Microspheres As Targeted Drug Delivery Systems: A Review

Abstract

Microspheres have emerged as a versatile and effective platform for targeted drug delivery, offering improved therapeutic efficacy and reduced systemic side effects. Typically ranging from 1 to 1000 ?m in size, microspheres are composed of biodegradable or non-biodegradable polymers that enable controlled and sustained drug release. Their surface can be engineered to achieve site-specific targeting through ligand–receptor interactions, magnetic guidance, or pH- and enzyme-responsive mechanisms. Microsphere-based delivery systems have been extensively investigated for applications in cancer therapy, vaccines, gene delivery, and treatment of chronic diseases. Advantages such as enhanced drug stability, protection of labile drugs, improved bioavailability, and the ability to modulate release kinetics make microspheres superior to conventional dosage forms. Various preparation techniques, including solvent evaporation, spray drying, and emulsion polymerization, influence particle size, encapsulation efficiency, and release behavior. Despite their promising potential, challenges related to large-scale production, reproducibility, and regulatory approval remain. This review highlights the types of microspheres, materials used, drug loading and targeting strategies, therapeutic applications, and current challenges, providing an overview of recent advances and future prospects in microsphere-based targeted drug delivery systems.

Keywords

Introduction





ADVANTAGES OF MICROSPHERES^[6]:

• Microspheres have a consistent and long-lasting therapeutic impact.
• Reduces the frequency of dosing and thereby improves patient compliance.
• Along with their spherical form and smaller size, they may be inserted into the body.
• Improved drug utilization will improve bioavailability while lowering the risk of side effects.
• The morphology of microspheres allows for controlled variability in drug release and degradation.
• Oils and other liquids are converted to solids to make them easier to handle.

DISADVANTAGES OF MICROSPHERES^[7]:

• The modified release from the formulations.
• The release rate of the controlled release dosage form may vary from a variety of factors like food and the rate of transit though gut.
•  Differences in the release rate from one dose to another.
• Controlled release formulations generally contain a higher drug load and thus any loss of integrity of the release characteristics of the dosage form may lead to potential toxicity.
• Dosage forms of this kind should not be crushed or chewed.

CHARACTERISTICS^[8]:

1. Microsphere size may be critical to the proper function of an assay, or it may be secondary to other characteristics. Considering traditional diagnostic methods, the test or assay format commonly dictates particle size, such as the use of very small spheres (~0.1- 0.4μm) to ensure satisfactory wicking in lateral flow tests, or the use of larger, cell-sized spheres (~4-10μm) for bead-based flow cytometric assays.
2.  Common microsphere compositions include polystyrene (PS), poly(methyl methacrylate) (PMMA), and silica. These materials possess different physical and optical properties, which may present advantages or limitations for different applications. Polymer beads are generally hydrophobic, and as such, have high protein binding abilities. However, they often require the use of some surfactant (e.g. 0.01-0.1% Tween® 20 or SDS) in the storage buffer to ensure ease of handling. During synthesis, functional monomers may be co-polymerized with styrene or methyl methacrylate to develop beads with surface reactive groups. Functional groups may be used in covalent binding reactions, and also aid in stabilizing the suspension. Silica microspheres are inherently hydrophilic charged. Consequently, and negatively aqueous silica suspensions rarely require use of surfactants or other stabilizers. Carboxyl- and amine functionalized silica spheres are available for use in common covalent coating protocols, and plain silica microspheres may be modified using a variety of silanes to generate functional groups or alter surface properties.
3. Microspheres may be coated with capture molecules, such as antibodies, oligonucleotides, peptides, etc. for use in diagnostic or separation applications. Microsphere coatings are typically optimized to achieve desired specific activity, while minimizing nonspecific interactions. Consideration should also be given to the required stability, development time frame and budget, and the specific biomolecule to be coated. These factors will aid in determining the most fitting coating strategy for both short- and long-term objectives. Standard microsphere products support three basic coating strategies: adsorption, coupling, and affinity binding.
4. Many applications in the life sciences demand added properties, such as fluorescence or a visible color, or iron oxide inclusions for magnetic separations. Polymer spheres (and polymer based magnetic spheres) are often internally dyed via organic solvent swelling, and many standard products are available. Dye concentrations can be adjusted to produce beads with different intensities to meet special needs, such as QuantumPlex™ for multiplexed flow cytometric assays, or our Dragon Green or Flash Red Intensity Standards, which support imaging applications and associated instrument QC. Many surface- or internally labeled fluorescent beads are also available as specialized flow cytometry standards.

CLASSIFICATION OF POLYMER:

Synthetic polymers:

• Non-biodegradable: Acrolein, Glycidyl methacrylate, Epoxy polymers, etc.^[9]
•  Biodegradable: Polyanhydrides, Polyalkylcyano- acryalates Lactides glycosides, and their copolymers.^[10,11]

 Natural materials: They are obtained from different sources like^[12,13]

• Proteins (albumin, gelatin, collagen)
• Carbohydrate (starch, agarose, carrageenan)
• Chemically modified carbohydrates [poly (acryl dextran), Poly (acryl starch)]

TYPES OF MICROSPHERES:

Bioadhesive microspheres ^[14]:

Adhesion is the process of attaching a drug to a membrane by using the adhesive properties of water-soluble polymers. Bio adhesion is described as the adhesion of a drug delivery system to a mucosal membrane such as the buccal, ocular, rectal, nasal, and other mucosal membranes. These microspheres have a longer residence period at the application site, resulting in close interaction with the absorption site and improved therapeutic action.

Magnetic microspheres ^[15]:

This kind of delivery system is very much important which localizes the drug to the disease site. In this larger amount of freely circulating drug can be replaced by smaller amount of magnetically targeted drug. Magnetic carriers receive magnetic responses to a magnetic field from incorporated materials that are used for magnetic microspheres are chitosan, dextran etc. The different types are therapeutic magnetic microspheres and diagnostic microsphere:

i. Therapeutic Magnetic Microspheres: It is used to deliver chemotherapeutic agent to liver tumor. Drugs like proteins and peptides can also be targeted through this system.

ii. Diagnostic Microspheres: It can be used for imaging liver metastases and also can be used to distinguish bowel loops from other abdominal structures by forming nano size particles supramagnetic iron oxides.

Radioactive microspheres ^[16,17]:

Therapy with Radioembolization Microspheres 10-30 nm in size are larger than capillary microspheres and are tapped in the first capillary bed as they pass through, they are inserted into the arteries that cause a tumor of interest. Thus, under all these cases, radioactive microspheres provide a high dose of radiation to the target areas without affecting normal surrounding tissues. It differs from the drug delivery system, as radioactivity is not released from microspheres but acts from within a radioisotope typical distance and the different kinds of radioactive microspheres are α emitters, β emitters, γ emitters.

Polymeric microspheres:

The different types of polymeric microspheres can be classified as:

Biodegradable polymeric microspheres ^[18]:

Natural polymers like starch are used because they are biodegradable, biocompatible, and bioadhesive. Due to its excellent degree of swelling in an aqueous medium, biodegradable polymer extend the residence time when in contact with mucous membranes, resulting in the formation of gels. The concentration of polymer and the release pattern in a sustained manner regulate the rate and degree of drug release. The main disadvantage is that drug loading performance of biodegradable microspheres in clinical use is complicated, making drug release difficult to manage. However, in microsphere-based therapy, they have a wide variety of applications.

Synthetic polymeric microspheres:

Synthetic polymeric microspheres are widely used in clinical applications, as well as bulking agents, fillers, embolic particles, drug delivery vehicles, and other applications, and have been shown to be safe and biocompatible.^[19] However, the main downside of these microspheres is that they have a tendency to move away from the injection site, posing a risk of embolism and further organ damage.

MECHANISM OF MICROSPHERES ^[20]:

The majority of drug delivery via microparticles prevents the formation of a matrix-like internal solid dispersion morphology structure. The drug may be insoluble in the polymeric matrix, and it is released by erosion. First, water diffuses into the matrix, dissolving the resulting near the device's surface. The resulting osmotic pressure is alleviated by forming a channel to the surface and releasing a predetermined amount of drug in the initial drug burst.

METHOD OF PREPARATION:

Single emulsion technique ^[21]:

This method can be used to prepare a variety of proteins and carbohydrates. The natural polymers are first dissolved in an aqueous medium, then dispersed in an oil phase, which is a non-aqueous medium. That is the initial phase in the process.

Two methods are used to cross-link the next step as:

• Cross-linking by heat :By adding the dispersion into heated oil, but it is unsuitable for the thermolabile drugs.
• Chemical cross-linking agents: By using agents i.e. Formaldehyde, diacid chloride, glutaraldehyde, etc. However, it is detrimental to the undue exposure of active ingredients to chemicals when applied at the time of preparation and then subjected to centrifugation, washing and separation. Chitosan solution (in acetic acid) by applying w/o emulsion to the liquid paraffin containing a surfactant. Microsphere is prepared using a 25 percent solution of glutaraldehyde as a cross-linking agent. ^[22]

Double emulsion technique ^[23,24]:

It is the creation of several emulsions, i.e. W/O/W is prepared by pouring the primary w/o emulsion into an aqueous polyvinyl alcohol solution. This w/o/w emulsion shall be put at constant stirring for 30 min. Slowly add some water to the emulsion for a duration of 30 min. Collection of microcapsules by filtration and dry under vacuum. It is ideally suited for water-soluble medicines, peptides, proteins and vaccines. Natural as well as synthetic polymers can be used for this process. The aqueous protein solution is distributed in a continuous organic lipophilic phase. This protein solution will contain active ingredients. Disperse in oil/organic phase homogenization/vigorous i.e. the formulation of the first emulsion then the addition of the aqueous solution of PVA (Poly Vinyl Alcohol) i.e. the multiple emulsion now produced by the addition of the broad aqueous phase denaturation/hardening after this separation, the washing, drying and collection of the microspheres is prepared using the o/w/o multiple emulsion process.

Phase separation coacervation technique ^[25,26]:

This method is based on the idea of decreasing the solubility of the polymer in the organic phase in order to influence the formation of a polymer-rich phase called coacervates. In this process, the drug particles are dispersed into a polymer solution and an incompatible polymer is added to the device, which separates the first polymer phase and engulfs the drug particles. Adding the non-solvent results to the solidification of the polymer. This process has been used to prepare polylactic acid (PLA) microspheres by using butadiene as an incompatible polymer. Process variables are very significant as the rate of achievement of the coacervates determines the distribution of the polymer film. The size of the particles and the agglomeration of the formed particles. Agglomeration must be avoided by stirring the suspension using an appropriate speed stirrer, because as the process of microsphere forming starts, the formed polymerized globules begin to adhere and form agglomerates. Process variables are therefore important as they govern the kinetics of the formed particles, since there is no given state of equilibrium attainment.

Polymerization techniques ^[26]:

Two techniques are mainly used for the formulation of microspheres are as follow;

• Normal polymerization:

In bulk polymerization, a monomer or a mixture of a number of monomers along with the initiator or catalyst is usually heated to initiate polymerization. The polymer so obtained

may be molded as microspheres. Drug may be done by adding the drug during the process of polymerization. It is a pure polymer formation technique but it is very difficult to dissipate the heat of the reaction which affects the thermolabile the active ingredients.

Suspension polymerization is carried out at a lower temperature and also refer to as pearl polymerization in which heating the monomer mixture with the active drug as droplets

dispersion in the continuous aqueous phase.

• Interfacial polymerization:

The reaction of various monomers at the interface between the two immiscible liquid phases forms a film of polymer that essentially envelops the dispersed phase. In this

technique two reacting monomers are employed; one is dissolved in the continuous phase while the other is dispersed in continuous phase (aqueous in nature) throughout which the second monomer is emulsified.

Spray drying ^[27]:

The polymer is first dissolved in a suitable volatile organic solvent, such as dichloromethane or acetone, before being spray dried. Thereafter, the compound is dispersed in a polymer solution using high-speed homogenization. This dispersion is then atomized in a hot air current. The atomization results in the formation of tiny droplets or fine mist from which the solvent evaporates instantaneously leading to the formation of microspheres in the 1-100μm range. Microparticles are separated from hot air using a cyclone separator, and the solvent residue is removed using vacuum drying. One of the main benefits of the procedure is the viability of action under aseptic conditions. This process is rapid, leading to the formation of porous microparticles.

Solvent evaporation ^[28]:

Solvent evaporation method is used for the preparation of microparticles, involves removal of the organic phase by extraction of the organic solvent. The method involves water miscible organic solvents such as isopropanol. Organic phase is removed by extraction with water. This process decreases the hardening time for then microspheres. One variation of the process involve direct addition of the drug or protein to polymer organic solution. The rate of solvent removal by extraction method depends on the temperature of water, ratio of emulsion volume to the water and the solubility profile of the polymer.

EVALUATION PARAMETERS OF MICROSPHERES:

Characterization:

The characterization of the microparticulate carrier is a significant phenomenon that aids in the development of a suitable carrier for the delivery of proteins, drugs, or antigens. The microstructures of these microspheres vary. The release and stability of the carrier are determined by these microstructures.^[29]

Particle size and shape:

The most well-known used procedures to visualize microparticles are conventional light microscopy (LM) and scanning electron microscopy (SEM). Both can be used to analyze the shape and outer structure of microparticles. LM provides control over coating parameters in the case of double-walled microspheres. The microspheres structures can be seen before and after coating and the change can be measured microscopically. SEM provides a higher resolution in contrast to the LM. SEM enables the investigation of the surfaces of the microspheres, and when the particles are cross-sectioned, it can also be used for the investigation of double-walled structures.^[29]

Electron spectroscopy for chemical analysis:

The surface chemistry of the microspheres can be determined using electron spectroscopy for chemical analysis (ESCA).^[30]

Density determination:

The density of the microspheres can be calculated by using a multi-volume pycnometer.^[31]

Isoelectric point:

Micro-electrophoresis is used to calculate the electrophoretic mobility of microspheres from which the isoelectric point can be calculated.^[32]

Angle of contact:

The contact angle is determined to determine the wetting properties of the microparticle carrier.^[33]

In vitro methods:

Release studies for a specific type of microsphere are executed using a different suitable dissolution medium, often by rotating paddle apparatus (USP/BP).^[34]

Drug entrapment efficiency:

The entrapment efficiency of the microspheres or the percent entrapment can be determined by holding the microspheres in the buffer solution and allowing lysing. The lysate obtained is filtered or centrifuged and then subjected to monograph requirements for the determination of active constituents.  Drug entrapment efficiency can be calculated using the following equation,

% Entrapment = Actual content / Theoretical content x 100 ^[35]

Percentage yield:

It is calculated as the weight of microspheres obtained from each batch divided by the total weight of drug and polymer used to prepare that batch multiplied by 100. ^[35]

Flow properties ^[35,36]:

Density:

• Bulk density: It is measured by pouring a sample of microspheres of known weight into a measuring cylinder without tapping and measuring its length, and then dividing the weight by the volume.         Bulk density = wt. of microspheres/bulk         volume
• Tapped density: It is determined by pouring a sample of microspheres of known weight into a measuring cylinder & thoroughly tapping it & measuring its volume, then dividing the weight by the volume.                  Tapped density = wt. of the microspheres/volume after tapping
• Hausner’s ratio: Hausner’s ratio is the ratio of the tapped density to the bulk density of microspheres & can be used to predict microspheres flow. A Low Hausner’s ratio of < 1.2 indicates a free-flowing microsphere.                       Hausner’s ratio = bulk density – tapped density
• Angle of repose: It is defined as the maximum angle to the horizontal that is attainable by a heap of microspheres. The fixed height cone and the fixed base cone are among the methods available for calculating the angle of repose.    Angle of Repose????= tan−1 h/r        r = the radius of the base of the heap of microsphere ;h = height of the heap of microsphere

Zeta potential: The polyelectrolyte shell is set up by consolidating chitosan of various atomic load into the W2 stage and the subsequent particles are dictated by zeta potential estimation.^[37]

Attenuated total reflectance Fourier Transform Infrared Spectroscopy:

FT-IR is used to determine the deterioration of the carrier device polymer matrix. The surface of the microspheres shall be examined by calculating the alternative cumulative reflectance (ATR). The ATR-FTIR shall include details on the surface composition of the microspheres, depending on the manufacturing processes and conditions.^[38,39]

In-vitro release study:

Standard IP/BP/USP disintegration mechanical assembly is used to think about the in-vitro discharge profile in the disintegrating media which is the liquid present at the ingestion site according to the monograph, the use of a pivoting bin or an oar form disintegration contraption.

APPLICATIONS OF MICROSPHERES:

Oral drug delivery:

The oral route is an easy and convenient route for administration of the drug with higher patient compliance. There are large numbers of pharmaceutical products administered through the oral route. The principal behind oral absorption totally depends on the solubility and permeability of the drug. Microsphere drug delivery offers a sustained and controlled manner drug release for a longer period of time leads to reduce dosing frequency and improve patient compliance.^[40]

Transdermal and topical drug delivery:

Polymers having good film-forming ability used for delivery of drug through the skin, for example, Chitosan, Alginate, and PLGA loaded microspheres are used as Transdermal Drug Delivery. It also used for delivering the drug for topical application, for example, Asiaticoside loaded microspheres for wound healing showing an acceleration in reepithelization as well as promoting the angiogenesis.^[41]

Gene therapy:

In this technique, microspheres are fabricated with viral vectors in gene-drug delivery. This technique offers ease of preparation, site targeting, and large scale production and shows low immunogenic response as compared to the direct viral vector drug delivery.^[42]

Intranasal drug delivery:

This route is mainly preferred for the delivery of proteins and the peptides. Conventional formulations are easily get drained off from nasal mucosa. Bioadhesive microspheres provide better bioavailability by exerting its sustained/controlled mechanism.^[43]

Buccal drug delivery:

Mucoadhesive microspheres serve as a reservoir for the drug; it releases the drug from the applied site for a longer period of time. Mucoadhesive polymers reside on the mucosa of the buccal cavity and act as a reservoir; it also improves the bioavailability of the drug by avoiding first-pass metabolism in the body.^[44]

Intra-tumoral and local drug delivery:

Anticancer drugs should be delivered at the tumor site inappropriate concentration, for example, paclitaxel loaded microspheres. Film forming polymers are used to sustain the release at local site, that is, oral cavity.^[45]

Vaccine delivery:

The precondition of a vaccine is safety toward the microbes and its harmful component. An ideal vaccine should satisfy this same necessity of effectiveness, protection, affordability in application and charge. The aspect of protection and avoidance of severe effects is a complicated. The aspect of safeness and the extent of the manufacturing of antibody responses are intently linked to mode of application. Biodegradable delivery technology for vaccines which are provided by intravenous path may resolve the shortcoming of this same conventional vaccines. The involvement in parenteral (subcutaneous, intramuscular, intradermal)carrier exists even though those who offer significant benefits.^[46]

Colonic drug delivery:

 Microspheres are used for delivering the drug at a specific site in intestine, that is, colon. Insulin loaded into chitosan microspheres targeted to release its drug at colon. ^[47]

Vaginal drug delivery:

Microspheres drug delivery used for treating vaginal infections such as mycotic infection of the genital tract. Chitosan, Gelatin, and PLGA polymers are used for fabricating the microspheres to treat vaginal infections.^[48]

Targeting using microparticulate carriers:

The principle of trying to target is a well established dogma, that is trying to gain huge interest present a days. The response manufactured by drug depends itself on availability and ability to interact to binding site generally pellets technique is confirmed that can be formulated by utilizing extrusion / Spheronization innovation e.g. microcrystalline cellulose (MCC) and chitosan.^[49]

Radioactive application:

It can be used for embolization of liver and spleen tumors. It is used for radio synvectomy of arthritis joints, local radiotherapy, interactivity treatment, Imaging of liver, spleen, bone marrow, lung and even imaging of thrombus in deep vein thrombosis can be done.^[50]

Other applications:

Fluorescent microspheres can be used for membrane based technology for flow cytometry, cell biology, microbiology, Fluorescent Linked Immuno-Sorbent Assay.^[51] Yttrium 90 can be used for primary treatment of hepatocellular carcinoma and also used for pre transplant management of HCC with promising results.^[52]

CONCLUSION

Microsphere-based drug delivery systems represent a promising approach for achieving targeted and controlled therapeutic outcomes. Their ability to encapsulate a wide range of drugs, protect active agents from degradation, and provide sustained and site-specific release makes them highly advantageous over conventional dosage forms. Advances in polymer science and formulation techniques have enabled the development of microspheres with tailored physicochemical properties and targeting capabilities. Applications in cancer therapy, vaccine delivery, and treatment of chronic diseases highlight their broad therapeutic potential. However, challenges such as scale-up, batch-to-batch reproducibility, long-term safety, and regulatory complexities continue to limit their widespread clinical translation. Future research focused on multifunctional microspheres, improved targeting efficiency, and scalable manufacturing processes is expected to further enhance their role in next-generation targeted drug delivery systems.

REFERENCES

1. Reddy BV, Krishnaveni K. Formulation and evaluation of efavirenz microspheres. Der Pharmacia letters. 2015;7(6):1-9.
2. Inada A, Oue T, Yamashita S, Yamasaki M, Oshima T, Matsuyama H. Development of highly water-dispersible complexes between coenzyme Q10 and protein hydrolysates. European Journal of Pharmaceutical Sciences. 2019 Aug 1;136:104936.
3. Chaudhari A, Jadhav KR, Kadam VJ. An overview: Microspheres as a nasal drug delivery system. Int J Pharm Sci Rev Res. 2010 Nov;5(1):8-17.
4. Mathew Sam T, Devi Gayathri S, Prasanth VV, Vinod B. NSAIDs as microspheres. The Internet Journal of Pharmacology. 2008;6(1):332-8.
5. Basarkar G, Shirsath G, Patil S. Development of microspheres containing Diclofenacdiethylamine as sustained release topical formulation. Bull Pharm Res. 2013;3(1):14-22.
6. Verma NK, Alam G, Vishwakarma DK, Mishra JN, Khan WU, Singh AP, Roshan A. RecentAdvances in Microspheres Technology for Drug Delivery. International Journal of Pharmaceutical Sciences and Nanotechnology (IJPSN). 2015 May 31;8(2):2799-813.
7. Vyas SP, Khar RK. Targeted and Controlled drug delivery., 7th Edition; Vallabh Prakashan, New Delhi India , 420-445.
8. Dr. Fishers  Microsphere Selection  Bangs laboratories inc, Tech Notes 201 A, 1-4 Available from URL http://www.bangslabs.com/sites/default/files/bangs/do cs/pdf/201A.pdf
9. Khar R.K, Vyas, S.P. Targeted and Controlled Drug Delivery- Novel Carrier Systems., 1st edition. CBS Publications and Distributors, New Delhi; 2002; 417- 418.
10.  Kreuter J, Nefzger M, Liehl E, CzokR VR. Microspheres–A Novel Approach in Drug Delivery System. J Pharm sci. 1983;72(1146):48-78.
11. Singh C, Purohit S, Singh M, Pandey BL. Design and evaluation of microspheres: A Review. Journal of drug delivery research. 2013; 2(2):18-27.
12. Midha K, Nagpal M, Arora S. Microspheres: a recent update. International Journal of Recent Scientific Research. 2015; Jul;50(8): 5859-67.
13.  Sipai AB, Vandanayadav M, Mamatha Y, Prasanth VV. Mucoadhesive Microsphere An overview. American Journal of Pharmaceutical Research. 2012; 2(1):237-58.
14.  Liu G, Yang H, Zhou J, Law SJ, Jiang Q, Yang G. Preparation of magnetic microspheres from water-in-oil emulsion stabilized by block copolymer dispersant. Biomacromolecules. 2005 May 9;6(3):1280-8.
15. Guojun Liu, Husheng Yang, Jiayun Zhou, Preparation of magnetic microsphere from waterin-oil emulsion stabilized by block copolymer dispersant,. Biomacromolecules , 6, 2005, 1280-1288.
16.  Yadav AV, Mote HH.  Development of Biodegradable Starch Microspheres for Intranasal Delivery, Indian Journal of pharmaceutical Sciences. 2008; 70(2):170-174.
17. Saralidze K, Leo H, Koole, Menno L, Knetsch W. Polymeric Microspheres for Medical Applications, Materials.2010; 3:3357-3564.
18. Trivedi P, Vermal, Garud N. Preparation and Characterization of Acelofenac Microspheres, Asian Journal of pharmaceutics.2008; 2(2):110-115.
19. Nikam VK, Gudsoorkar VR, Hiremath SN, Dolas RT, Kashid VA. Microspheres-A Novel drug delivery system: An overview; International Journal of Pharmaceutical and chemical sciences. 2012 Jan; 1(1):113-28.
20. Alagusundaram M, Chetty MS, Umashankari K, Badarinath AV, Lavanya C, Ramakant S. Microspheres: As novel drug delivery system. International Journal of Chem Tech Research. 2009 Jul; 1(3):526-34.
21. Jayaprakash S, Halith S M, Mohamed Firthouse P U, Kulaturanpillai K, Abhijith, Nagarajan M. Preparation and evaluation of biodegradable microspheres of methotrexate. Asian Journal of Pharmaceutical sciences.2009; 3(1):26-9.
22. Sinha V R, Bansal K, Kaushik R, Kumria R, Trehan A. Polycaprolactone microspheres and nanospheres: an overview. International Journal of Pharmaceutics . 2004 Jun 18; 278(1): 1–23
23. Kumar A, Jha S, Rawal R, Chauhan PS and Maurya SD. Mucoadhesive microspheres for novel drug delivery system: A Review. American Journal of Pharm Tech Research. 2013; 3(4):195-213.
24. Meena KP, Dangi JS, Samal PK, Namedo KP. Recent advances in microsphere manufacturing technology. International Journal of Pharmacy and Technology. 2011 Mar; 3(1):854-855.
25. Jain NK. Controlled and Novel drug delivery; CBS Publishers New Delhi, India; 04 Edition.2004; 236-237, 21.
26. Kadam NR, Suvarna V. Microsphere: a brief review. Asian Journal of Biomedical and Pharmaceutical Sciences. 2015 Aug 1; 5(47):13.
27. Thanoo BC, Sunny MC, Jayakrishanan A. Cross-linked chitosan microspheres: Preparation and evaluation as a matrix for the controlled release of pharmaceuticals. Journal of Pharmacy and Pharmacology. 1992 Apr; 44(4):283-286
28. Agusundaram M, Madhu Sudana Chetty et al.  Microsphere As A Novel Drug Delivery System A Review. International Journal of ChemTech Research.  2009;1(3):526-534.
29. Singh C, Purohit S, Singh M, Pandey B.L. Design and evaluation of microspheres: A Review, Journal of Drug Development and Research 2013; 2(2):18- 27.
30. Sahil K, Akanksha M, Premjeet S, Bilandi A, Kapoor B. Microsphere: A review. International Journal of Research in Pharmacy and Chemistry 2011; 1(11):84-98.
31. Kumar BP, Chandiran IS, Bhavya B, Sindhuri M. Microparticulate drug delivery system: a review. Indian journal of pharmaceutical science & research. 2011;1(1):19-37.
32. Dhakar R.C, Maurya S.D, Sagar B.P.S, Bhagat S, Prajapati S.K, Jain C.P. Variables influencing the drug entrapment efficiency of microspheres: A pharmaceutical review. Der Pharmacia Lettre. 2010; 2(5):102-116.
33. Gogu PK, Jithan AV. Preparation and in vitro/in vivo characterization of spray dried microsphere formulation encapsulating 4-chlorocurcumin. Indian journal of pharmaceutical sciences. 2010 May;72(3):346.
34. Alagusundaram M, Chetty MS, Umashankari K, Badarinath AV, Lavanya C, Ramkanth S. Microspheres as a novel drug delivery system: A review. International Journal of Chem Tech Research. 2009; 1(3):526-534.
35. Patel NR, Patel DA, Bharadia PD, Pandya V, Modi D. Microsphere as a novel drug deliver. International Journal of Pharmacy & Life Sciences. 2011 Aug 1; 2(8).
36. Thadanki M, Chadalawada PK, Lavanya P., Umashankar D: Formulation and evaluation of sustained release saxagliptin microspheres by ionotropic gelation method. International

Journal of Bioassays. 2017; pg. no. 5328-5333.

37. Dupinder K, Seema S: Variable Effecting Drug Entrapment Efficiency of Microspheres: A Review. International Research Journal of Pharmaceutical and Applied Sciences (IRJPAS); 2013; 3(3):24-28.
38. Sailaja AK, Anusha K. Review on microspheres as a drug delivery carrier. International Journal of Advances in Pharmaceutics 2017 May 30; 06(05):96-102.
39. Virmani T, Gupta J. Pharmaceutical Application of Microspheres: An Approach for the Treatment of Various Diseases; International Journal of Pharmaceutical Sciences and Research, 2017; 8(8):3253- 3260.
40. Jiang WZ, Cai Y, Li HY. Chitosan-based spray-dried mucoadhesive microspheres for sustained oromucosal drug delivery. Powder Technology 2017 May 1;312:124-32.
41. Lee S, McAuliffe DJ, Kollias N, Flotte TJ, Doukas AG. Photomechanical     delivery of 100?nm     microspheres  through           the       stratum              corneum: Implications for transdermal drug delivery. Lasers in Surgery and Medicine 2002 Sep;31(3):207-10.
42. Xu Q, Leong J, Chua QY, Chi YT, Chow PK, Pack DW, Wang CH. Combined modality doxorubicin-based chemotherapy and chitosan-mediated p53 gene therapy using double-walled microspheres for treatment of human hepatocellular carcinoma. Biomaterials. 2013 Jul 1;34(21):5149-62.
43. Sahu Y, Jain S, Shukla K. Mucoadhesive microspheres based formulation development of ziprasidone hydrochloride for nasal delivery. Journal of Drug Delivery & Therapeutics. 2020 Sep 1;10(5):175-81.
44. Jiang WZ, Cai Y, Li HY. Chitosan-based spray-dried mucoadhesive microspheres for sustained oromucosal drug delivery. Powder Technol 2017;312:124-32.
45. Almond BA, Hadba AR, Freeman ST, Cuevas BJ, York AM, Detrisac CJ, Goldberg EP. Efficacy of mitoxantrone-loaded albumin microspheres for intratumoral chemotherapy of breast cancer. Journal of controlled release. 2003 Aug 28;91(1-2):147-55.
46. Abbaraju Krishna shailaja, et. al., Biomedical applications ofmicrospheres, Journal of Modern Drug Discovery and Drug Delivery Research, 2015, 4 (2), Page 1-5.
47. Wang QS, Wang GF, Zhou J, Gao LN, Cui YL. Colon targeted oral drug delivery system based on alginate-chitosan microspheres loaded with icariin in the treatment of ulcerative colitis. International journal of pharmaceutics. 2016 Dec 30;515(1-2):176-85.
48. Yang TT, Cheng YZ, Qin M, Wang YH, Yu HL, Wang AL, Zhang WF. Thermosensitive chitosan hydrogels containing polymeric microspheres for vaginal drug delivery. BioMed Research International. 2017;2017(1):3564060.
49. Tarun Virman, et. al., Pharmaceutical Application Of Microspheres: An Approach For The Treatment Of Various Diseases, International Journal of Pharmaceutical Science and Reaserch, 2017; Vol. 8(8): 3252-3260.
50. Prasanth VV, Moy AC, Mathew ST, Mathapan R. Microspheres-an overview. International journal of research in pharmaceutical and biomedical sciences. 2011 Apr;2(2):332-8.
51. Rajput MS and Agarwal P: Microspheres in cell biology. Indian Journal of Pharmacy 2010; 47:458-468.
52. Ali SM: Radioembolization for hepatocellular carcinoma using Therasphere. The Suadi Journal of Gastroenterology 2011 May 1; 17(3):215-217.
