Glow From Waste: The Herbal Brightening Mask Infused with Pectin from Orange Waste

The cosmetic industry is increasingly focusing on sustainability and the use of natural, eco-friendly ingredients. Citrus fruit peels, a major agro industrial by-product, are often discarded, causing environmental issues despite being rich in valuable compounds such as Pectin. Pectin is a natural polysaccharide known for its gelling and stabilizing properties. It is biodegradable, biocompatible, and safe for cosmetic applications, offering a sustainable alternative to synthetic thickeners.

This study, “Glow from Waste: The Herbal Brightening Mask Infused with Pectin from Orange Waste,” aims to extract Pectin from discarded orange peels and use it as a natural thickener in a herbal face mask. The extracted Pectin, combined with beetroot extract, tomato extract, rose water, and vitamin E, forms a brightening and moisturizing mask. The project demonstrates a simple, cost-effective, and eco-friendly approach that converts fruit waste into a value-added product, supporting green innovation and sustainable cosmetic development. Despite the booming cosmetic industry, most commercial face masks rely on synthetic thickeners, chemical stabilizers, and non-biodegradable sheet materials that eventually contribute to environmental pollution and skin-related side effects. At the same time, tons of citrus fruit peels especially orange peels are discarded every day, becoming a major component of biodegradable waste. These peels are rich in valuable biopolymers like pectin, yet they remain highly underutilized.

Figure : Collection of Orange peels

2. COLLECTION OF RAW MATERIALS

Fresh orange peels were collected from local fruit vendors and nearby households to utilize fruit waste as a potential source of valuable biomolecules. Orange peel is known to be rich in pectin, a natural polysaccharide widely used as a gelling and thickening agent in the food and pharmaceutical industries. The collected peels were thoroughly washed with clean water to remove dirt, dust, and other surface impurities before processing. Approximately 45 grams of fresh orange peels were taken for the experiment and carefully divided into two equal portions. This was done to study how different drying conditions could influence the yield and quality of pectin extraction. Drying is an important step in pectin extraction because it removes moisture from the peel, prevents microbial growth, and helps preserve the bioactive compounds present in the material.

The first portion of orange peels was subjected to shade drying. In this method, the peels were spread evenly on clean trays and kept at room temperature under shade for about 4–5 days. Shade drying is a natural and cost-effective method that helps retain some heat-sensitive compounds because it avoids direct exposure to sunlight and high temperatures. The second portion of the orange peels was dried using a hot air oven at a controlled temperature of 60°C for about 3 - 4 hours. Oven drying is a faster and more controlled drying technique compared to natural drying. The purpose of using this method was to determine whether controlled heat treatment could improve the efficiency of drying and potentially influence the pectin yield obtained from the peels.

This dual drying approach (shade drying and oven drying) was intentionally used to compare how different drying conditions affect the extraction efficiency, yield, and quality of pectin. Such comparisons help in identifying the most suitable drying method for efficient pectin production from citrus waste.

Figure : dried orange peels

After the drying process was completed, the dried orange peels were weighed again to observe the reduction in moisture content. The dried samples were then ground using a grinder to obtain a fine powder, which increases the surface area and facilitates better extraction of pectin during further processing. Finally, the powdered orange peel samples were stored in airtight containers to protect them from moisture, contamination, and environmental exposure until they were used for the subsequent pectin extraction experiments.

2.1 EXTRACTION OF PECTIN

The acid extraction method was used to extract pectin from dried orange peel powder. First, an acidic solution was prepared by adjusting distilled water to pH 2 using hydrochloric acid (HCl). Approximately 1.5 grams of orange peel powder was then weighed and placed in a beaker. The powder was mixed with 20 mL of the prepared acidic solution and heated at 60°C on a magnetic stirrer with continuous stirring to facilitate extraction. After the extraction process, the mixture was filtered using filter paper or muslin cloth to separate the liquid extract. The obtained filtrate was then mixed with 99% ethanol in a 1:2 ratio to precipitate the pectin. Finally, the precipitated pectin was collected and dried in an oven at 50°C for several hours, powdered, and stored for further formulation.

2.2 CONFIRMATORY TEST FOR PECTIN

2.2.1 Confirmatory Test for Pectin

To confirm that pectin was successfully extracted from orange peels, a few simple qualitative tests were carried out. These tests help in identifying the presence of pectin based on its natural properties. One of the most common methods used is the alcohol precipitation test. In this test, a small amount of the extracted solution is mixed with ethanol. If pectin is present, a jelly-like or fibrous precipitate forms immediately because pectin does not dissolve in alcohol. The formation of this precipitate indicates that pectin has been successfully extracted from the orange peel.

Another characteristic property of pectin is its ability to form a gel. When the extracted pectin solution is mixed with sugar and a small amount of acid under suitable conditions, it forms a thick, gel-like consistency. This gel formation is a typical feature of pectin and further confirms its presence in the extracted sample.

These simple tests provide an easy and effective way to verify that the extraction process has worked properly. Confirming the presence of pectin is an important step before using it for further applications such as preparing hydrogels or cosmetic formulations like facial masks.

2.3 ATTRIBUTES OF THE PROJECT

The extracted pectin was further subjected to a series of qualitative tests to confirm its presence and evaluate its functional properties. In the alcohol (ethanol) precipitation test, which is based on the principle that pectin is soluble in water but insoluble in alcohol, approximately 5 mL of the aqueous pectin extract was taken in a test tube and mixed with 10 mL of 99% ethanol in a 1:2 ratio. Upon gentle mixing, a white, jelly-like or gelatinous precipitate appeared immediately. This rapid formation of a coagulated mass indicated the precipitation of pectin from the solution, thereby confirming its presence. The intensity and volume of the precipitate also suggested a good yield of pectin extracted from the orange peel powder.

In the gel formation test, the ability of pectin to form a gel in the presence of sugar and mild acid was evaluated. About 5 mL of the pectin solution was taken and mixed with approximately 2 g of sugar, followed by the addition of 2–3 drops of dilute acid to maintain a pH around 3–3.5. The mixture was gently heated to dissolve the sugar completely and then allowed to cool at room temperature (around 25°C). Upon cooling, a firm, uniform, and stable gel was formed. This observation confirmed the gel-forming ability of the extracted pectin, indicating that it possesses good quality and is suitable for applications such as food products and cosmetic formulations where gelling properties are essential.

In the viscosity test, the thickening property of pectin was assessed based on its ability to increase the viscosity of solutions. Approximately 5 mL of the pectin solution was observed for its flow characteristics by gently tilting the test tube. The solution exhibited a thick, smooth, and slightly sticky consistency, with a noticeable resistance to flow compared to plain water. This increase in viscosity confirmed that the extracted pectin functions effectively as a natural thickening and stabilizing agent. Such properties make it highly useful in industries like food processing, pharmaceuticals, and cosmetics, where viscosity enhancement is required.

2.3.1. Physical Characterization of Extracted Pectin

The extracted pectin appeared as an off-white pale cream powder, indicating effective removal of pigments and impurities. Its dry, brittle nature confirmed successful ethanol precipitation and dehydration. Upon hydration, the pectin exhibited rapid swelling and gel formation, a key requirement for cosmetic hydrogel applications.

2.3.2. Gelling and Viscosity Behavior

When dissolved in warm distilled water (0.5 -1%), the pectin demonstrated strong viscosity enhancement and gel consistency upon cooling. This confirmed its functional suitability as a natural gelling agent, comparable to commercial cosmetic thickeners.

2.3.3. Film-Forming Ability

The prepared pectin-herbal gel formed a uniform, flexible hydrogel sheet when cast into molds. The mask showed good mechanical integrity and facial adaptability without tearing an essential property for molded facial masks.

2.3.4. Herbal Compatibility and Stability

Incorporation of beetroot, tomato extract, rose derivatives, and vitamin E did not disrupt gel stability. Instead, these bio actives enhanced the color, antioxidant potential, and aesthetic appeal of the formulation, demonstrating excellent compatibility with the pectin matrix.

2.3.5. Biodegradability and Safety Perspective

As a plant-derived polysaccharide, pectin is biocompatible, non-toxic, and biodegradable, making it highly suitable for topical cosmetic applications and environmentally responsible product development.

3. RESULTS

3.1 Yield and Extraction Efficiency

The extraction of pectin from dried orange peel powder was successfully achieved using an acid extraction method followed by ethanol precipitation. From approximately 1.5 g of dried peel powder, a yield of 0.3–0.45 g of pectin was obtained, corresponding to a 20–30% extraction efficiency. The maintenance of acidic pH (~2) using hydrochloric acid played a critical role in facilitating the release of protopectin into soluble pectin. Upon addition of ethanol in a 1:2 ratio, immediate formation of a white, gelatinous precipitate confirmed successful extraction. The final dried product appeared as a fine, pale cream to light yellow powder, indicating minimal contamination and suitability for formulation.

3.2 Effect of Drying Method on Pectin Quality

A comparative analysis of drying methods revealed that shade drying preserved the structural and functional integrity of pectin more effectively than hot-air oven drying. Shade-dried samples yielded higher amounts (0.4–0.45 g) and exhibited superior gel strength and consistency. In contrast, oven-dried samples produced lower yields (0.3–0.35 g) and showed slight degradation, likely due to thermal breakdown of pectic substances. This indicates that controlled, low-temperature drying methods are preferable for maintaining pectin quality.

3.3 Physical Characterization of Extracted Pectin

The extracted pectin was observed as an off-white to pale cream powder with a dry and brittle texture, confirming successful dehydration. The absence of dark coloration suggested effective removal of pigments and impurities during processing. Upon hydration, the pectin demonstrated rapid swelling and hydration capacity, forming a gel-like structure. This property is essential for applications in hydrogel-based cosmetic products.

3.4 Gelling and Viscosity Behavior

When dissolved in warm distilled water at concentrations of 0.5–1%, the extracted pectin significantly enhanced viscosity. Upon cooling, it formed a stable gel with good consistency. The observed pH of the pectin solution ranged between 3–3.5, which is optimal for gel formation. These results confirm that the extracted pectin possesses strong gelling ability and functions effectively as a natural thickening agent, comparable to commercially available gelling agents.

3.5 Film-Forming Ability

The formulated pectin-based herbal gel demonstrated excellent film-forming properties. When cast into molds and allowed to set, it formed a uniform, flexible hydrogel sheet. The resulting film showed good mechanical strength, elasticity, and integrity, allowing it to adapt to facial contours without cracking or tearing. This confirms its suitability for use in peel-off or sheet-type facial masks.

3.6 Herbal Compatibility and Formulation Stability

The incorporation of natural additives such as beetroot extract (2 mL), tomato extract (2 mL), rose water (5 mL), and vitamin E (2–3 drops) resulted in a smooth, homogeneous gel without phase separation. These bioactive ingredients enhanced the color, texture, and antioxidant properties of the formulation without compromising gel stability. The final gel remained stable at room temperature (25–28°C) and maintained consistency over time, indicating strong compatibility between pectin and herbal components.

3.7 pH and Skin Compatibility

The pH of the final gel formulation was found to be in the range of 5–5.5, which is close to the natural pH of human skin. This suggests that the formulation is non-irritating and suitable for topical cosmetic applications. The slightly acidic nature also supports skin barrier function and product stability.

3.8 Biodegradability and Safety Assessment

The extracted pectin, being a plant-derived polysaccharide, demonstrated excellent biocompatibility, non-toxicity, and biodegradability. These properties make it a safe ingredient for cosmetic use and environmentally sustainable. The absence of synthetic chemicals further enhances its appeal for use in natural and eco-friendly product development.

Figure : Extraction of pectin

Figure: Sustainability comparison: natural pectin vs synthetic pectin

              Figure: powdered form of peels         Figure : Final facemask formation
