Recent Advances in Sustained Release Pellets Using Extrusion-Spheronization Technique: A Comprehensive Review

Abstract

Sustained release drug delivery systems are gaining momentum due to their potential to maintain constant plasma drug concentrations, reduce dosing frequency, and improve patient compliance. Among these systems, pellet-based formulations produced by extrusion-spheronization have demonstrated significant advantages including uniform size distribution, high sphericity, and smooth surface characteristics. This review highlights the principles of extrusion-spheronization, critical formulation parameters, suitable excipients, evaluation methods, and examples of marketed and experimental sustained release pellets. The technique’s ability to process both hydrophilic and hydrophobic drugs makes it highly versatile. The paper further discusses the limitations, regulatory perspectives, and future potential of extrusion-spheronization in advanced drug delivery systems.

Keywords

Sustained release, Pelletization, Extrusion-spheronization, Drug delivery system, Rabeprazole, Controlled release

Introduction

4. Extrusion-Spheronization Technique

Extrusion-spheronization is a widely used technique for preparing multiparticulate drug delivery systems, especially sustained release pellets. It enables the production of dense, spherical pellets with narrow size distribution—essential for uniform coating and drug release.

Key Steps in the Process: ^{8, 9}

1. Mixing/Wet Massing: Drug and excipients are mixed with a binder to form a plastic mass.
2. Extrusion: Wet mass is extruded through a screen to form cylindrical extrudates.
3. Spheronization: Cylindrical extrudates are rounded into spheres using a rotating friction plate.
4. Drying: Pellets are dried to remove moisture.
5. Coating (Optional): Coating applied for SR or enteric protection.

Process Flow:

Raw Materials → Wet Massing → Extrusion → Spheronization → Drying → Coating (optional) → Final Pellets

5. Formulation Variables and Excipients ^{10, 11}

Excipient	Roles	Examples
Diluent	Improves binding and plasticity	Microcrystalline cellulose (MCC)
Binder	Forms plastic mass	PVP K30, HPMC
Pore-former	Alters drug release	Lactose, Mannitol
Release retardant	Sustained release matrix	Ethyl cellulose, HPMC K100M
Plasticizer	Improves coating flexibility	Diethyl phthalate (DEP)
Solvent	Used in granulation or coating	Water, Methylene dichloride

Case Study: Rabeprazole SR Pellets ¹²

Rabeprazole sodium is an acid-labile proton pump inhibitor. SR pellets are produced by layering the core drug onto MCC-based pellets, followed by enteric and sustained release coatings. Coating polymers include Eudragit L100 and ethyl cellulose.

6. Evaluation Parameters of Pellets ¹⁴

1. Particle Size Distribution: Sieve or laser diffraction analysis
2. Sphericity and Surface Morphology: SEM, image analysis
3. Flow Properties: Angle of repose, bulk/tapped density, Carr’s Index
4. Moisture Content: LOD or Karl Fischer titration
5. Drug Content Uniformity: UV or HPLC
6. In Vitro Release Studies: USP apparatus I/II, pH 1.2 and 6.8 media

7. Marketed Formulations and Examples

Drug	Brand Examples	Coating Type
Rabeprazole	Rabicip L, Rabium SR	Enteric + SR
Diclofenac Sodium	Diclo SR	SR coating
Omeprazole	Omez, Ocid	Enteric + SR
Theophylline	Theolair SR	Matrix or layered SR

8. Challenges and Limitations ¹⁵

• Moisture sensitivity during wet massing
• Optimization complexity (speed, binder, screen size)
• Equipment cost for small scale
• Scale-up reproducibility

9. Recent Trends and future scope in Pelletization Technology ^{16, 17}

0. 1. Recent Trends
1. Use of Natural and Biodegradable Polymers

These materials offer biocompatibility and reduce long-term toxicity. Natural gums (e.g., xanthan, guar, gellan gum), chitosan, and alginates are beinused as matrix formers for eco-friendly sustained release.

2. Co-processed Excipients

MCC-lactose, MCC-dicalcium phosphate combinations enhance pellet strength, flow, and sphericity. Reduce the need for binders or plasticizers.

3. Hot-Melt Extrusion (HME)

A solvent-free, continuous process gaining popularity for heat-stable drugs.

Allows fine control over drug dispersion and release kinetics.

4. Multi-layered and Multiparticulate Systems

Pellets with dual or triple layers (e.g., immediate + sustained + enteric) to treat complex diseases like GERD or chronic infections.

5. Incorporation of Nanoparticles into Pellets

Nanoparticles embedded into pellets for targeted delivery or enhanced solubility of poorly water-soluble drugs.

6.  3D Printing in Pellet Manufacturing

Though in early research, extrusion-based 3D printing can produce customized,    layered, and programmable-release pellets.

7. Design of Experiments (DoE) and QbD

DoE and Quality by Design (QbD) principles help optimize process variables (speed,           binder ratio, drying time) to improve reproducibility and quality control.

9.2 Future Scope in Pelletization Technology ^{18, 19}

1. Personalized Medicine:

Pelletization allows customization of doses and combinations — ideal for age-specific or patient-specific treatments.

2. Pediatric and Geriatric Formulations:

Small, tasteless pellets in sprinkle capsules or suspensions can improve compliance in children and elderly.

3. Colon-targeted Delivery:

pH-sensitive coatings and time-dependent systems for diseases like IBD and colorectal cancer.

4. Artificial Intelligence (AI) in Formulation Design:

Machine learning models will predict optimal excipient combinations, release profiles, and stability parameters.

5. Sustainability and Green Pharmacy:

Use of solvent-free, low-energy, and biodegradable systems will align with environmental goals and regulatory pressure.

6. Regulatory Harmonization:

Future guidelines (USFDA, EMA, CDSCO) may support pellet-based drug delivery as a preferred system due to its modular, safe, and reproducible nature.

CONCLUSION

Extrusion-spheronization is a scalable and reliable technique to produce sustained release pellets with consistent quality. With advancements in polymers, excipients, and coating methods, the technique continues to be widely used for oral drug delivery. Its role in developing combination, pediatric, and targeted therapies is expanding, aligning with current trends in personalized medicine.

REFERENCES

1. Jadhav NR, Pawar AY. Pelletization techniques for oral drug delivery. Am J PharmTech Res. 2013;3(2):2249-3387.
2. Ghebre-Sellassie I. Pellets: A General Overview. In: Pharmaceutical Pelletization Technology. CRC Press; 1989.
3. Kumar A, Garg S. Pellets: a general overview. Int J PharmTech Res. 2010;2(2):1339-1345.
4. Bhalekar MR, Avari JG, Pokharkar VB. Formulation and evaluation of sustained release pellets of a poorly soluble drug using extrusion spheronization technique. AAPS PharmSciTech. 2009;10(3):951–957.
5. Singh R, Singh M, Arora V. Controlled release multiparticulate drug delivery system. Pharm Glob. 2010;1(1):1-6.
6. Sharma V, Pathak K. Formulation and evaluation of sustained release mucoadhesive pellets of Ketorolac Tromethamine. Acta Pharm. 2009;59(2):229–241.
7. Sinha VR, Kumar RV, Bhinge JR. A review on sustained release technology. Pharmainfo.net. 2017.
8. Kaur R, Arora S. Recent advances in pellet formulation using extrusion–spheronization. Int J Drug Dev Res. 2020;12(1):123–130.
9. Pandey A, Khale A. Formulation and evaluation of enteric coated Rabeprazole pellets. Int J Pharm Sci Rev Res. 2014;27(2):66-71.
10. Jain N, Ahuja N. Recent trends in pelletization techniques: A review. Int J Drug Dev Res. 2021;13(2):80-89.
11. Patil C, Sutar M. Application of extrusion-spheronization in pharmaceuticals: An overview. Int J Res Pharm Chem. 2015;5(4):714-719.
12. Anantwar SP, Jaiswal SB. Multiparticulate drug delivery system. Int J Pharm Life Sci. 2011;2(10):1230-1236.
13. Mehta T, Upadhyay UM. An overview on sustained release drug delivery system. Asian J Pharm Res Dev. 2022;10(3):109-117.
14. Deshmukh A, Khadka D. Advanced multiparticulate oral drug delivery systems. J Drug DelivTher. 2020;10(6):129-134.
15. Dalwadi C, Patel P. Formulation and evaluation of sustained release pellets of Tramadol Hydrochloride. J Pharm SciBiosci Res. 2022;12(2):172-180.
16. Kaur R et al. Int J Drug Dev Res. 2020;12(1):123–130.
17. Mehta T et al. Asian J Pharm Res Dev. 2022;10(3):109–117.
18. Dalwadi C et al. J Pharm Sci Biosci Res. 2022;12(2):172–180.
19. FDA QbD Guidelines: [www.fda.gov](https://www.fda.gov)
