Evaluation of Analytical Techniques for Curcumin Quantification: A Comprehensive Review

Jansi Patel, Chalsi Patel, Mikita Purohit, Dip Patel, Romit Limbachiya, Dr. Khushbu Patel,

doi:10.5281/zenodo.15039876

Review Paper | Open Access
Volume 03 | Issue 03 | Article Id IJPS/250303104

Evaluation of Analytical Techniques for Curcumin Quantification: A Comprehensive Review
Jansi Patel* Chalsi Patel Mikita Purohit Dip Patel Romit Limbachiya Dr. Khushbu Patel
Department of Pharmaceutical Chemistry and Quality Assurance, Shri Sarvajanik Pharmacy College, Mehsana.

Abstract

Turmeric (Curcuma longa) a golden-yellow spice widely used in both culinary and medicinal practices, contains curcumin as its primary bioactive compound, known for its potent anti- inflammatory, anti-oxidant and anti-cancer properties. It has been utilized for centuries in traditional medicine, particularly in Ayurveda. However, curcumin’s poor bioavailability poses challenges, prompting the use of enhancers like pipeline and innovative pharmaceutical formulations to improve its absorption. Analytical techniques such as UV-Visible Spectroscopy, HPTLC and HPLC are employed for the precise quantification of curcumin in pharmaceutical products, ensuring accurate dosing. These methods play a vital role in its routine application in both traditional and modern medicinal systems.

Keywords

Curcumin, Turmeric, Anti-inflammatory, HPLC, UV- Visible Spectroscopy, Bioavailability, Ayurvedic medicine.

Introduction

Turmeric, derived from the rhizomes of Curcuma longa (family Zingiberaceae), is an essential part of Indian culture, often called the “kitchen queen.” ^[1-2] India, known as the “land of species”, produces about 78% of the word’s turmeric, growing it extensively in states like Tamil Nadu, Maharashtra and Bengal. ^[3-4] Turmeric, along with spices like ginger, fenugreek, cinnamon is not only key culinary ingredient but also has numerous health benefits. ^[5] It is known for its anti- inflammatory properties, blood-purifying abilities and cultural significance in Ayurveda. The name turmeric comes from the French word Terre-merite, meaning “merit of the earth.” ^[6] Historically referred to as the “earthy herb of the sun” during the Vedic period, turmeric is rich in bioactive compounds such as curcumin, which helps regulate inflammation and control cellular oxidation. ^[7] Widely cultivated in Asia, including China, Bangladesh and Southeast Asia, turmeric plays a key role as a spice, preservative and coloring agent. ^[1,8] In turmeric the rhizome part is used. Turmeric is perennial, erect and leafy plant with very large, lily-like leaves up to 1.2 m long. It has oblong, pointed leaves and funnel-shaped yellow flowers.^[9] In Hindu rituals, turmeric is still used as a natural dye for holy robes.^[10]

Fig.1: Curcuma longa Linn

Introduction Of Curcumin

Curcumin, also known as diferuloylmethane, is a key polyphenol from Curcuma longa. It is insoluble in water but soluble in organic solvents. Curcumin, with the IUPAC name 1,7-bis(4- hydroxy-3-methoxyphenyl)-1,6-heptadiene-3,5-dione, provides turmeric’s color and contains volatile oils, sugars, and proteins. Curcumin exists in two forms enolic in solvents and keto in water. Historically, turmeric has been used medicinally in India for over 4000 years. Curcumin offers health benefit like reducing inflammation, managing metabolic syndrome and supporting eye and kidney health, mainly due to its antioxidants and anti-inflammatory properties. However, curcumin’s bioavailability is low due to poor absorption and rapid metabolism. ^[11-12] Curcumin is a yellow-orange polyphenol (C21H20O6) with a molecular weight of 368.39 g/mol. It is insoluble in water but soluble in alcohol and glacial acetic acid, with a log P of 3.0, pKa of 8.5-10.7, and a melting point of 183 ºc. ^[13-15] There are many pharmacological effects of Curcumin like anti-inflammatory, antioxidant and antimicrobial. It is used to manage conditions like cancer, diabetes, cardiovascular diseases and arthritis. Additionally, curcumin supports liver protection, immune modulation, and helps with obesity and premenstrual symptoms. ^[16]

Mechanism of action

Curcumin scavenges reactive oxygen species and inhibit lipid peroxidation and DNA damage. It modulates signaling pathways involved in inflammation, cancer, and cellular growth, inhibiting protein kinases, prostaglandin biosynthesis, and COX-2 activity. ^[13-15]

Fig. 2: Chemical structure of Curcumin

Review Of Literature

Table 1: Official Reported Method for Curcumin

Sr.

No.

Official in

Method

Description

Reference

No.

Indian Pharmacopoeia 2022

High Performance Liquid Chromatography (HPLC)

Mobile phase: Water: Acetonitrile (85:15 %v/v) Stationary phase: Octadecylsilane column (250 × 4.6 mm, 5 ?m)

Wavelength: 240 nm

Flow rate: 1mL/min

U.S

Pharmacopoeia 2013

High Performance Thin Layer Chromatography (HPTLC)

Mobile phase: Chloroform: Methanol: Formic acid (96:4:1

%v/v/v)

Stationary phase: Silica gel (0.25 mm layer) on TLC plates

Wavelength: 365 nm

Table 2: Literature review on UV Spectroscopy Method.

Sr. No.	Title	Description	Reference No.
1	UV-Visible Spectrophotometric estimation of Curcumin in nanoformulation	Wavelength: 421 nm Solvent: Methanol Linearity: 5-25 µg/mL R2: 0.9997	19
2	Development and validation of UV Spectrophotometric method for the estimation of Curcumin in bulk drug and pharmaceutical dosage form	Wavelength: 421 nm Solvent: Methanol Linearity: 1-7 µg/mL R2: 0.9995	20
3	Development and validation of UV Spectrophotometric method for the estimation of Curcumin in cream formulation	Wavelength: 422 nm Solvent: Methanol Linearity: 1-7 µg/mL R2: 0.999	21
4	Qualitative analysis of Curcumin in marketed dosage form by using UV Spectroscopy	Wavelength: 421 nm Solvent: Methanol Linearity: 1-7 µg/mL R2: 0.9357	22
5	Development and validation of UV-Visible Spectrophotometric method for the estimation of Curcumin in bulk and pharmaceutical formulation	Wavelength: 429 nm Solvent: Phosphate buffer and ethanol (1:1) Linearity: 2-10 µg/mL	23

Table 3: Literature review on HPLC Method.

Sr. No.	Title	Description	Reference No.
1	Estimation of Curcumin in different turmeric samples using High Performance Liquid Chromatography (HPLC)	Mobile phase: Methanol: Water (75:25 %v/v) Stationary phase: Zodiac C18 column (100 × 4.6 mm, 5 μm) Wavelength: 225 nm Flow rate: 1.2 mL/min	26
2	Simple HPLC method for resolution of curcuminoids with antioxidant potential	Mobile phase: 2- Propanol: Water (95:5 %v/v) Stationary phase: Exil-amino column (150 × 4.6 mm, 5 μm) Wavelength: 425 nm Flow rate: 1 mL/min	27
3	Greener stability-indicating HPLC approach for the determination of Curcumin in-House developed nanoemulsion and Curcuma longa L. extract	Mobile phase: Ethanol: Ethyl acetate (83:17 %v/v) Stationary phase: Nucleodur C18 column (150 × 4.6 mm, 5 μm) Wavelength: 425 nm Flow rate: 1 mL/min	28
4	Analytical Method and Validation for Simultaneous Estimation of Curcumin and Cyclosporine by RP- HPLC	Mobile phase: Acetonitrile: Water: Methanol (50:10:40 %v/v/v) Stationary phase: Eclipse C18 column (4.6 × 150 mm, 5 μm) Wavelength: 214 nm Flow rate: 0.5 mL/min	29
5	A New Stability-Indicating RP-HPLC Method for Determination of Curcumin: An Application to Nanoparticulate Formulation	Mobile phase: Phosphate buffer (pH 3): Acetonitrile (50:50 %v/v) Stationary phase: C18 column (250 × 4.6 mm, 5 μm) Wavelength: 422 nm Flow rate: 1 mL/min	30
6	Bioanalytical RP-HPLC method development and validation for estimation of Curcumin in plasma samples	Mobile phase: Acetonitrile: Water with 0.1% formic acid (40:60 %v/v) Stationary phase: Qualisil BDS C18 column (250 × 4.6 mm, 5 µm) Wavelength: 423 nm Flow rate: 0.3 mL/min	31
7	A Simple isocratic HPLC method for the simultaneous determination of Curcuminoids in commercial turmeric extracts	Mobile phase: Acetonitrile: 2% v/v acetic acid (40:60 %v/v) Stationary phase: Alltima C18 column (150 × 4.6 mm, 5 μm) Wavelength: 425 nm Flow rate: 2 mL/min	32

Table 4: Literature review on HPTLC Method.

	Title	Description			Reference No.
1	Validated HPTLC analysis method for quantification of variability in content of Curcumin in Curcuma longa L (turmeric) collected from different geographical region of India	Mobile phase: Toluene: Chloroform: Methanol (50:40:10 %v/v/v) Stationary phase: TLC aluminium plates precoated with silica gel 60F254 Wavelength: 430 nm			33
2	Improved HPTLC method for determination of Curcuminoids from Curcuma longa	Mobile phase: Chloroform: Methanol (98:2 %v/v) Stationary phase: Precoated HPTLC aluminium plates silica gel 60F254 Wavelength: 366 nm			34
3	HPTLC method for the quantitative determination of ar-Turmerone and Tumerone in lipid soluble fraction from Curcuma longa	Mobile phase: N-Hexane: Ethyl acetate (98:2 %v/v) Stationary phase: TLC aluminium plates precoated with silica gel 60F254 Wavelength: 254 nm		35
4	Stability-indicating HPTLC determination of Curcumin in bulk drug and pharmaceutical formulations	Mobile phase: Chloroform: Methanol (92.5:7.5 %v/v) Stationary phase: TLC Aluminium plates precoated with silica gel 60F254 Wavelength: 430 nm		36
5	Qualitative analysis and quantitative determination of “Curcumin” in a siddha herbo- mineral formulation using High Performance Thin Layer Chromatography (HPTLC)	Mobile phase: Chloroform: Methanol (9.5:0.5 %v/v) Stationary phase: Silica gel 60F254 coated on aluminium plate Wavelength: 366 nm		37
6	Development of HPTLC method for its validation for the estimation of Curcuminoids	Mobile Chloroform:	phase: Methanol:	38

CONCLUSION

This review highlights the significant medicinal value of turmeric, particularly its active component curcumin, known for its anti-inflammatory, antioxidant and anticancer properties. The development and validation of UV-Visible Spectrophotometry, RP-HPLC and HPTLC methods for curcumin were found to be eco-friendly, simple, reliable and cost effective. These methods were rigorously evaluated for accuracy, precision, linearity and robustness, adhering to ICH guidelines. The study presents a comprehensive approach for the routine analysis of curcumin in bulk and pharmaceutical formulations, ensuring quality control in both Ayurvedic and modern medicinal applications. This work provides a strong foundation for further research in enhancing the bioavailability of curcumin and its potential in treating various health conditions.

REFRENCES

1. 1. 1. Preeti Rathaur, Waseem Raja, P.W. Ramteke and Suchit A. John, “Turmeric: The Golden Spice of Life.” Int. J. Pharm. Sci. Res. 2012, 3(7), 1987.
    2. Jaggi Lal, “Turmeric, Curcumin and Our Life.” Bull. Environ. Pharmacol. Life Sci. 2012, 1(7), 11.
    3. YS Dhruw, HK Awasthi and Govind Prasas, “Psychological Attributes of Turmeric Growers About Turmeric Production Technology.” J. Pharmacogn. Phytochem. 2018, 7(4), 863.
    4. Ashok Sheth, Vasundhara Ni Vanaspati; 4th Edn; Navbharat Sahitya Mandir, Ahmedabad, 2002, pp 275.
    5. Roshni Chaudhari, Varsha Dhole, Sadhana More, Saraswati Kushwaha and Dr. Smita Takarkhede, “Health Benefits of Herbs and Spices.” World J. Pharm. Res. 2021, 10(3), 1050.
    6. Thejaswini. S, Dr. Neetha Pattan, “Composition and Health Benefits of Turmeric (Curcuma longa).” Int. J. Res. Appl. Sci. Eng. Tech. 2022, 10(2), 658.
    7. Reshma H Mirjanaik, Dr. YC Vishwanath, “Advances in Production Technology of Turmeric.” J. Pharmacogn. Phytochem. 2020, 9(4), 1198.
    8. Abhishek Niranjan, Dhan Prakash, “Chemical Constituents and Biological Activities of Turmeric (Curcuma longa Linn).” J. Food Sci. Technol. 2008, 45(2), 109.
    9. Roshan Prasad Yadav, Gaur Tarun, “Versatility of Turmeric: A Review of the Golden Spice of Life.” J. Pharmacogn. Phytochem. 2017, 6(1), 41.
    10. Debjit Bhowmik, Chiranjib, K. P. Sampath Kumar, Margret Chandira, B. Jayakar, “Turmeric: A Herbal and Traditional Medicine.” Scholars Res. Library. 2009, 1(20), 91.
    11. Surbhi Rathore, Mohammad Mukim, Pratishtha Sharma, Siwani Devi, Jagdish Chandra Nagar, Mohammad Khalid, “Curcumin: A review for Health Benefits.” Int. J. Res. Rev. 2020, 7(1), 273.
    12. Alok Vyas, Prasad Dandawate, Subhash Padhye, Aamir Ahmad, Fazlul Sarkar, “Perspectives on new synthetic curcumin analogs and their potential anticancer properties.” Current Pharm. Des. 2013, 19, 2047.
    13. Wikipedia, the free encyclopedia “curcumin”, September 2024, https://en.wikipedia.org/wiki/Curcumin
    14. Pubchem (969516), “curcumin”, September 2024,https://pubchem.ncbi.nlm.nih.gov/compound/curcumin
    15. Drugbank (DB11672), “curcumin”, September 2024, https://go.drugbank.com/drug/DB11672
    16. Layal Slika, Digambara Patra, “Traditional Uses, Therapeutic Effects and Recent Advances of Curcumin: A Mini-Review.” Med. Chem. 2020, 20(12).
    17. Government of India, Ministry of Health and Family Welfare, Indian Pharmacopoeia; 9th Edn; The Indian pharmacopoeia commission, Ghaziabad, 2022, Vol 3, pp 4143-4145.
    18. United States Pharmacopeial Convention, The United States Pharmacopeia; 36th Edn; United States Pharmacopeial Convention, Rockville, MD, 2013, Vol 1, pp 1611-1612.
    19. Kalyan Hazra, Ravi Kumar, Biresh Kumar Sarkar, Y. Ankamma Chowdary, Manish Devgan, Maddi Ramaiah, “UV-Visible Spectrophotometric estimation of Curcumin in nanoformulation.” Int. J. Pharmacogn. 2015, 2(3), 127.
    20. Kiran Sharma, S. S. Agarwal, Monica Gupta, “Development and validation of UV Spectrophotometric method for the estimation of Curcumin in bulk drug and pharmaceutical dosage forms.” Int. J. Drug Dev. & Res. 2012, 4(2), 375.
    21. Prasad Vijay Kadam, Chandrashekhar Laxman Bhingare, Rohini Yuvraj Nikam, Suchita Anil Pawar, “Development and validation of UV Spectrophotometric method for the estimation of Curcumin in cream formulation.” Pharm. Methods. 2013, 4, 43.
    22. Bhagyashri Suryawanshi, Dr. J. Y. Nehete, “qualitative analysis of Curcumin in marketed dosage form by using UV Spectroscopy.” Int. J. Pharm. Res. & Appl. 2021, 6(3), 846-848.
    23. Kollol Kumar, Majumder, Jai Bharti Sharma, Manish Kumar, Shailendra Bhatt, Vipin Saini, “Development and validation of UV-Visible Spectrophotometric method for the estimation of Curcumin in bulk and pharmaceutical formulation.” Pharmacophore. 2020, 11(1), 115.
    24. Kamini Sharma, Pankaj Popli, Sahil Vij, Shubham Sharma, Abhishrk Mangla, Amit Yadav, Anchal Dhawan, A. Pandurangan, Manish Kumar, “Development and validation of UV- Visible Spectrophotometric method for qualifying Curcumin in simulated tear fluid.” A J. New Zealand Herpetology. 2023, 12(2), 1296.
    25. Ashwinder Singh, Vasudeva Rao Avupati, “Development and validation of UV Spectrophotometric method for the estimation of Curcumin in standardized polyherbal formulations.” J. Young Pharm. 2017, 9(4), 493.
    26. K. Suneetha, M. Lalitha, P. Anusha, “Estimation of Curcumin in different turmeric samples using High Performance Liquid Chromatography (HPLC).” Int. J. Creat. Res. Thoughts. 2022, 10(7), 840.
    27. M. Madhava Naidu, B.N. Shyamala, J.R. Manjunatha, G. Sulochanamma, P. Srinivas, “Simple HPLC method for resolution of Curcuminoids with antioxidant potential.” J. Food Sci. 2009, 74(4), C313.
    28. Nazrul Haq, Faiyaz Shakeel, Mohammed M. Ghoneim, Syed Mohammed Basheeruddin Asdaq, Prawez Alam, Saleh A. Alanazi, Sultan Alshehri, “Greener stability-indicating HPLC approach for the determination of Curcumin in in-house developed nanoemulsion and Curcuma longa L. extract.” Separations. 2023, 10, 98.
    29. Neha Desai, Munira Momin, Upasana Singh, Tabassum Khan, Atul Sherje, “Analytical method development and validation for simultaneous estimation of Curcumin and Cyclosporine by RP-HPLC.” Int. J. Pharm. & Pharm. Sci. 2019, 11(2), 26.
    30. Suchita Panigrahi, Rajashree Hirlekar, “A new stability-indicating RP-HPLC method for determination of Curcumin: An Application to Nanoparticulate Formulation.” Int. J. Pharm. Sci. 2016, 8(12), 149.
    31. Sagar Kishor Savale, “Bioanalytical RP-HPLC method development and validation for estimation of Curcumin in plasma samples.” Asian J. Pharm. Anal. Med. Chem. 2017, 5(2), 96.
    32. Wisut Wichitnithad, Nutthapon Jongaroonngamsang, Sunilbhond Pummangura, Pornchi Rojsitthisak, “A simple isocratic HPLC method for the simultaneous determination of Curcuminoids in commercial turmeric extracts.” Phytochem. Anal. 2009, 20, 314.
    33. Kamran Ashrafl, Mohd Mujeeb, Altaf Ahmad, Mohd Amir, Md Nasar Mallick, Deepak Sharma, “Validated HPLC analysis method for quantification of variability in content of Curcumin in Curcuma longa L (turmeric) collected from different geographical region of India.” Asian Pac. J. Trop. Biomed. 2012, S584.
    34. Vijaylata Pathania, Ajai Prakash Gupta, Bikram Singh, “Improved HPTLC method for determination of Curcuminoids from Curcuma longa.” J. Liq. Chromatogr. & Related Tech. 2006, 29, 877.
    35. Vikash Jain, Vure Prasad, Satwayan Singh, Raghwendra Pal, “HPTLC method for quantitative determination of ar-Turmerone and Turmerone in lipid soluble fraction from Curcuma longa.” Natural Product Communications. 2007, 2(9), 927.
    36. M.J. Ansari, S. Ahmad, K. Kohli, J. Ali, R.K. Khar, “Stability-indicating HPTLC determination of Curcumin in bulk drug and pharmaceutical formulations.” J. Pharm. Biomed. Anal. 2005, 39, 132.
    37. Shanmugapriya P, Murugesan M, “Qualitative analysis and quantitative analysis determination of “Curcumin” in a siddha herbo-mineral formulation using High Performance Thin Layer Chromatography (HPTLC).” World J. Pharm. Res. 2016, 5(5), 1158.
    38. Vijaylata Pathania, Ajai Prakash Gupta, Bikram Singh, “Improved HPTLC method for determination of Curcuminoids from Curcuma longa.” J. Liq. Chromatogr. & Related Tech. 2006, 29, 877.
    39. Poonam Kushwaha, Babita Shukla, Jyotsana Dwivedi, Sumedha Saxena, “Validated High Performance Thin-Layer Chromatographic analysis of Curcumin in the methanolic fraction of Curcuma longa L. rhizomes.” Future J. Pharm. Sci. 2021, 7, 2.
