The nanoparticles were prepared by ionotropic external gelation to improve prednisolone solubility at salivary pH¹². Chitosan was dissolved in acetic acid and combined with a surfactant and prednisolone in an organic solvent. The organic phase was added dropwise to the chitosan solution, followed by cross-linking with Tripolyphosphate to form nanoparticles through electrostatic interaction. The nanoparticles were then isolated by centrifugation, characterized, and the optimized formulation was used to develop oral dispersible tablets. The formulated nanoparticles were utilized to develop oral fast-disintegrating tablets using the direct compression technique¹³. In a same way, a study focused on developing a colon-targeted oxaliplatin (OP) tablet by combining nanotechnology with fused deposition modeling (FDM) 3D printing to enhance its antitumor efficacy, targeting ability, and safety. OP-loaded alginate nanoparticles were incorporated into Eudragit L100-55 filaments via hot-melt extrusion and 3D printed into tablets, ensuring uniform drug content and targeted release in the colon ¹⁴.

Nanoparticle Based Injectables

The systemic delivery of bisphosphonates, such as sodium alendronate, typically suffers from poor bioavailability and notable toxicity. To address these issues, a novel injectable formulation was developed for direct intra-bone administration of alendronate. This delivery system comprises alendronate-encapsulated nanoparticles incorporated into a gellan gum-based hydrogel matrix. PLGA nanoparticles were prepared using a double emulsion and solvent evaporation method. Alendronate powder was first emulsified in a PLGA solution to form a primary emulsion, which was then added to an aqueous PVA solution under ultrasonication to create a secondary emulsion. After solvent evaporation, the nanoparticles were collected by centrifugation, washed, freeze-dried, and stored, then redispersed in water for further analysis. Gellan gum  was dissolved in ultra-high-quality water at elevated temperature and then cooled before incorporating the nanoparticles- alendronate suspension. To improve injectability, the hydrogel matrix was cross-linked using a calcium chloride solution¹⁵.

Nanoparticle Based Suspension

The study aims to develop Omeprazole-loaded nanoparticles for use in a liquid pharmaceutical dosage form. Omeprazole is commonly used to treat gastric hypersecretion disorders in children; however, a liquid formulation suitable for pediatric use is unavailable. Omeprazole-loaded nanoparticles were prepared using the interfacial deposition of preformed polymers method with Eudragit RS100. The organic phase was combined with an aqueous phase containing stabilizers, followed by solvent removal to concentrate the formulation. Enteric coating was applied using Eudragit L100-55 solutions^16,17.

Nanoparticle Based Gels

A thermosensitive chitosan-gelatin hydrogel containing 5-fluorouracil -alginate nanoparticles was developed for effective and sustained transdermal delivery of 5-fluorouracil , a commonly used anticancer drug. Due to its short biological half-life (5–10 minutes), 5-fluorouracil clinical application is limited¹⁸. To enhance its therapeutic efficiency, 5-fluorouracil was encapsulated in alginate nanoparticles via interactions with alginate's functional groups and then incorporated into the hydrogel using a spray drying method^19,20. Vaginal drug delivery offers localized, long-term release while minimizing systemic side effects. Nanoparticles and nanofibers are promising carriers for this route. This study aimed to develop nanofiber and gel formulations containing benzydamine nanoparticles to ensure prolonged release against vaginal infections. Chitosan nanoparticles were prepared using the ionic gelation method, where benzydamine and ethanol were added to a chitosan solution to enhance drug solubility. Tripolyphosphate (TPP) was added under controlled conditions to form nanoparticles, which were then centrifuged and dispersed in a mannitol solution as a lyoprotectant²¹. The final nanoparticle suspension was freeze-dried to obtain a stable formulation. Then, dispersions containing benzydamine nanoparticles were prepared for nanoparticle-loaded nanofiber formulations. Gel formulations were prepared by dissolving HPMC in water and mixing it with lyophilized nanoparticles using a mechanical stirrer^22,23.

Nanoparticle Based Cream

A study formulated day and night cosmeceutical creams using Elaeis guineensis (palm fruit) extract encapsulated in solid lipid nanoparticles (SLNs). The extract, rich in antioxidants like vitamin E, β-carotene, and palmitic acid, demonstrated strong antioxidant activity. The resulting creams showed good physical properties, stability, and were tested for effectiveness on female volunteers. Solid lipid nanoparticles (SLNs) were prepared using the hot homogenization method by mixing Elaeis guineensis extract with glyceryl monostearate at elevated temperature until clear. A surfactant solution containing Tween® 80 and Span® 80 was then added and homogenized, followed by cooling in an ice bath. The resulting SLNs were stored in airtight containers for further use. Day and night creams were formulated using the hot homogenization method with a high-shear mixer. The oil phase, containing various emollients and waxes, was heated and combined with a water phase that included Elaeis guineensis SLNs, moisturizers, and stabilizers. After mixing and homogenization, tocopherol acetate and grape seed extract were added; the night cream followed a similar process but excluded sun protection agents and a few specific ingredients²⁴.

Nanoparticles Based Dry Powder Inhaler Formulation

Prothionamide (PTH), a second-line drug for tuberculosis, faces challenges with oral administration due to variable absorption and the need for frequent dosing. To address these issues, pulmonary delivery using nanoparticles was explored to achieve prolonged drug release in the lungs. Chitosan/TPP nanoparticles were formulated using a modified ionic gelation method^25,26. Prothionamide was incorporated into a chitosan solution, followed by the gradual addition of TPP under continuous stirring. The resulting nanosuspension was centrifuged under controlled temperature to prevent heat-induced instability, washed, and freeze-dried using a cryoprotectant. The flow properties of PTH nanoparticles were first evaluated²⁷. To enhance flow, they were manually blended with inhalable-grade anhydrous lactose in varying ratios using the geometrical dilution method²⁸.

Nanoparticle Based Capsule

Cantigi extract possesses several beneficial properties, including antioxidant activity. Although various dosage forms have been developed, a capsule formulation has not yet been explored. Nanoparticles were synthesized through the nanoprecipitation method using gelatin as the polymer and glutaraldehyde as the cross-linker. They were subsequently analyzed for their particle size, polydispersity index, functional groups, surface charge, morphology, and drug entrapment efficiency^29,30. The capsule formulation was formulated by manually blending the active compounds with suitable fillers and a glidant, followed by filling into hard gelatin capsules. Before encapsulation, the mixture was assessed for parameters such as moisture content, particle size distribution, bulk and tapped density, and flow characteristics. Post-filling, the capsules underwent evaluation for mass uniformity, disintegration time, and dissolution performance³¹.

Regulatory Considerations

Nanoparticle-based medicines are complex, multi-component systems, making their regulation far more challenging than conventional drugs. Unlike standard formulations with a single active agent and inert excipients, nanomedicines often contain multiple functional components that influence pharmacological behavior.

Currently, agencies like the FDA and EMA assess nanomedicines case by case, as there are no universal standards. Key regulatory concerns include:

1. Physicochemical characterization – Ensuring critical product attributes are consistently reproduced during manufacturing.
2. Biodistribution – Evaluating unusual tissue accumulation or prolonged persistence of nanoparticles.
3. Clinical safety – Assessing immune responses and long-term toxicity.
4. Definition – Establishing clear criteria for what qualifies as a nanomedicine.

The emergence of generic nanomedicines adds further complexity. Unlike small-molecule generics, demonstrating equivalence in nanomedicines requires more than standard bioequivalence testing. Failed attempts to replicate formulations such as nab-paclitaxel highlight risks of instability, poor reproducibility, and unsafe impurity levels when critical physicochemical parameters are not matched. Regulators have begun developing product-specific guidance, for example with liposomal doxorubicin, but broader frameworks are still needed. Standard PK and toxicity studies may not adequately predict nanoparticle behavior at target sites, and conventional animal models may fall short in mimicking human responses. To ensure safety and efficacy, regulatory approval must rely on comprehensive characterization, advanced disease models, and long-term monitoring. Personalized approaches, where nanomedicines are directed toward specific biomarkers (e.g., tumor receptors), may reduce trial size and cost while improving patient outcomes—an approach regulators are increasingly supportive of.³²

CONCLUSION

Nanoparticle-based drug delivery systems (DDS) represent a significant advancement in pharmaceutical technology, offering enhanced therapeutic outcomes through targeted, controlled, and efficient delivery of drugs. These systems address key limitations of conventional dosage forms, such as poor bioavailability, rapid degradation, and systemic side effects. By leveraging the unique physicochemical properties of nanoparticles—such as high surface-area-to-volume ratio, tunability, and biocompatibility—researchers have developed a wide variety of innovative formulations, including tablets, injectables, suspensions, gels, creams, dry powder inhalers, and capsules. Each dosage form serves distinct therapeutic needs and routes of administration, from oral fast-dissolving tablets to colon-targeted 3D-printed formulations and thermosensitive gels for sustained transdermal or vaginal drug delivery. Incorporating nanoparticles into these forms not only improves drug solubility and stability but also ensures precise delivery to the intended site of action. The progress outlined in various studies highlights the transformative potential of nanotechnology in drug delivery, especially for poorly soluble drugs and complex therapeutic agents. With continued research and technological refinement, nanoparticle-based pharmaceutical formulations are poised to redefine treatment paradigms across multiple therapeutic areas, contributing to more effective, safer, and patient-friendly healthcare solutions.

REFERENCES

1. Nevozhay D, Ka?ska U, Budzy?ska R, Boraty?ski J. [Current status of research on conjugates and related drug delivery systems in the treatment of cancer and other diseases]. Postepy Hig Med Doswiadczalnej Online. 2007;61:350-360.
2. Wilczewska AZ, Niemirowicz K, Markiewicz KH, Car H. Nanoparticles as drug delivery systems. Pharmacol Rep. 2012;64(5):1020-1037. doi:10.1016/S1734-1140(12)70901-5
3. Nasrollahzadeh M, Sajadi SM, Sajjadi M, Issaabadi Z. An Introduction to Nanotechnology. In: Interface Science and Technology. Vol 28. Elsevier; 2019:1-27. doi:10.1016/B978-0-12-813586-0.00001-8
4. Cheng Y, Wolkenhauer M, Bumbu G, Gutmann JS. A Facile Route to Reassemble Titania Nanoparticles Into Ordered Chain?like Networks on Substrate. Macromol Rapid Commun. 2012;33(3):218-224. doi:10.1002/marc.201100638
5. Kango S, Kalia S, Celli A, Njuguna J, Habibi Y, Kumar R. Surface modification of inorganic nanoparticles for development of organic–inorganic nanocomposites—A review. Prog Polym Sci. 2013;38(8):1232-1261. doi:10.1016/j.progpolymsci.2013.02.003
6. Yusuf A, Almotairy ARZ, Henidi H, Alshehri OY, Aldughaim MS. Nanoparticles as Drug Delivery Systems: A Review of the Implication of Nanoparticles’ Physicochemical Properties on Responses in Biological Systems. Polymers. 2023;15(7):1596. doi:10.3390/polym15071596
7. Beach MA, Nayanathara U, Gao Y, et al. Polymeric Nanoparticles for Drug Delivery. Chem Rev. 2024;124(9):5505-5616. doi:10.1021/acs.chemrev.3c00705
8. Cai W, Chen X. Nanoplatforms for Targeted Molecular Imaging in Living Subjects. Small. 2007;3(11):1840-1854. doi:10.1002/smll.200700351
9. Annabelle Hett. Nanotechnology: Small Matter, Many Unknowns.; 2004.
10. Bhatia S. Nanoparticles Types, Classification, Characterization, Fabrication Methods and Drug Delivery Applications. In: Natural Polymer Drug Delivery Systems. Springer International Publishing; 2016:33-93. doi:10.1007/978-3-319-41129-3_2
11. Ibrahim AH, Smått JH, Govardhanam NP, et al. Formulation and optimization of drug-loaded mesoporous silica nanoparticle-based tablets to improve the dissolution rate of the poorly water-soluble drug silymarin. Eur J Pharm Sci. 2020;142:105103. doi:10.1016/j.ejps.2019.105103
12. Antoniou J, Liu F, Majeed H, Qi J, Yokoyama W, Zhong F. Physicochemical and morphological properties of size-controlled chitosan–tripolyphosphate nanoparticles. Colloids Surf Physicochem Eng Asp. 2015;465:137-146. doi:10.1016/j.colsurfa.2014.10.040
13. Zhang H, Han M, Tian Y, et al. Development of oral dispersible tablets containing prednisolone nanoparticles for the management of pediatric asthma. Drug Des Devel Ther. Published online November 2015:5815. doi:10.2147/DDDT.S86075
14. Mirdamadian SZ, Varshosaz J, Minaiyan M, Taheri A. 3D printed tablets containing oxaliplatin loaded alginate nanoparticles for colon cancer targeted delivery. An in vitro/in vivo study. Int J Biol Macromol. 2022;205:90-109. doi:10.1016/j.ijbiomac.2022.02.080
15. Posadowska U, Parizek M, Filova E, et al. Injectable nanoparticle-loaded hydrogel system for local delivery of sodium alendronate. Int J Pharm. 2015;485(1-2):31-40. doi:10.1016/j.ijpharm.2015.03.003
16. Diefenthaeler HS, Bianchin MD, Marques MS, et al. Omeprazole nanoparticles suspension: Development of a stable liquid formulation with a view to pediatric administration. Int J Pharm. 2020;589:119818. doi:10.1016/j.ijpharm.2020.119818
17. Mora-Huertas CE, Fessi H, Elaissari A. Polymer-based nanocapsules for drug delivery. Int J Pharm. 2010;385(1-2):113-142. doi:10.1016/j.ijpharm.2009.10.018
18. Zhang DY, Shen XZ, Wang JY, Dong L, Zheng YL, Wu LL. Preparation of chitosan-polyaspartic acid-5-fluorouracil nanoparticles and its anti-carcinoma effect on tumor growth in nude mice. World J Gastroenterol. 2008;14(22):3554. doi:10.3748/wjg.14.3554
19. Nawaz A, Ullah S, Alnuwaiser MA, et al. Formulation and Evaluation of Chitosan-Gelatin Thermosensitive Hydrogels Containing 5FU-Alginate Nanoparticles for Skin Delivery. Gels. 2022;8(9):537. doi:10.3390/gels8090537
20. Sarfaraj Hussain Md, Azam F, Ahmed Eldarrat H, et al. Structural, functional, molecular, and biological evaluation of novel triterpenoids isolated from Helichrysum stoechas (L.) Moench. Collected from Mediterranean Sea bank: Misurata- Libya. Arab J Chem. 2022;15(6):103818. doi:10.1016/j.arabjc.2022.103818
21. Tsai M, Bai S, Chen R. Cavitation effects versus stretch effects resulted in different size and polydispersity of ionotropic gelation chitosan–sodium tripolyphosphate nanoparticle. Carbohydr Polym. 2008;71(3):448-457. doi:10.1016/j.carbpol.2007.06.015
22. Tu?cu-Demiröz F, Saar S, Kara AA, Y?ld?z A, Tunçel E, Acartürk F. Development and characterization of chitosan nanoparticles loaded nanofiber hybrid system for vaginal controlled release of benzydamine. Eur J Pharm Sci. 2021;161:105801. doi:10.1016/j.ejps.2021.105801
23. Veríssimo MIS, Pais AACC, Gomes MTSR. Following HPMC gelation with a piezoelectric quartz crystal. Carbohydr Polym. 2010;82(2):363-369. doi:10.1016/j.carbpol.2010.04.064
24. Plyduang T, Atipairin A, Sae Yoon A, Sermkaew N, Sakdiset P, Sawatdee S. Formula Development of Red Palm (Elaeis guineensis) Fruit Extract Loaded with Solid Lipid Nanoparticles Containing Creams and Its Anti-Aging Efficacy in Healthy Volunteers. Cosmetics. 2021;9(1):3. doi:10.3390/cosmetics9010003
25. Al-Qadi S, Grenha A, Carrión-Recio D, Seijo B, Remuñán-López C. Microencapsulated chitosan nanoparticles for pulmonary protein delivery: In vivo evaluation of insulin-loaded formulations. J Controlled Release. 2012;157(3):383-390. doi:10.1016/j.jconrel.2011.08.008
26. Saha P, Goyal A, Rath G. Formulation and Evaluation of Chitosan-Based Ampicillin Trihydrate Nanoparticles. Trop J Pharm Res. 2010;9(5). doi:10.4314/tjpr.v9i5.61061
27. Plamen Katsarov BP. Flowability Evaluation of Dry Powder Inhalation Formulations Intended for Nasal Delivery of Betahistine Dihydrochloride. SMU Med J. Published online 2015.
28. Debnath SK, Saisivam S, Debanth M, Omri A. Development and evaluation of Chitosan nanoparticles based dry powder inhalation formulations of Prothionamide. Fraceto L, ed. PLOS ONE. 2018;13(1):e0190976. doi:10.1371/journal.pone.0190976
29. Khan SA. Mini-Review: Opportunities and challenges in the techniques used for preparation of gelatin nanoparticles. Pak J Pharm Sci. 2020;33(1):221-228.
30. Milano F, Masi A, Madaghiele M, Sannino A, Salvatore L, Gallo N. Current Trends in Gelatin-Based Drug Delivery Systems. Pharmaceutics. 2023;15(5):1499. doi:10.3390/pharmaceutics15051499
31. Kosasih K, Deny Susanti, Immanuel Puji Hosanna Asianski, Dede Irving Maryanto. Formulation and Characterization of Antioxidant Capsules Containing Cantigi Extract-loaded Nanoparticles Synthesized Via Nanoprecipitation Method. J Nat Prod Degener Dis. 2024;1(2):80-86. doi:10.58511/jnpdd.v1i2.6352
32. Desai N. Challenges in Development of Nanoparticle-Based Therapeutics. AAPS J. 2012;14(2):282-295. doi:10.1208/s12248-012-9339-4.
