Abstract

This review dives into the fascinating world of nanoparticles (NPs), exploring their creation, properties, and diverse uses. NPs are incredibly small materials, typically ranging from 1 to 100 nanometers (nm) in size. They come in various forms, including organic, inorganic (metals, ceramics, polymers), and fullerenes. The unique properties of NPs, largely due to their tiny size, are revolutionizing many fields. Their high surface area, reactivity, stability, and sensitivity make them highly desirable for various applications.Multiple synthesis methods exist for creating NPs, enabling researchers to tailor them for specific purposes. In recent decades, NPs have found widespread use in industry and environmental applications.

Keywords

Introduction

STRUCTURAL BASIS OF NANOPARTICLE

Unlike simple molecules, nanoparticles (NPs) have a complex structure with three distinct layers:

1. Surface Layer:

This outermost layer can be customized with various molecules like surfactants, polymers, and even metal ions.

2. Shell Layer:

This middle layer is made of a different material than the core, offering additional functionality.

3. Core:

The central part of the NP, often containing the drug itself.

Nanoparticles come in various shapes and sizes, categorized based on the number of dimensions they exhibit at the nanoscale (1-100 nanometers):

1. 0-Dimensional (0D):

These are tiny, nearly spherical objects with all three dimensions confined to the nanoscale. Think of them as ultra-small dots, often called quantum dots.

2. 1-Dimensional (1D):

Imagine long, thin structures with only one dimension exceeding the nanoscale. Examples include nanowires and nanotubes.

3. 2-Dimensional (2D):

These are like ultra-thin sheets where two dimensions (length and width) are nanoscale, while the third dimension (thickness) is much smaller. A famous example is graphene.

4. 3-Dimensional (3D):

These are more common and encompass most traditional nanoparticles, where all three dimensions (height, width, and length) fall within the nanoscale range. Think of gold nanoparticles used in various applications.8 Nanoparticles (NPs) can be classified into different categories based on their building blocks, size, and shape. Three main categories encompass most nanoparticles:

Organic nanoparticles:

Organic nanoparticles (NPs) are microscopic carriers built from natural or synthetic polymers, lipids, or proteins. Typically ranging from 10 nanometers to 1 micrometer in size, they offer several advantages for drug delivery:

• Biocompatibility:

Organic NPs are often well-tolerated by the body, reducing the risk of side effects.

• Biodegradability:

They can naturally break down over time, minimizing environmental impact.

• Controlled Release:

The design of organic NPs allows for controlled release of the encapsulated drug, improving drug targeting and efficacy.

• Economics:

Compared to some inorganic NPs, organic NPs can be more cost-effective to produce. Examples of well-known organic NPs include micelles, dendrimers, ferritin, and liposomes. Some, like micelles and liposomes, can even have a hollow core (nanocapsule) for drug encapsulation. These unique properties make organic NPs a promising platform for advanced drug delivery applications.9

Inorganic nanoparticles

• Metal NPs:

Almost any metal can be turned into nanoparticles, typically ranging from 10 to 100 nanometers. These NPs offer unique properties due to partially filled electron orbitals and find applications in drug delivery, biomolecule detection, and environmental cleanup. Common examples include gold and silver nanoparticles.

• Ceramic NPs:

These inorganic NPs are formed from materials like oxides and carbides. They come in various shapes and are used in catalysis, drug delivery (targeting tumors), and dye degradation.8

• Semiconductor NPs:

These bridge the gap between metals and non-metals. They exhibit interesting properties due to their tunable bandgaps and are used in electronics, photocatalysis, and water splitting applications. Examples include Gallium Nitride (GaN) and Zinc Oxide (ZnO).9

• Polymeric NPs:

These organic NPs can be spheres (nanospheres) or capsules (nanocapsules). They offer biocompatibility and controlled drug release, making them ideal for drug delivery applications.

• Lipid-based NPs:

Analogous to polymeric nanoparticles, lipid-based NPs also exploit lipids as their elemental constituents. The effectiveness of these nanoparticles is notable in drug delivery which has proven to be effective for cancer therapy among others and RNA release during therapies.

• Carbon-based Nanomaterials:

Fullerenes, carbon nanotubes (CNTs), graphene — these are the progeny of carbon-based nanomaterials. NPs that boast unique electrical, mechanical, and structural properties owing to their lineage as carbon derivatives; industries where such materials find value include electronics and materials science.10

HOW NANOPARTICLES DIFFER ?

When it comes to NPs, their small size is what makes them unique. A significant percentage of atoms in NPs are located on the surface due to their incredibly small size; this results in an unusual behavior where surface area dominates over bulk materials. Another important factor that affects the properties of NPs is quantum mechanics which comes into play significantly at nanoscale: these properties are influenced by quantum effects.

And interparticle interactions matter a great deal in the nanoworld where, unlike in the wonderfully solitary world of single atoms, particles don’t live isolated. They live within ‘swarms’ of similar and different NPs through weak interparticle forces such as Van der Waals forces, electrostatic forces and hydration forces. Understanding and expertly applying these forces is critical in predicting the behaviour of NPs.

Unusual characteristics of NPs include:

1. Jolting held: heat conduction between particles, as well as Brownian motion in suspensions, lead to quick and efficient heat transfer.
2. Thermal Stability: NPs melt earlier than the bulk materials due to smaller forces of attraction between interatomic bonds on the surface.
3. Chemical Reactivity: With more surface area, NPs become more reactive, but also more susceptible to environmental impacts
4. Biocidal Properties: Some NPs exhibit antibacterial, antifungal, and disinfectant properties.
5. Oxidising and reducing properties of NPs: This is related to the chemical substance. Flammability, or not: This depends on the material. Corrosive, corrosion control, or preventing corrosion: If made of certain substances, nanosize materials can work as anti-corrosive agents.11

APPROACHES FOR NP SYNTHESIS:

There are two main approaches for synthesizing NPs with desired properties:

1. Bottom-up constructive approach:

This is a technique that involves building NPs starting from smaller building blocks, such atoms or clusters. The size and the structure are closely controlled. Examples:

• Nanolithography:

A technique using light or electron beams to create precise patterns on a surface, defining the shape and size of NPs. Two Primary Lithography Techniques: Masked and Maskless

• Masked Lithography (common):

Uses a pre-designed mask to define patterns in a light-sensitive material. Light exposure alters the material for further processing (etching or deposition) to create nanoscale patterns.

• Maskless Lithography (flexible):

Offers more freedom for creating custom patterns without a mask. Focused beams or probes directly manipulate the light-sensitive material for pattern formation.

• Laser Ablation:

Laser ablation synthesis offers a unique method for generating nanoparticles. It utilizes a highly focused laser beam to precisely vaporize a target material. This intense laser irradiation delivers a tremendous amount of energy, causing the material to rapidly transition from a solid state directly into a vapor state. This vaporized material then condenses under specific conditions, leading to the formation of nanoparticles.

• Sputtering:

Sputtering is a versatile technique used in nanotechnology to create thin films of nanomaterials. It works by bombarding a solid target material with high-energy particles, typically from a plasma or gas. These energetic collisions eject atoms from the target, which then condense and deposit as a thin film on a nearby surface. This process allows for precise control over the composition and thickness of the resulting nanomaterial film.

• Thermal Decomposition:

Thermal breakdown offers a novel, practical way to make uniform-sized metal nanoparticles. By fine-tuning factors like temperature, reactant amounts, and stabilizers, researchers can achieve desired nanoparticle properties. Thermal breakdown is attractive due to its simplicity, scalability, and high production yield. It works by using heat to break down precursor materials at specific temperatures, triggering a chemical reaction that forms the nanoparticles.12,14

2. Top-down Approach (Destructive):

This method breaks down bulk materials into smaller nanoparticles. It's generally simpler but offers less control over size and structure. Examples include:

• Mechanical Milling:

Ball milling reigns supreme as the most cost-effective method for mass-producing nanomaterials. This technique utilizes a high-energy shaking process. A chamber filled with balls (often metal or ceramic) collides with the material being processed, grinding it down to nanoscale particles. This versatility makes ball milling a top choice for creating a wide range of nanoparticles and metal alloys.

• Specific Techniques:
• Chemical Vapor Deposition (CVD):

Chemical Vapor Deposition (CVD) is a technique for depositing thin films or powders on surfaces. It works by introducing gaseous precursors (chemical starting materials) into a chamber. These precursors react (often requiring extra energy) to form a solid material that then coats the surfaces present. This versatile process can involve both gas-phase and surface-based chemical reactions.

• Sol-Gel Process:

The sol-gel process starts with liquid precursors like metal alkoxides. These undergo a chain reaction involving hydrolysis and polycondensation, forming a colloidal suspension (sol) at room temperature and pressure. This sol then transforms into a solid gel. By drying and calcining the gel, researchers obtain metal oxide nanoparticles. The sol-gel process allows for control over the shape, morphology, and texture of the final nanomaterial.

• Spinning Method:

This technique utilizes a spinning disc reactor to generate nanoparticles. A precursor solution is forced onto a rapidly spinning disc, where it spreads and solidifies under controlled conditions. This rapid process can be advantageous for producing certain types of nanoparticles.

• Pyrolysis:

Pyrolysis, heating a material in high temperatures without oxygen, is a leading method for industrial nanoparticle production. Liquid or gas precursors are injected into a furnace, breaking down due to intense heat (often from flames, but lasers or plasma can be used for faster control). The resulting gas stream is then separated to isolate the desired nanoparticles. This efficient, scalable process makes pyrolysis ideal for mass production.13,15

NANOPARTICLE CHARACTERIZATION: UNVEILING THE TINY

Characterizing nanoparticles (NPs) is crucial to understand their behavior and optimize their applications. Key properties analyzed include:

• Size and Distribution:

Electron microscopy (SEM/TEM) is the gold standard for size and distribution analysis. Other techniques like laser diffraction and photon correlation spectroscopy are used for specific sample types.

• Surface Area:

The Brunauer-Emmett-Teller (BET) method is the primary technique for measuring surface area, which significantly impacts NP behavior.

• Composition:

X-ray photoelectron spectroscopy (XPS) is extensively used to determine the fundamental make-up of NPs. Additional techniques like mass spectrometry can offer a complete compositional profile.

THE DIVERSE APPLICATIONS OF NANOPARTICLES

Nanoparticles (NPs) hold tremendous potential due to their unique properties and multiple applications. Here’s a breakdown of the key areas where NPs are having the biggest impact:

1. Cancer Detection:

Gold nanoparticles conjugated with antibodies can target and bind to precise most cancers cells, taking into consideration their detection via imaging techniques like dark-area microscopy. (Example: HER2-effective breast most cancers cells)

• Skin Cancer Diagnosis:

 Surface-superior Raman spectroscopy (SERS) the usage of gold nanoparticles can probably provide rapid and accurate detection of basal cell carcinoma (BCC), a not unusual shape of skin most cancers.

• Antibacterial Properties:

Silver nanoparticles (AgNPs) show off robust antibacterial activity because of their interplay with bacterial mobile membranes. This makes them suitable for diverse packages, together with wound healing and antimicrobial coatings.

• Drug Delivery:

Nanoparticles may be designed to deliver tablets mainly to diseased cells, improving treatment efficacy and decreasing facet consequences. Researchers are exploring strategies to overcome the blood-brain barrier for targeted drug delivery to the mind.12

2. Catalysis:

Gold Nanoparticles as Catalysts: Despite not being appropriate catalysts in bulk shape, gold nanoparticles can become powerful catalysts due to the "quantum size impact." This unique belongings makes them treasured for various chemical reactions, which include hydrogenation and oxidation.

3. Food and Agriculture:

Nanotechnology in Food Science: Nanotechnology offers new possibilities for food safety, preservation, and delivery of essential nutrients.

4. Energy Applications:

Energy Harvesting: NPs with properties like large surface area and catalytic activity are being explored for harvesting energy from various sources, including solar and mechanical energy.

Energy Storage: Nanoparticles hold promise for developing next-generation energy storage solutions.

5. Electronics:

Printed Electronics: Nanoparticles like carbon nanotubes and organic nanoparticles are being used to develop printed electronics, offering a potentially cheaper and faster alternative to traditional methods.16

6. Medical Imaging:

Magnetic Resonance Imaging (MRI): Magnetic nanoparticles (MNPs) act as contrast agents in MRI, enhancing the visibility of specific tissues and organs. This improves the accuracy and detail of medical scans.17

THE NANOTECH BOOM: PROMISE AND CHALLENGES

Nanotechnology has exploded in recent years, with a surge in research dedicated to nanoparticles and their potential applications in various fields, especially medicine. However, translating this exciting potential into real-world treatments remains a significant hurdle. While pre-clinical studies (in vitro and in vivo) often show promising results, only a small fraction of nanoparticles progress to human trials. This highlights the challenge of bridging the gap between basic science discoveries and practical applications.

1. Manufacturing Matters

As mentioned, the ability to manufacture nanoparticles continuously and on a huge scale is essential for their fulfillment. Factors like price, scalability, and preserving preferred homes during production turn out to be vital issues.

2. Safety First

The precise homes of nanoparticles also boost issues approximately their ability toxicity and lengthy-term outcomes on human health. Extensive protection checks are vital earlier than good sized use.

3. Three.      Regulatory Roadblocks

Regulatory organizations have strict suggestions for drug improvement, and nanoparticles frequently require new testing protocols due to their novel nature. This can upload complexity and time to the development method.

4. The Road Ahead

The destiny of nanoparticle-based totally remedies hinges on overcoming these challenges. Here are some key regions for improvement:

• Translational Focus: Research efforts need to prioritize packages with a clear route to medical translation, ensuring the chosen nanoparticles have a practical threat of achieving patients.
• Manufacturability Matters: Early-stage studies should don't forget the feasibility of large-scale manufacturing strategies to keep away from roadblocks later in improvement.
• Safety through Design: Rigorous safety trying out and an intensive know-how of ability dangers are critical for responsible development and regulatory approval.
• Collaboration is Key: Effective collaboration between academic researchers and pharmaceutical corporations can bridge the distance among simple technology and commercialization

CONCLUSION

Nanotechnology's software in medicinal drug is unexpectedly expanding. Nanoparticles are being explored for scientific imaging, prognosis, and treatment, with numerous studies progressing via medical trials. The pharmaceutical industry is actively utilising nanoparticles to expand more secure and more effective medicinal drugs. This revised model avoids redundancy and makes a speciality of the important thing benefits of nanoparticles in medicine. It additionally clarifies the purpose of characterization strategies and emphasizes the developing importance of nanomedicine.

REFERENCES

1. Ahmed TA, Aljaeid BM. Preparation, characterization, and potential application of chitosan, chitosan derivatives, and chitosan metal nanoparticles in pharmaceutical drug delivery. Drug design, development and therapy. 2016 Jan 28:483-507.
2. Jeevanandam J, San Chan Y, Danquah MK. Nano-formulations of drugs: recent developments, impact and challenges. Biochimie. 2016 Sep 1;128:99-112.
3. Jeevanandam J, Barhoum A, Chan YS, Dufresne A, Danquah MK. Review on nanoparticles and nanostructured materials: history, sources, toxicity and regulations. Beilstein journal of nanotechnology. 2018 Apr 3;9(1):1050-74.
4. Azmi N, Tiwari A, Kaur N, Chaskar A. Nanotechnology: A Promising Approach in Nerve Regeneration. Current Nanoscience. 2023 May 1;19(3):305-21.
5. Pal SL, Jana U, Manna PK, Mohanta GP, Manavalan R. Nanoparticle: An overview of preparation and characterization. Journal of applied pharmaceutical science. 2011 Aug 30(Issue):228-34.
6. Farjadian F, Ghasemi A, Gohari O, Roointan A, Karimi M, Hamblin MR. Nanopharmaceuticals and nanomedicines currently on the market: challenges and opportunities. Nanomedicine. 2019 Jan;14(1):93-126.
7. Mohanraj, V.J. & Chen, Y. (2007). Nanoparticles - A Review. Tropical Journal of Pharmaceutical Research. 5. 10.4314/tjpr.v5i1.14634
8. Ibrahim Khan KS, Khan I. Nanoparticles: Properties, applications and toxicities. Arabian journal of chemistry. 2017 Mar;12(7):908-31.
9. Kumari S, Sarkar L. A review on nanoparticles: structure, classification, synthesis & applications. Journal of Scientific Research. 2021;65(8):42-6.
10. Joudeh N, Linke D. Nanoparticle classification, physicochemical properties, characterization, and applications: a comprehensive review for biologists. Journal of Nanobiotechnology. 2022 Jun 7;20(1):262.
11. Singh M, Sharma V, Shrivastav A, Singh P, Verma N. Nanotechnology for Novel Drug Delivery: A Systematic Review of Classification, Preparation, Characterization, and Applications of Nanoparticles in Drug Delivery. Biosciences Biotechnology Research Asia. 2023 Dec 31;20(4):1147-65.
12. Baig N, Kammakakam I, Falath W. Nanomaterials: A review of synthesis methods, properties, recent progress, and challenges. Materials Advances. 2021;2(6):1821-71.
13. Kolahalam LA, Viswanath IK, Diwakar BS, Govindh B, Reddy V, Murthy YL. Review on nanomaterials: Synthesis and applications. Materials Today: Proceedings. 2019 Jan 1;18:2182-90..
14. Khan Y, Sadia H, Ali Shah SZ, Khan MN, Shah AA, Ullah N, Ullah MF, Bibi H, Bafakeeh OT, Khedher NB, Eldin SM. Classification, synthetic, and characterization approaches to nanoparticles, and their applications in various fields of nanotechnology: A review. Catalysts. 2022 Nov 8;12(11):1386.
15. Ijaz I, Gilani E, Nazir A, Bukhari A. Detail review on chemical, physical and green synthesis, classification, characterizations and applications of nanoparticles. Green Chemistry Letters and Reviews. 2020 Jul 2;13(3):223-45.
16. Yohan D, Chithrani BD. Applications of nanoparticles in nanomedicine. Journal of Biomedical Nanotechnology. 2014 Sep 1;10(9):2371-92.
17. Harish V, Tewari D, Gaur M, Yadav AB, Swaroop S, Bechelany M, Barhoum A. Review on nanoparticles and nanostructured materials: Bioimaging, biosensing, drug delivery, tissue engineering, antimicrobial, and agro-food applications. Nanomaterials. 2022 Jan 28;12(3):457
