Review On the Development of Microsphere-Loaded Gel: A Novel Drug Delivery System

Abstract

Microsphere-loaded gels have emerged as an innovative approach in novel drug delivery systems (NDDS), combining the benefits of controlled-release microspheres with the bioadhesive and sustained drug-release properties of hydrogels. These systems offer prolonged drug retention, improved bioavailability, and localized delivery, reducing systemic side effects. They have been extensively studied for applications in ophthalmic, transdermal, intra-articular, and cancer drug delivery. This review provides an in-depth analysis of the formulation, mechanisms, advantages, challenges, and future prospects of microsphere-loaded gels. Microspheres were prepared by the chemical denaturation method using glutaraldehyde as a cross-linking agent. The microspheres were characterized by particle size analysis, zeta potential, scanning electron microscopy (SEM) and stability study. Several factors such as stirring rate, temperature, and viscosity show an effect on the size. The sizes of the microspheres were found to be 156.5 nm.

Keywords

Microsphere-Loaded Gel, Novel Drug Delivery System, glutaraldehyde, zeta potential, scanning electron microscopy.

Introduction

Conventional drug delivery methods often suffer from limitations such as poor bioavailability, frequent dosing, systemic toxicity, and instability of therapeutic agents. The concept of drug delivery has been revolutionized. The strides have been made to lend the patient derive maximum benefits of drug. The drug should be delivered to specific target sites at a rate and concentration that permit optimum therapeutic efficacy while reducing side effects to minimum. Another aspect to be considered in drug delivery is patient compliance during drug therapy. The need for innovative drug delivery approaches has led to the development of microsphere-loaded gels, which integrate two key components:

1. Microspheres – Microspheres are small spherical particles, with diameters in the micrometer range (typically 1 μm to 1000 μm). Microspheres are sometimes referred to as microparticles. Microspheres can be manufactured from various natural and synthetic materials. Glass microspheres, polymer microspheres and ceramic microspheres are commercially available. Solid and hollow microspheres vary widely in density and, therefore, are used for different applications.

2. Gels – Hydrophilic or hydrophobic polymeric networks that enhance drug retention and bioadhesion.

This system allows for sustained drug release, localized targeting, and improved patient compliance, making it a promising approach in pharmaceutical and biomedical applications.

2. Formulation Strategies of Microsphere-Loaded Gels

The formulation of microsphere-loaded gels consists of two major components:

2.1. Preparation of Microspheres

Microspheres serve as drug carriers that protect the drug from degradation and control its release. They are usually composed of biodegradable polymers such as:

Natural Polymers: Chitosan, Alginate, Gelatin.

Synthetic Polymers: Poly(lactic-co-glycolic acid) (PLGA), Polycaprolactone (PCL), Polyvinyl alcohol (PVA).

Methods of Microsphere Preparation:

1. Solvent Evaporation: An emulsion-based method where the organic solvent is evaporated, leading to solidification of the microspheres.

2. Ionic Gelation: Used mainly for biopolymers like chitosan and alginate, where cross-linking occurs upon interaction with oppositely charged ions.

3. Spray Drying: Involves rapid drying of the drug-polymer solution, forming microspheres with controlled size.

4. Coacervation/Phase Separation: A method where polymer precipitation occurs due to non-solvent addition.

5. Emulsification-Solvent Diffusion: A two-phase method used for hydrophobic drugs, ensuring uniform encapsulation.

2.2. Preparation of Gel Matrix

The gel serves as a viscous carrier for the microspheres, allowing prolonged retention at the application site.

Types of gels used in formulation:

Hydrophilic Gels: Carbopol, Hydroxypropyl Methylcellulose (HPMC), Xanthan gum.

Hydrophobic Gels: Polyethylene glycol (PEG), Poloxamers.

Thermo-Sensitive Gels: Pluronic F-127, which transitions from sol to gel upon temperature change. The interaction between microspheres and the gel matrix ensures drug stabilization and sustained release, depending on polymer composition, cross-linking density, and drug-polymer interactions.

3. Mechanism Of Drug Release From Microsphere-Loaded Gels

The release of drugs from microsphere-loaded gels follows multiple mechanisms, including:

3.1. Diffusion-Controlled Release:

The drug diffuses through the polymeric gel matrix or microsphere shell into the surrounding medium. Example: Hydrophilic drugs release through gel swelling and polymer relaxation.

3.2. Erosion-Controlled Release:

The polymer matrix undergoes degradation, leading to gradual drug release. Example: PLGA microspheres degrade in physiological fluids, releasing encapsulated drugs.

3.3. Swelling-Controlled Release:

Hydrophilic gel matrices absorb water, expand, and create a pathway for drug diffusion.

3.4. Stimuli-Responsive Release:

pH-Responsive: Drug release varies with pH changes (e.g., gastrointestinal-targeted delivery).

Enzyme-Triggered: Enzymatic degradation of microspheres leads to controlled drug release (e.g., intra-articular delivery).

4. Advantages Of Microsphere-Loaded Gels

Microsphere-loaded gels combine the benefits of both microspheres and gels, making them an excellent choice for drug delivery and other applications. Here are some key advantages:

1. Controlled and Sustained Drug Release

Microspheres help in prolonged drug release, reducing the frequency of dosing. Ensures a steady therapeutic effect over time.

2. Enhanced Drug Stability

Protects sensitive drugs (e.g., proteins, peptides) from degradation. Improves the shelf life of the formulation.

3. Improved Bioavailability

Gels enhance drug penetration through tissues. Microspheres can improve drug absorption by targeting specific sites in the body.

4. Localized Drug Delivery

Useful for topical, ophthalmic, oral, or injectable applications. Reduces systemic side effects by keeping the drug at the site of action.

5. Patient Compliance

Less frequent dosing means better adherence to the treatment. The gel form is easy to apply and comfortable for patients.

6. Versatile Applications

Can be used for hydrophilic and hydrophobic drugs. Useful in wound healing, cancer therapy, ophthalmic treatments, and transdermal delivery.

5. Challenges And Limitations

Despite its advantages, microsphere-loaded gels face several formulation and regulatory challenges:

1. Stability Issues: Microsphere aggregation or polymer degradation may occur over time.

2. Complex Manufacturing Process: Requires precise control over microsphere size, drug loading, and gel consistency.

3. Sterilization Challenges: Injectable formulations must maintain sterility without affecting drug stability.

4. Limited Drug Loading Capacity: Encapsulation efficiency varies depending on polymer-drug interactions.

5. High Production Cost: Advanced polymeric formulations increase the overall cost of development.

6. Applications Of Microsphere-Loaded Gels

There are some applications of microsphere-loaded gels:

6.1. Ophthalmic Drug Delivery

Used for sustained drug release in glaucoma, conjunctivitis, and dry eye syndrome. Example: Timolol-loaded microsphere gel for intraocular pressure control.

6.2. Dermatological and Transdermal Drug Delivery

Used for wound healing, acne treatment, and transdermal drug patches. Example: Clindamycin microsphere gel for prolonged acne treatment.

6.3. Intra-Articular Drug Delivery

Provides long-term pain relief in osteoarthritis and rheumatoid arthritis. Example: Diclofenac-loaded microsphere gel for joint pain management.

6.4. Cancer Therapy

Ensures localized chemotherapy with reduced systemic toxicity. Example: Paclitaxel-loaded microspheres in a hydrogel matrix for breast cancer therapy.

6.5. Wound Healing and Tissue Engineering

Growth factors, antibiotics, and anti-inflammatory agents can be encapsulated for faster healing. Example: Curcumin-loaded microsphere gel for diabetic wound healing.

7. Future Perspectives and Innovations

Microsphere-loaded gels are gaining attention in pharmaceutical and biomedical fields due to their ability to provide controlled, targeted, and prolonged drug delivery. Future advancements aim to enhance their efficiency, safety, and versatility.

1. Smart and Stimuli-Responsive Gels

pH-sensitive gels: Release drugs in response to pH changes (e.g., in cancer or gastric conditions). Temperature-sensitive gels: Deliver drugs when body temperature increases, useful for fever-related conditions. Enzyme-responsive gels: Trigger drug release in response to disease-specific enzymes.

2. Nanotechnology Integration

Nano-Microsphere Hybrids: Combining nanoparticles and microspheres for better drug penetration and bioavailability.

Magnetic Microspheres: Used in cancer therapy and targeted delivery, where an external magnetic field guides the drug to the diseased site.

3. 3D Printing for Personalized Medicine

Customizable drug-loaded gels using 3D printing for patient-specific treatments. Tailored drug release profiles based on individual needs.

4. Injectable and Biodegradable Microsphere Gels

Biodegradable polymers (e.g., PLGA, chitosan) reduce toxicity and eliminate the need for surgical removal. Injectable gel formulations improve patient compliance, especially in ophthalmic and orthopedic applications.

5. Advanced Wound Healing and Regenerative Medicine

Microsphere-loaded hydrogel scaffolds for tissue regeneration and wound healing. Growth factor-loaded microspheres for faster healing of diabetic wounds or burns.

6. AI and Machine Learning in Formulation Development

Predictive modeling for optimizing drug release kinetics. AI-driven personalized drug delivery systems to enhance treatment efficacy.

7. Multi-Drug and Combination Therapy

Microsphere-loaded gels could co-deliver multiple drugs, such as antibiotics and pain relievers, for more effective treatment. Useful in cancer therapy where chemotherapy and immunotherapy drugs need to be delivered together.

8. CONCLUSION

Microsphere-loaded gels represent a breakthrough in controlled drug delivery, offering sustained release, improved bioavailability, and localized therapeutic effects. Despite formulation challenges, advancements in biodegradable polymers, nanotechnology, and 3D printing are driving the development of next-generation microsphere-loaded gels. Their potential in ophthalmology, dermatology, cancer therapy, and orthopedic treatments makes them a promising candidate for future pharmaceutical innovations.  Microsphere-loaded gels have a promising future in personalized medicine, controlled drug release, and targeted therapy. Innovations in smart materials, nanotechnology, and AI-driven formulations will further enhance their potential in pharmaceuticals, wound healing, and regenerative medicine.

REFERENCES

1. 1. 1. 1. Das, M. K., Ahmed, A. B., & Saha, D. (2019). "Microsphere: A Drug Delivery System–A Review." International Journal of Current Pharmaceutical Research, 11(4), 34-41.
         2. Kong, X., Xu, W., Zhang, C., & Kong, W. (2018). "Chitosan Temperature?Sensitive Gel Loaded with Drug Microspheres Has Excellent Effectiveness, Biocompatibility, and Safety as an Ophthalmic Drug Delivery System." Experimental and Therapeutic Medicine, 15(2), 1442-1448.
         3. Grizic, D., & Lamprecht, A. (2020). "Predictability of Drug Encapsulation and Release from Propylene Carbonate/PLGA Microparticles." International Journal of Pharmaceutics, 586, 119601.
         4. Kozak, J., & Rabiskova, M. (2021). "In Vitro Drug Release Testing of Parenteral Formulations via an Agarose Gel Envelope to Closer Mimic Tissue Firmness." International Journal of Pharmaceutics, 594, 120142.
         5. Algharib, S. A., Dawood, A., Zhou, K., Chen, D., Li, C., Meng, K., Zhang, A., Luo, W., Ahmed, S., Huang, L., & Xie, S. (2022). "Preparation of Chitosan Nanoparticles by Ionotropic Gelation Technique: Effects of Formulation Parameters and In Vitro Characterization." Journal
         6. Muthukumar, T., Sankari, D., Tamil Selvi, A., & Sastry, T. P. (2014). Preparation, characterization, and in vitro bioactivity of Bixa Orellana extract-impregnated collagen microspheres. Journal of Materials Science, 49, 5730-5737.
         7. Cui, F., Yang, M., Jiang, Y., Cun, D., Lin, W., Fan, Y., & Kawashima, Y. (2003). Design of sustained-release nitrendipine microspheres having solid dispersion structure by quasi-emulsion solvent diffusion method. Journal of controlled release, 91(3), 375-384.
         8. Li, G. Y., Zhong, M., Zhong, Y. D., Ding, P., & Huang, Y. (2011). Formulation optimization of chelerythrine loaded O-carboxymethylchitosan microspheres using response surface methodology. International journal of biological macromolecules, 49(5), 970-978.
         9. Pillaiyar, T., Namasivayam, V., Manickam, M., & Jung, S. H. (2018). Inhibitors of melanogenesis: an updated review. Journal of medicinal chemistry, 61(17), 7395-7418.
         10. D’Mello, S. A., Finlay, G. J., Baguley, B. C., & Askarian-Amiri, M. E. (2016). Signaling pathways in melanogenesis. International journal of molecular sciences, 17(7), 1144.
         11. Avcil, M., Akman, G., Klokkers, J., Jeong, D., & Çelik, A. (2021). Clinical efficacy of dissolvable microneedles armed with anti?melanogenic compounds to counter hyperpigmentation. Journal of Cosmetic Dermatology, 20(2), 605-614.
         12. Kumarasinghe, P. (Ed.). (2018). Pigmentary skin disorders. Springer.
         13. Kuroi, A., Sugimura, K., Kumagai, A., Kohara, A., Nagaoka, Y., Kawahara, H& Fuchino, H. (2017). The Importance of 11α-OH, 15-oxo, and 16-en Moieties of 11α-Hydroxy-15-oxo-kaur-16-en-19-oic Acid in Its Inhibitory Activity on Melanogenesis. Skin Pharmacology and Physiology, 30(4), 205-215.
         14. Baidya, B., Gupta, S. K., & Mukherjee, T. (2002). An extraction-based verification methodology for MEMS. Journal of Microelectromechanical Systems, 11(1), 2-11.
         15. Kokate CK, Purohit AP and Gokhale SB. Textbook of Pharmacognosy, Nirali Prakashan. 2000; 1–4.
         16. Jain, N., & Verma, A. (2020). Preformulation studies of pilocarpine hydrochloride as niosomal gels for ocular drug delivery. Asian Journal of Pharmaceutical and Clinical Research, 149-155.
         17. Fartyal, S., Jha, S. K., Karchuli, M. S., Gupta, R., & Vajpayee, A. (2011). Formulation and evaluation of floating microspheres of boswellic acid. Int J Pharm Tech Res, 3, 76-81.
         18. Singh, K. K., & Vingkar, S. K. (2008). Formulation, antimalarial activity and biodistribution of oral lipid nanoemulsion of primaquine. International Journal of Pharmaceutics, 347(1-2), 136-143.
         19. Voli?, M., Pe?inar, I., Mici?, D., ?or?evi?, V., Peši?, R., Nedovi?, V., & Obradovi?, N. (2022). Design and characterization of whey protein nanocarriers for thyme essential oil encapsulation obtained by freeze-drying. Food Chemistry, 386, 132749.
         20. Ahmed, M. M., Fatima, F., Kalam, M. A., Alshamsan, A., Soliman, G. A., Shaikh, A. A., & Anwer, M. K. (2020). Development of spray-dried amorphous solid dispersions of tadalafil using glycyrrhizin for enhanced dissolution and aphrodisiac activity in male rats. Saudi Pharmaceutical Journal, 28(12), 1817-1826.
         21. Mohammadi-Sichani, M., Karbasizadeh, V., Aghai, F., & Mofid, M. R. (2012). Effect of different extracts of Stevia rebaudiana leaves on Streptococcus mutans growth. J Med Plants Res, 6(32), 4731-34.
         22. Manandhar, S., Luitel, S., & Dahal, R. K. (2019). In vitro antimicrobial activity of some medicinal plants against human pathogenic bacteria. Journal of tropical medicine, 2019.
         23. Saharan, p., &saharan, s. P. (2024). Formulation, characterization and in-vitro evaluation of floating microsphere of ibuprofen using carbopol 940 polymer. Drug delivery, 5, 8.
         24. Baidya, B., Gupta, S. K., & Mukherjee, T. (2002). An extraction-based verification methodology for MEMS. Journal of Microelectromechanical Systems, 11(1), 2-11.
         25.  Kokate CK, Purohit AP and Gokhale SB. Textbook of Pharmacognosy, Nirali Prakashan. 2000; 1–4.
         26. Jain, N., & Verma, A. (2020). Preformulation studies of pilocarpine hydrochloride as niosomal gels for ocular drug delivery. Asian Journal of Pharmaceutical and Clinical Research, 149-155.
         27. Fartyal, S., Jha, S. K., Karchuli, M. S., Gupta, R., & Vajpayee, A. (2011). Formulation and evaluation of floating microspheres of boswellic acid. Int J Pharm Tech Res, 3, 76-81.
         28. Singh, K. K., & Vingkar, S. K. (2008). Formulation, antimalarial activity and biodistribution of oral lipid nanoemulsion of primaquine. International Journal of Pharmaceutics, 347(1-2), 136-143.
         29. Voli?, M., Pe?inar, I., Mici?, D., ?or?evi?, V., Peši?, R., Nedovi?, V., & Obradovi?, N. (2022). Design and characterization of whey protein nanocarriers for thyme essential oil encapsulation obtained by freeze-drying. Food Chemistry, 386, 132749.
         30. Ahmed, M. M., Fatima, F., Kalam, M. A., Alshamsan, A., Soliman, G. A., Shaikh, A. A., & Anwer, M. K. (2020). Development of spray-dried amorphous solid dispersions of tadalafil using glycyrrhizin for enhanced dissolution and aphrodisiac activity in male rats. Saudi Pharmaceutical Journal, 28(12), 1817-1826.
         31. Mohammadi-Sichani, M., Karbasizadeh, V., Aghai, F., & Mofid, M. R. (2012). Effect of different extracts of Stevia rebaudiana leaves on Streptococcus mutans growth. J Med Plants Res, 6(32), 4731-34.
         32. Manandhar, S., Luitel, S., & Dahal, R. K. (2019).In vitro antimicrobial activity of some medicinal plants against human pathogenic bacteria.Journal of tropical medicine, 2019.
         33. Sunanda Laxmi, P., Vidyavathi, M., & Venkata, S. K. R. (2021). DoE approach for development of localized controlled release microspheres of Vancomycin for treatment of septic arthritis. Future Journal of Pharmaceutical Sciences, 7, 1-15.
