Abstract

Nanotechnology supramolecular scale in the range of 1-100 nanometers. Nanotechnology is a modern science that is gaining immense popularity and applications in multiple scientific fields such as surface science, micro fabrication, semiconductor, molecular biology, electronics, medicine, consumer products and many other industrial and military applications. Nanotechnology also raises various issues like the impact of nanoparticles on the environment, toxicity, regulation of nanotechnology and nanoparticles and the overall impact of nanotechnology on global economics. The present article focuses on the past, present and future of nanotechnology with a special focus on the application of nanotechnology in various fields of medicine. Nanotechnology is the exploitation of the unique properties of materials at the nanoscale. Nanotechnology has gained popularity in several industries, as it offers better built and smarter products. The application of nanotechnology in medicine and healthcare is referred to as nanomedicine, and it has been used to combat some of the most common diseases, including cardiovascular diseases and cancer. The present review provides an overview of the recent advances of nanotechnology in the aspects of imaging and drug delivery.

Keywords

Nanotechnology, Nanomedicine, Devices based on Nanotechnology, Disease diagnosis, drug delivery

Introduction




Fig.no.2

Dendrimers

Carbon nanotubes

Metallic nanoparticles

Drugs are usually administered to a specific target place as part of therapy. External therapeutic approaches, such radiation therapy and surgery, are used when there is no internal channel for drug administration. These techniques are frequently applied singly or in concert to fight illnesses. Therapy's constant objective is to eradicate tumors or the source of disease in a persistent way. By creating new drug delivery mechanisms, nanotechnologies are making a significant contribution to this field. Several of these techniques have been shown to be useful in clinical settings and are currently in use. For instance, doxorubicin, a medication with a high level of toxicity, can be given directly to tumor cells via liposomes (Doxil) without harming the kidneys or heart. Furthermore, paclitaxel combined with polymeric mPEG-PLA micelles (Genexol-PM) is utilized in the chemotherapeutic management of breast tumors that have spread. The enhanced reticuloendothelial system evasion, favorable pharmacokinetics, and improved in vivo distribution are the main reasons for the success of nanotechnologies in drug administration.[19]

Both the capacity to target and control drug release are essential components of an ideal drug delivery system. By properly targeting and eliminating dangerous or malignant cells, side effects can be greatly decreased and treatment efficacy can be guaranteed. Furthermore, medication side effects might be lessened with controlled drug release. Because of their small size, which enables intravenous and other delivery methods, nanoparticle drug delivery systems have the advantage of reduced irritating reactions and improved penetration within the body. Adhesing nanoscaled radioactive antibodies complementary to antigens on the cancer cells with pharmaceuticals enables the specificity of nanoparticle drug delivery systems.

i) medication delivery to the intended location

ii) uptake of low solubility drugs summarizes the advantages of nanoparticles over conventional fine particles.[20]

At many different levels, including materials, systems, and devices, nanotechnology is being developed. Nanomaterials represent the most innovative level of information currently found in research and commercial applications. A small entity that functions as a single, cohesive unit in terms of its attributes and mobility is referred to as a particle in nanotechnology. It can be divided into fine and ultrafine particle categories based on size. Fine particles range in diameter from 100 to 2500 nanometers, and ultrafine particles are smaller, falling between 1 and 100 nanometers. Like ultrafine particles, nanoparticles are likewise sized between 1 and 100 nanometers. It is possible for nanoparticles to have size-related characteristics that are purposefully different from those seen in bulk materials and fine particles. As a result, nanoparticles are smaller than a few hundred nm. Their physical characteristics significantly alter as a result of this size decrease when compared to bulk material qualities. They may consist of a mixture of materials, minerals, metals, or polymers. Nanoparticle research is currently a hot topic in science because to its many potentiale uses in optical, electronic, and biological domains. The attraction of nanoparticles stems from their distinct and significant characteristics, including a surface to mass ratio significantly greater than that of other materials and particles, the capacity to adsorb and transport other substances like drugs, probes, and proteins, and the ability to catalytically promote reactions.[21]

• Advantages

It is possible to simply modify the particle size and surface properties of nanoparticles after parenteral delivery to accomplish both passive and active medication targeting.

• By attaching targeting ligands to particle surfaces or using magnetic guidance, site-specific targeting can be achieved. This leads to high drug therapeutic efficacy and fewer side effects.

• During transportation, they control and sustain release of the drug and at the localization site, altering distribution of the drug and subsequent clearance of the drug.
Oral, intraocular, parenteral, and nasal administration are among the modes of administration that the system can be utilized for.[22]
Preparation of nanoparticles

Based on the medicine to be loaded and the physicochemical characteristics of the polymer, the best preparation technique for nanoparticles is chosen. The following are the main techniques for preparing nanoparticles:

a. Emulsion-Solvent Evaporation Method;

 This approach is usually used to prepare the nanoparticles. This procedure mostly involves two steps. Emulsification of the polymer solution is necessary as the initial step in an aqueous phase. In the second stage, however, the polymer solution evaporates and the precipitation of the polymer is induced, resulting in the formation of nanospheres. Ultracentrifugation is used to collect the nanoparticles, which are then lyophilized for storage after being cleaned with distilled water to eliminate any remaining medication or residue. 18High pressure emulsification and the solvent evaporation method are other names for this process. 19 To remove organic solvent, this procedure entails homogenization under high pressure and general stirring.20 The size can be regulated by varying the temperature, the kind and quantity of the dispersion agent, the rate of stirring, and the viscosity of the organic and aqueous phases. 21 However, this technique can be used with lipid-soluble medications, and scale-up concerns impose limitations. PLGA24, cellulose acetate phthalate25, EC26, Poly (?-hydroxybutyrate) (PHB)22, Poly (caprolactone) (PCL)23, and PLA are the polymers employed in this process.[23]

b. Double Emulsion and Evaporation Method:

The primary shortcoming of this approach is the poor trapping of hydrophilic medicines. Consequently, the double emulsion method is used to encapsulate hydrophilic drugs. This method involves vigorously churning an organic polymer solution and adding aqueous drug solutions to create water-in-oil emulsions. After creating a mixed emulsion (w/o/w) by constant stirring, this w/o emulsion is introduced to another aqueous phase. The solvent is then eliminated by evaporation, and nanoparticles can be separated by rapidly centrifuging the mixture. The produced nanoparticles need to be cleaned before lyophilization. The amount of polymer, the volume of the aqueous phase, the concentration of the stabilizer, and the amount of hydrophilic medication included are the variables used in this approach. These factors also have an impact on how nanoparticles are characterized.[24]

c. Salting Out Method:

This method of separating the water-miscible solvent involves salting-out from an aqueous solution. Polyvinylpyrrolidone (PVP) or hydroxyethyl cellulose as a colloidal stabilizer are first dissolved in a solvent, which is then followed by the addition of the saltingout agent (electrolytes, such as calcium chloride, magnesium chloride, or sucrose as non-electrolytes) and the drug to create an aqueous gel that is emulsified. To enhance the solvent diffusion, which signals the creation of an aqueous phase, this oil in water emulsion is diluted with water. nanospheres. Numerous variables can be changed, including the concentration of the electrolyte, the amount of polymers in the organic phase, the kind of stabilizer, the velocity of stirring, and the ratio of the internal to exterior phases. This method produces PLA, poly(methacrylic) acids, and ethyl cellulose with great efficiency and ease of scaling up. nanospheres Since salting out doesn't require a rise in temperature, it might be helpful for materials that are sensitive to heat. The limitations of this approach include a limited application to lipophilic drugs and the need for lengthy washing procedures for nanoparticles.[25]

d. Emulsions Diffusion Method

To prepare nanoparticles, emulsions diffusion method is another method which iscommonly used. The encapsulating polymer is dissolvedin a solvent which is partially miscible with water such as propylene carbonate, benzyl alcohol and the initial thermodynamic equilibrium of both liquids saturated with water should be ensured. Subsequently, The polymer-water saturated solvent phase is emulsified in an aqueous solution containing stabilizer, leading to solvent diffusion to the external phase and according to the oil-topolymer ratio nanospheres or nanocapsules are formed. Finally, according to boiling point the solvent is removed by evaporation or filtration. This technique has several advantages, such as high reproducibility (batch-to-batch), no requirement of homogenization, high encapsulation efficiencies (generally 70%) simplicity, narrow size distribution and ease of scale-up However, this approach has significant disadvantages, such as large amounts of water that must be removed from the suspension and decreased encapsulation efficiency during emulsification due to water-soluble drug leakage in the saturated-aqueous exterior phase. Cyclosporine (cy-A-), loaded sodium glycolate nanoparticles, mesotetra (hydroxyphenyl) porphyrin-laden PLGA (p-THPP) nanoparticles, and doxorubicin-loaded PLGA nanoparticles are a few examples of drug-loaded nanoparticles that were created using this technology.[26]

e. Solvent Displacement/Precipitation method

The precipitation of a preformed polymer from an organic solution and the diffusion of the organic solvent in the aqueous medium, either with or without a surfactant, are examples of solvent displacement. Polymers, drugs, and lipophilic surfactants are dissolved in a semi-polar water miscible solvent, like ethanol or acetone. The solution is then injected or poured while being stirred magnetically.into an aqueous solution-containing stabilizer. Rapid solvent diffusion causes the formation of nanoparticles. Subsequently, the solvent is extracted from the suspension under low pressure. The pace at which the organic phase is added to the aqueous phase has an impact on the size of the particles as well. It was found that drug entrapment and particle size both decreased with increased mixing rate. The majority of medications that are poorly soluble can be effectively treated using nano precipitation. The size of the nanospheres and the release of the drug can be efficiently regulated by varying the production conditions. While varying the polymer's concentration produces good yields of nanospheres with lower sizes.[27]

 f. Polymerization method

In this approach, the medication is integrated either by adsorption onto the nanoparticles or by dissolving in the polymerization medium after the monomers are polymerized in an aqueous solution. By using ultra centrifugation, the stabilizers and surfactants used in the polymerization process are eliminated from the nanoparticle suspension. The particles are then re-suspended in an isotonic solution that is surfactant-free. This method has been published for the production of polybutyl cyanoacrylate or poly(alkylcyano acrylate) nanoparticles. The concentration of the stabilizers and surfactants utilized influences the formation of nanocapsules and their particle size.[28]

g. Coacervation or ionic gelation method

Much study has been done on the creation of nanoparticles employing hydrophilic biodegradable polymers like gelatin, chitosan, and sodium alginate. a technique created by Calvo and associates for ionic gelation to produce hydrophilic chitosan nanoparticles.39, 40 Two aqueous phases comprise the procedure: one phase comprises the polymer chitosan, while the second phase contains a polyanion, such as sodium tripolyphosphate. This approach creates coacervates with an anometer size range by interacting the positively charged amino group of chitosan with the negatively charged tri polyphosphate. Coacervates are formed when two aqueous phases interact electrostatically, and ionic gelation, which occurs at room temperature ionic interaction circumstances, causes a liquid to turn into a gel.[29]

Different Routes of Drug Delivery System:

The technique of delivering a pharmaceutical ingredient to produce a therapeutic effect in either people or animals is known as drug delivery. The importance of using nasal and pulmonary medication delivery channels for treating human diseases is growing. These delivery methods offer viable substitutes for parenteral medication administration, especially in the case of peptide and protein therapies. Numerous drug delivery methods have been developed for this reason, and pulmonary and nasal delivery are now being researched. These comprise, among other things, cyclodextrins, liposomes, proliposomes, microspheres, gels, and prodrugs. Biodegradable polymer-based nanoparticles provide certainty in meeting the strict specifications imposed on these delivery methods.characteristics, including the capacity to transform into an aerosol, stability against forces produced during aerosolization, biocompatibility, targeting of particular lung cell populations or places, controlled release of the medication, and disintegration within a reasonable amount of time.[30]

A. Beaded Delivery Systems:

Beaded delivery formulations are a further technique to provide long-acting drug levels associated with the ease of once-daily dosing, albeit they are not utilized in conjunction with oxybutylin. This system is marketed under the name Detrol LA (Pharmacia, Peapack, NJ) and has been effectively linked to tolterodine tartrate. The beaded system is basically made up of several tiny, inert beads made of polystyrene or some similar material. The delivery capsule containing the active medication is placed on top of the beads. This system's drug delivery is acid sensitive since the drug's release from the drug levels depends on the acidity of the stomach. A pharmacokinetic pattern that is akin to a zero-order pattern is produced by this procedure; C max is attained 4–6 hours after consumption, and sustained levels are shown for 24 hours following the initial dose. Detrol LA exhibits comparative advantages to immediate-release tolterodine in terms of both efficacy (improved rates of incontinence) and tolerability. The LA formulation produced 18?wer incontinence episodes than the immediate-release tolterodine in a double-blind, placebo-controlled, randomized study involving 1529 patients. Both formulations, however, were statistically better than the placebo in terms of decreasing frequency of urination and increasing volume of urine that was voided.[31]

B. Liposomal and Targeted Drug Delivery System

In theory, drug delivery systems can give anticancer medications increased efficacy and/or decreased toxicity. The "enhanced permeability and retention" effect can be used by long-circulating macromolecular carriers, like liposomes, to achieve preferential extravasation from tumor arteries. Liposomal anthracyclines, which include forms with much extended circulation such liposomal daunorubicin and pegylated liposomal doxorubicin, have achieved highly effective drug encapsulation, leading to considerable anticancer activity with reduced cardiac toxicity. Treatment for breast cancer with tigelated liposomal doxorubucin has demonstrated significant success when used alone or in conjunction with other chemotherapeutics. More liposome structures are being created to deliver different medications. True molecular targeting will be a feature of the next generation of delivery systems; immunoliposomes and other ligand-directed structures are examples of how biological elements with tumor identification capabilities might be integrated with delivery technology.[32]

As was previously said, the liposomal drug delivery methods that are now approved offer stable formulation, enhanced pharmacokinetics, and a certain amount of "passive" or "physiological" targeting to tumor tissue. These carriers do not, however, specifically target tumor cells. In addition to shielding liposomes from unfavorable interactions with cell membranes and plasma proteins, the design changes that set them apart from reactive carriers like cationic liposomes also stop interactions with tumor cells. Rather, liposomes stay within the tumor stroma as a drug-loaded depot following their extravasation into the tumor tissue. Eventually, phagocytic or enzymatic destruction of liposomes results in the release of medication, which diffuses into tumor cells. The upcoming generations of drug carriers are being developed with the ability to directly target cancer cells molecularly through interactions mediated by antibodies or other ligands.[33] A method for delivering drugs with molecular targeting is immuno liposomes, which are made of conjugated mAb fragments and liposomes. Fab' or scFv fragments attached to long-circulating liposomes have been used to create anti-HER2 immunoliposomes. Anti-HER2 immunoliposomes bound and internalized in HER2-overexpressing cells with efficiency in preclinical trials, leading to effective intracellular delivery of encapsulated drugs. In addition to demonstrating a markedly superior efficacy over all other treatments tested (free doxorubicin, liposomal doxorubicin, free mAb [trastuzumab], and combinations of trastuzumab plus doxorubicin or liposomal doxorubicin), anti-HER2 immunoliposomes loaded with doxorubicin also demonstrated potent and selective anticancer activity against HER2-overexpressing tumors. Scaling up of anti-HER2 immunoliposomes for clinical trials is presently underway.[34]

C. Lung-specific drug delivery

Compared to alternative administration methods, pulmonary medication delivery has a number of benefits for the treatment of respiratory disorders. It is possible to provide medication directly to the lungs by inhalation therapy. Without requiring high dose exposures through alternative modes of administration, the local pulmonary deposition and distribution of the supplied drug allows for a tailored therapy of respiratory illnesses, such as pulmonary arterial hypertension (PAH). For the past ten years, the preferred course of treatment for individuals with PAH has been the intravenous administration of short-acting vasodilators. The relative severity of side effects prompted the creation of novel prostacyclin analogs as well as alternate delivery systems. Iloprost (Ventavis), one such equivalent, is a medication that has been licensed for use in all countries to treat PAH. Because of this compound's pulmonary selectivity, inhaling it is an appealing idea for limiting adverse effects. Unfortunately, iloprost's short half-life necessitates repeated inhalation maneuvers—up to nine times daily. Consequently, a patient's convenience and compliance would be enhanced by an aerosolized controlled release formulation. The use of controlled drug delivery systems in inhalation therapy is becoming more and more appealing. Numerous carrier systems, such as drug-loaded lipid and polymer-based particles, have been created and explored as potential controlled drug delivery formulations to the lung. In nanomedicine, the application of colloidal carrier systems for pulmonary medication administration is gaining attention. [35]

D. Targeting to brain

The fact that mucosal surfaces serve as a primary point of entry for numerous infections is the reason for the increased interest in mucosal vaccination administration. Nasal administration is particularly appealing for vaccination among other mucosal sites because the nasal epithelium has a significant number of immunocompetent cells, low enzymatic activity, and relatively high permeability. Together with these benefits, the nasal route may also provide vaccination procedures that are easier to follow and more affordable while also improving patient compliance. Using nano carriers, antigenic substances can be efficiently transported into the nasal passage.  In addition to enhancing defense and expediting antigen transportation, nanoparticulate delivery technologies may enhance immune cell antigen recognition. These are important elements in the best possible presentation and processing of the antigen, and consequently in the formation of an appropriate immune response. Thus, the development of highly effective vaccine nanocarriers presents a viable approach to nasal mucosal immunization.[36]

E. Nano particulate systems for brain delivery of drugs

Using nanoparticles is one method of delivering medication to the brain. Polymeric particles known as nanoparticles are composed of synthetic or natural polymers and range in size from 1 mm to around 1000 nm. Drugs can be chemically bonded, adsorbed to the surface, or bound inside a solid solution or dispersion. To yet, only poly (butylcyanoacrylate) nanoparticles have shown effective in the in vivo administration of pharmaceuticals to the brain. The first medication to be administered to the brain via nanoparticle delivery was hexapeptidedalargin (Tyr-D-Ala- Gly- Phe-Leu-Arg), an opioid-active counterpart of leu-enkephalin. Drug delivery systems utilizing nanoparticles and nanoformulations have previously been used with remarkable effectiveness, and there is yet more promise for these systems involving the use of radiation treatment, anti-tumor, gene. [37]

F. Transdermal delivery

Bioadhesive liposomes containing levonorgestrel have been studied as a controlled drug delivery system.[26] The mesophasic proliposomal system of levonorgestral was developed. Most of the vesicles were unilamellar, however a small number of them were multilamellar. Zero order kinetics applied to the release. Alcohol affected transdermal flux more than oils did. Research carried out in vivo demonstrated the requirement for a loading dose due to a discernible latency period prior to the achievement of therapeutic levels. Proliposome technology was found to function better than the PEG-based ointment approach for topical delivery that is controlled and localized, a liposomal reservoir system containing the local anesthetic benzocaine was developed [33]. A gel and ointment basis was combined with the liposomal suspension. Unlike regular ointment, which releases the medication at a rapidly dropping rate every 24 hours, the systems delivered the medication at a consistent pace every day. Drugs did not absorb through human cadaver skin very quickly. Research carried out in vivo revealed that liposomal formulation has a longer-lasting effect. [38]

G. Colon-specific drug delivery:

The development of dosage forms with site-specific release is required due to the increasing number of protein and peptide medications under research. Colonic absorption is a novel approach to delivering peptide and protein therapeutic molecules, together with pharmaceuticals that are poorly absorbed through the upper gastrointestinal (GI) tract, into the systemic circulation. Oral colon-specific drug delivery techniques have definite advantages over parenteral administration. It goes without saying that colon targeting is advantageous for the topical treatment of colon conditions such as ulcerative colitis, Crohn's disease, and colorectal cancer. Medication administered by chronic colonic release may be useful in the treatment of angina, arthritis, and nocturnal asthma.[39] Colon-specific drug delivery systems have been demonstrated to be beneficial and required. Prodrugs, pH- and time-dependent systems, and microflora-activated systems were the main approaches used to achieve colon-specific delivery in the past. These approaches had varied degrees of success.
The triggering mechanism of the delivery system must only respond to the physiological conditions specific to the colon in order for colon medicine administration to be accurate. Ongoing efforts have been focused on creating colon-specific delivery systems with improved site specificity and flexible drug release kinetics in order to achieve a range of therapeutic goals.
In terms of achieving in vivo site specificity, design rationale, and manufacturing feasibility, four of the most recently developed colon-specific delivery systems—pressure-controlled colon delivery capsules (PCDCs), CODES, colonic drug delivery system based on pectin and galactomannan coating, and Azo hydrogels—were exceptional. In addition to offering thorough explanations of each of the four systems in particular, this study seeks to evaluate colon-specific drug delivery techniques generally both in vitro and in vivo.[40] The potential for administering therapeutic proteins and peptides as well as drugs for the treatment of localized colon illnesses has made colonic drug delivery increasingly important. For a medication to properly undergo colonic administration, it must be protected against absorption and/or the environment of the upper gastrointestinal tract (GIT). This is followed by a rapid release of the medication into the proximal colon, which is considered to be the optimal site for colon-targeted drug delivery. Colon targeting, of course, is helpful for the topical management of colon diseases like Chron's diseases, ulcerative colitis, amebiasis, and colorectal cancer. Candidates for colon-targeted drug delivery include proteins, oligonucleotides, vaccines, and peptides.[41]

Target Drug Delivery System:

Targeted drug delivery is a method of delivering medication to a patient in a manner that increases the concentration of the medication in some parts of the body relative to others. Targeted drug delivery seeks to concentrate the medication in the tissues of interest while reducing the relative concentration of the medication in the remaining tissues. This improves efficacy of the while reducing side effects.[42] The pharmacological characteristics of a medication determine its biological effects in a patient The interactions between the drug and the receptors at the drug's site of action result in these effects. Until the medicine is delivered to its site of action at a concentration and pace that results in the fewest negative effects and the greatest number of beneficial benefits, the effectiveness of this drug-target interaction has been compromised. Targeted medication delivery is a therapeutic approach in which a therapeutic material is delivered to a particular tissue while avoiding contact with other bodily parts. As a result, it exclusively administers the drug to the body's targeted regions. The drug delivery system's superior technology regulates the pharmacokinetic parameters, drug absorption, and drug bioavailability. Four fundamental principles are needed for drug targeting: (1) the drug must be able to be loaded at the target location; (2) it must not be broken down by bodily fluids; (3) it must reach the target site; and (4) it must be released at the designated place at the scheduled time. Depending on the route to be taken, different drug delivery mechanisms must be used at different body areas of interest. [43]

• The advantages of drug targeting

1. The drug administration regimen gets easier to follow
2. By focusing on a single spot, the drug's toxicity is reduced.
3. A modest dosage can produce the required pharmacological effect.
4. Prevent the effect of first pass.
5. An increase in the medication's absorption from the intended spot.
6. There was no peak or dip in plasma concentration as a result of drug targeting

• The disadvantages of drug targeting

1. Rapid drug elimination from the body results in high dose frequency.
2. The carrier of the targeted drug delivery system may result in the immune response.
3. The drug delivery system is not localized at the tumor tissue for sufficient time.
4. The diffusion and redistribution of released drugs.

Carries applied for drug targeting a. Carriers systems can be used to target drugs.
b. The carriers are the systems needed to deliver entrapped drugs to their intended locations.
c. The drug moiety is entrapped by the carriers, who then transfer it to the target site without letting it escape into the non-target site.[44]

• 6.1 Different types of carriers for drug targeting

• Quantum dots:

Conduction band electrons, valence band holes, or excitons—bound pairs of conduction semiconductor nanostructure. The presence of an interface between distinct semiconductor materials (as in core-shell nanocrystal systems), the presence of the semiconductor surface (as in semiconductor nanocrystals), electrostatic potentials (produced by external electrodes, doping, strain, and impurities), or a combination of these can all be responsible for the confinement.

Because of their theoretically high quantum yield, quantum dots are especially important for optical applications. One of the most intriguing options for use in solid-state quantum computation and diagnosis, drug delivery, tissue engineering, catalysis, filtration, and textile band electrons and valence band holes—can only move in certain three spatial directions within a quantum dot, a Technology is the capacity to alter the size of quantum dots.[45]

• Transdermal Approach:

Transdermal drug delivery system is topically administered medicaments in the form of patches that deliver drugs for systemic effects at a predetermined and controlled rate. A transdermal drug delivery device, which may be of an active or a passive design, is a device which provides an alternative route for administering medication. These devices allow for pharmaceuticals to be delivered across the skin barrier. In theory, transdermal patches work very simply. A drug is applied in a relatively high dosage to the inside of a patch, which is worn on the skin for an extended period of time. Through a diffusion process, the drug enters the bloodstream directly through the skin. Since there is high concentration on the patch. and low concentration in the blood, the drug will keep diffusing into the blood for a long period of time, maintaining the constant concentration of drug in the blood flow.[46]

• Folate Targeting:

Folate targeting is a method utilized in biotechnology for drug delivery purposes. It involves the attachment of the vitamin, folate (folic acid), to a molecule/drug to form a "folate conjugate". Based on the natural high affinity of folate for the folate receptor protein (FR), which is commonly Folate-drug conjugates, which are expressed on the surface of numerous human malignancies, bind firmly to the FR and cause endocytosis to occur, which initiates cellular uptake. It has been successfully accomplished to deliver a wide range of molecules inside FR-positive cells and tissues, from huge DNA plasmid formulations to small radio diagnostic imaging agents.[47]

REFERENCE

1. Tushar Madaan, Shweta Pandey and Sushama Talegaonkar Journal of Chemical and Pharmaceutical Research, 2015, 7(6):257-264
2. KE Drexler. Nanosystems: Molecular Machinery, Manufacturing, and Computation,1 stedition, John Wiley & Sons, New Delhi, 1992; 1-3.
3. Syed A.A. Rizvi, Ayman M. Saleh Applications of nanoparticle systems in drug delivery technology Saudi Pharm J. 2018 Jan; 26(1): 64–70. Published online 2017 Oct 25. doi: 10.1016/j.jsps.2017.10.012
4. V PKinesh; DP Neelam; BP Punit; SB Bhavesh; KS Pragna. International Journal of Pharmaceutical Sciences and Nanotechnology. 2010, 3(3), 1057-1064.
5. MZH Saad; R Jahan; U Bagul, Asian Journal of Biomedical & Pharmaceutical Sciences, 2012, 2(14), 11-20
6. kshirsagar, n.a. drug delivery systems Indian  Journal of Pharmacology 32(4):p 54-61, Jul–Aug 2000.
7. Amato G. Silica-Encapsulated Efficient and Stable Si Quantum Dots with High Biocompatibility.Nanoscale Research Letters [Internet]. Springer Nature; 2010 May 1;5(7):1156–60. Available from: http://dx.doi.org/10.1007/s11671-010-9619-9
8. Gaurav Tiwari, Ruchi Tiwari, Birendra Sriwastawa, L Bhati, S Pandey, P Pandey, and Saurabh K Bannerjee Drug delivery systems: An updated review Int J Pharm Investig. 2012 Jan-Mar; 2(1): 2–11. doi: 10.4103/2230-973X.96920
9. Kumaresh.S Soppimath, Tejraj.M Aminabhavi, Anandrao.R Kulkarni, Walter E Rudzinski Journal of Controlled Release Volume 70, Issues 1–2, 29 January 2001, Pages 1-20 https://doi.org/10.10160/S0168-3659(00)00339-4
10. Afreen Sultana, Mina Zare, Vinoy Thomas ,T.S. Sampath Kumar  Nano-based drug delivery systems: Conventional drug delivery routes Medicine in Drug Discovery Volume 15, September 2022, 100134 https://doi.org/10.1016/j.medidd.2022.100134
11. Singh J, Pandit S, Bramwell VW, Alpar HO. Diphtheria toxoid loaded poly-(?caprolactone) nanoparticles as mucosal vaccine delivery systems. Methods [Internet]. Elsevier BV; 2006 Feb;38(2):96–105. Available from: http://dx.doi.org/10.1016/j.ymeth.2005.11.003
12. L Yu-Te; L Chia-Hung; Y Jilashing; W Kevin. International Journal of  Nanomedicine. 2014, 9(1), 2767-2778
13. Luis A. Prieto-Costas, Génesis R. Rivera-Cordero, José M. Rivera. Quantifying and Modulating Protein Encapsulation in Guanosine-Based Supramolecular Particles. Bioconjugate Chemistry 2023, 34 (11), 2112-2122. https://doi.org/10.1021/acs.bioconjchem.3c00412
14. Xiaozhuo Ba, Tao Ye, Haojie Shang, Yonghua Tong, Qiu Huang, Yu He, Jian Wu, Wen Deng, Zichen Zhong, Xiaoqi Yang, Kangyang Wang, Yabin Xie, Yanlong Zhang, Xiaolin Guo, Kun Tang. Recent Advances in Nanomaterials for the Treatment of Acute Kidney Injury. ACS Applied Materials & Interfaces 2024 , 16  (10) ,12117-12148 https://doi.org/10.1021/acsami.3c19308
15. Samuel A. Smith, Bruna Rossi Herling, Changhe Zhang, Maximilian A. Beach, Serena L. Y. Teo, Elizabeth R. Gillies, Angus P. R. Johnston, Georgina K. Such. Self-Immolative Polymer Nanoparticles with Precise and Controllable pH-Dependent Degradation. Biomacromolecules 2023, 24 (11)4958 4969. https://doi.org/10.1021/acs.biomac.3c00630
16. Zheng Yang, Tiantian Xu, Hui Li, Mengyao She, Jiao Chen, Zhaohui Wang, Shengyong Zhang, Jianli Li. Zero-Dimensional Carbon Nanomaterials for Fluorescent Sensing and Imaging. Chemical,Reviews 2023, 123 (18) 1104711136. https://doi.org/10.1021/acs.chemrev.3c00186
17. Lingping Xie, Yuanfeng Li, Yong Liu, Zhihua Chai, Yuxun Ding, Linqi Shi, Jinhui Wang. Vaginal Drug  Delivery Systems  to  Control Microbe-Associated Infections. ACS Applied Bio Materials 2023, 6 (9) , 3504-3515. https://doi.org/10.1021/acsabm.3c00097
18. Ceri J. Richards, Thomas C. Q. Burgers, Rifka Vlijm, Wouter H. Roos, Christoffer Åberg. Rapid Internalization of Nanoparticles by Human Cells at the Single Particle Level. ACS Nano 2023, 17 (17), 16517-16529. https://doi.org/10.1021/acsnano.3c01124
19. Prabhat Kattel, Shoukath Sulthana, Ji?í Trousil, Dinesh Shrestha, David Pearson, Santosh Aryal. Effect of Nanoparticle Weight on the Cellular Uptake and Drug Delivery Potential of PLGA. Nanoparticles. ACSOmega 2023,8 (30),2714627155. https://doi.org/10.1021/acsomega.3c02273
20. Cai Wang, Jingyi Sun, Qian Chen, Jixiang Chen, Huiyu Wan, Qingbin Ni, Hui Yuan, Jingguo Wu, Ying Wang, Baoliang Sun. Application of Nanotechnology-Based Products in Stroke. ACS Chemical Neuroscience 2023, 14 (13), 2405-2415. https://doi.org/10.1021/acschemneuro.2c00804
21. AZARMI S, TAO X, CHEN H, WANG Z, FINLAY W, LOBENBERG R, et al. Formulation and cytotoxicity of doxorubicin nanoparticles carried by dry powder aerosol particles. International Journal of Pharmaceutics [Internet]. Elsevier BV; 2006 Aug 17;319(1- 2):155–61. Available from: http://dx.doi.org/10.1016/j.ijpharm.2006.03.0 5
22. Allen TM. Ligand-targeted therapeutics in anticancer therapy. Nature Reviews Cancer [Internet]. Springer Nature; 2002 Oct;2(10):750–63. Available from: http://dx.doi.org/10.1038/nrc903
23. Kadriye K?z?lbey. Optimization of Rutin-Loaded PLGA Nanoparticles Synthesized by Single-Emulsion Solvent Evaporation Method. ACS Omega 2019, 4 (1) , 555-562. https://doi.org/10.1021/acsomega.8b02767
24. Carmeliet P, Jain RK. Nature [Internet]. Springer Nature; 2000 Sep 14;407(6801):249– 57. Available from: http://dx.doi.org/10.1038/35025220
25. Czarnobaj K. Preparation and Characterization of Silica Xerogels as Carriers for Drugs. Drug Delivery [Internet]. Informa UK Limited; 2008 Jan;15(8):485–92. Available from: http://dx.doi.org/10.1080/1071754080232149
26. Jing Wang, Wenjun Le, Tinghua Yan, Jinhua Jiang, Bingdi Chen. Usage of Nanoparticles to Alter Neutrophils’ Function for Therapy. ACS Biomaterials Science & Engineering 2022, 8 (9), 3676-3689. https://doi.org/10.1021/acsbiomaterials.2c00711
27. Dayoung Lee, Seungki Baek, Young-Youb Kim, Yongbin Bang, Han Na Jung, Hyung-Jun Im, Yoon-Kyu Song. Self-Assembled DNA–Protein Hybrid Nanospheres: Biocompatible Nano-Drug-Carriers for Targeted Cancer Therapy. ACS Applied Materials & Interfaces 2022, 14 (33) , 37493-37503. https://doi.org/10.1021/acsami.2c10397
28. Megan G. Roberts, Valerie J. Facca, Rachel Keunen, Qing Yu, Raymond M. Reilly, Mitchell A. Winnik. Changing Surface Polyethylene Glycol Architecture Affects Elongated Nanoparticle Penetration into Multicellular Tumor Spheroids. Biomacromolecules 2022, 23 (8), 32963307. https://doi.org/10.1021/acs.biomac.2c00386
29. F lavio F. Contreras-Torres, Daniel Salas-Treviño, Adolfo Soto-Domínguez, Gerardo De Jesús García-Rivas. Carbon Nanotubes in Tumor-Targeted Chemotherapeutic Formulations: A Review of Opportunities and Challenges. ACS Applied Nano Materials 2022, 5 (7), 8649-8679. https://doi.org/10.1021/acsanm.2c01118
30. Maya Holay, Jiarong Zhou, Joon Ho Park, Igor Landa, Christian J. Ventura, Weiwei Gao, Ronnie H. Fang, Liangfang Zhang. Organotropic Targeting of Biomimetic  Nanoparticles to Treat Lung Disease. Bioconjugate Chemistry 2022, 33 (4), 586-593. https://doi.org/10.1021/acs.bioconjchem.1c00599
31. Anuj S. Shah, Bapurao Surnar, Nagesh Kolishetti, Shanta Dhar. Intersection of Inorganic Chemistry and Nanotechnology for the Creation of New Cancer Therapies. Accounts of Materials Research 2022, 3 (3), 283-296. https://doi.org/10.1021/accountsmr.1c00178
32. Raj Kumar Chandrani Sarkar Sudipta Panja Chandra Khatua Kishan Gugulothu Diptesh Sil . Biomimetic Nanocomposites for Biomedical Applications. , 163-196. https://doi.org/10.1021/bk-2022-1410.ch007
33. Tieshuai Zhao, Roberto Terracciano, Jonas Becker, Alessandra Monaco, Gokhan Yilmaz, C. Remzi Becer. Hierarchy of Complex Glycomacromolecules: From Controlled Topologies to Biomedical Applications. Biomacromolecules 2022, 23 (3), 543-575. https://doi.org/10.1021/acs.biomac.1c01294
34. Xiang Li, Xian-Xin Chen, Yu Xu, Xian-Bing Xu, Wen-Fei Wu, Qi Zhao, Jiang-Ning Hu. Construction of Glycogen-Based Nanoparticles Loaded with Resveratrol for the Alleviation of High-Fat Diet-Induced Nonalcoholic Fatty Liver Disease. Biomacromolecules 2022, 23 (1) , 409-423. https://doi.org/10.1021/acs.biomac.1c01360
35. Houjuan Zhu, Xian Jun Loh, Enyi Ye, Zibiao Li. Polymeric Matrix-Based Nanoplatforms toward Tumor Therapy and Diagnosis. ACS Materials Letters 2022, 4 (1), 21-48. https://doi.org/10.1021/acsmaterialslett.1c00558
36. Morteza Mahmoudi, Sepideh Pakpour, George Perry. Drug-Abuse Nanotechnology: Opportunities and Challenges. ACS Chemical Neuroscience 2018, 9 (10), 2288-2298. https://doi.org/10.1021/acschemneuro.8b00127
37. Chung-Jen Chiang, Li-Jen Lin, Chia-Pei Wu, Chih-Jung Chen, Yun-Peng Chao. Development of Nanoscale Oil Bodies for Targeted Treatment of Lung Cancer. Journal of Agricultural and Food Chemistry 2018, 66 (36), 9438-9445. https://doi.org/10.1021/acs.jafc.8b02972
38. Xiaochong Li, Chuan Xie, Hesheng Xia, Zhanhua Wang. pH and Ultrasound Dual-Responsive Polydopamine-Coated Mesoporous Silica Nanoparticles for Controlled Drug Delivery. Langmuir 2018, 34 (34) , 9974-9981. https://doi.org/10.1021/acs.langmuir.8b01091
39. Caina Xu, Yanbing Wang, Haiyang Yu, Huayu Tian, Xuesi Chen. Multifunctional Theranostic Nanoparticles Derived from Fruit-Extracted Anthocyanins with Dynamic Disassembly and Elimination Abilities. ACS Nano 2018, 12 (8), 8255-8265. https://doi.org/10.1021/acsnano.8b03525
40. Moonhyun Choi, Daheui Choi, Jinkee Hong. Multilayered Controlled Drug Release Silk Fibroin Nanofilm by Manipulating Secondary Structure. Biomacromolecules 2018, 19 (7), 3096-3103. https://doi.org/10.1021/acs.biomac.8b00687
41. Damgé C, Maincent P, Ubrich N. Oral delivery of insulin associated to polymeric nanoparticles in diabetic rats. Journal of Controlled Release [Internet]. Elsevier BV; 2007 Feb;117(2):163–70. Available from: http://dx.doi.org/10.1016/j.jconrel.2006.10.0 23 31.
42. Davis ME, Chen Z (Georgia), Shin DM. Nanoparticle therapeutics: an emerging treatment modality for cancer. Nature Reviews Drug Discovery [Internet]. Springer Nature; 2008 Sep;7(9):771–82. Available from: http://dx.doi.org/10.1038/nrd2614 32.
43. Deryugina EI, Quigley JP. Matrix metalloproteinases and tumor metastasis. Cancer and Metastasis Reviews [Internet]. Springer Nature; 2006 Mar;25(1):9–34. Available from: http://dx.doi.org/10.1007/s10555-006-7886-9 33.
44. Di Pasqua AJ, Wallner S, Kerwood DJ, Dabrowiak JC. Adsorption of the PtIIAnticancer Drug Carboplatin by Mesoporous Silica. Chemistry & Biodiversity [Internet]. Wiley-Blackwell; 2009 Sep;6(9):1343–9. Available from: http://dx.doi.org/10.1002/cbdv.200900021 34.
45. Echeverría JC, Estella J, Barbería V, Musgo J, Garrido JJ. Synthesis and characterization of ultramicroporous silica xerogels. Journal of Non-Crystalline Solids [Internet]. Elsevier BV; 2010 Mar;356(6-8):378–82. Available from: http://dx.doi.org/10.1016/j.jnoncrysol.2009.1 1.044 35.
46. Figuerola A, Di Corato R, Manna L, Pellegrino T. From iron oxide nanoparticles towards advanced iron-based inorganic materials designed for biomedical applications. Pharmacological Research [Internet]. Elsevier BV; 2010 Aug;62(2):126–43. Available from: http://dx.doi.org/10.1016/j.phrs.2009.12.012 36.
47. Fidalgo A, Lopez TM, Ilharco LM. Wet sol–gel silica matrices as delivery devices for phenytoin. Journal of Sol-Gel Science and Technology [Internet]. Springer Nature; 2008 Dec 30;49(3):320–8. Available from: http://dx.doi.org/10.1007/s10971-008-1880-3
