Glipizide in Situ Gels: A Promising Approach for Gastroretentive Drug Delivery

Abstract

Glipizide, a second-generation sulfonylurea, is widely used to manage type 2 diabetes. However, it requires frequent dosing to its short half-life, low bioavailability, and site-specific absorption in the upper gastrointestinal tract. Gastroretentive drug delivery system (GRDDS), especially in situ gels, address these issues by extending gastric retention and allowing sustained drug release. These systems convert from liquid to gel in response to physiological triggers like pH, ions, or temperature. Key polymers such as sodium alginate, gellan gum, poloxamers, and HPMC are used to formulate these gels. Evaluation parameters include gelation capacity, drug release profile, mucoadhesive strength, and floating behavior. Research indicates that in situ gels can sustain drug release for 12-24 hours, enhancing therapeutic efficacy and patient compliance. Despite their promise, challenges remain, such as ensuring formulation consistency and scalability. Future studies should focus on optimizing polymer combinations, conducting in vivo studies for validation, and addressing regulatory requirements to ensure safe and effective clinical use.

Keywords

In situ Gel, Gastroretentive Drug Delivery, Thermosensitive Gel, Type 2 Diabetes, Mucoadhesive Polymers, Sustained Drug Release

Introduction

Table.1: Overview of In Situ Gel Systems for Glipizide

Table.1 Types of In Situ Gel System

Mechanism of In Situ Gels in Gastroretentive Drug Delivery Systems (GRDDS)

In situ gels are a promising approach within gastroretentive drug delivery systems (GRDDS), particularly beneficial for drugs like glipizide that have a narrow absorption window in the upper gastrointestinal tract. These formulations are administered as liquids and undergo a sol-to-gel transformation once they encounter physiological conditions in the stomach. The mechanisms through which they work can be categorized as physical, physicochemical, and biological ^[11].

1. Physical Mechanisms

The primary physical mechanisms include floating and mucoadhesion. Floating in situ gels are designed to have a lower density than gastric fluids, allowing them to float on the stomach contents. This buoyant property helps the formulation stay in the stomach longer, avoiding premature transit to the intestines ^[12]. Another physical mechanism is mucoadhesion, where the gel adheres to the gastric mucosa through weak physical interactions such as hydrogen bonding or van der Waals forces. This localized adhesion prevents displacement by gastric motility, enhancing gastric retention time ^[13].

2. Physicochemical Mechanisms

These involve environmental triggers that induce gelation. pH-sensitive systems respond to the acidic pH of the stomach, where polymers like sodium alginate and Carbopol gel, upon exposure to gastric fluids ^[14]. Ion-sensitive gels use polymers like gellan gum or pectin, which undergo gelation in the presence of divalent ions (e.g., Ca²? or Mg²?) naturally present in the stomach. Thermosensitive gels, such as those made with poloxamers, remain liquid at room temperature but form gels at body temperature (~37°C), enabling temperature-triggered gelation after administration ^[15].

3. Biological Mechanisms

Less commonly used in GRDDS, enzyme-triggered systems rely on specific enzymes to initiate gelation. These are more applicable to site-specific delivery in the intestines rather than the stomach, but remain an area of research interest ^[16].

POLYMERS USED IN IN SITU GEL FORMULATIONS

1. Gellan Gum

Ion-activated polysaccharides form in situ gels in the presence of divalent cations like calcium (Ca²?). The gelation occurs through ionic crosslinking between the polymer chains and the ions, providing structural integrity and prolonged gastric retention ^[17]. These polymers exhibit high gel strength and stability, making them suitable for sustained drug delivery. When combined with gas-generating agents, they offer excellent floating ability, enhancing gastric retention. Additionally, they are biocompatible and well-tolerated, ensuring safety for long-term use ^[18].

2. Sodium Alginate

Natural polysaccharides, such as sodium alginate, form ion-sensitive in situ gels through interaction with calcium ions, creating an “egg-box” structure ^[19]. Polymers are mucoadhesive, non-toxic, and form soft yet stable gels. Increasing their concentration enhances gel strength, prolongs drug release, and influences gelation time and mechanical properties ^[20].

3. Carbopol

pH-sensitive synthetic polymers, such as Carbopol, swell and form gels in acidic environments through hydrogen bonding and chain entanglement ^[21]. They exhibit excellent thickening and mucoadhesive properties, making them suitable as primary or secondary gelling agents. Even at low concentrations, they significantly increase viscosity, while higher concentrations strengthen the gel network and may delay drug release ^[22].

4. HPMC (Hydroxypropyl Methylcellulose)

Semi-synthetic cellulose derivatives, such as HPMC (Hydroxypropyl Methylcellulose), primarily function as viscosity enhancers and drug release modulators. They possess good film-forming and stabilizing properties and are non-reactive, making them compatible with other polymers. Increasing their concentration enhances viscosity and mucoadhesiveness while slowing drug diffusion through the gel matrix, contributing to sustained release ^[23].

FORMULATION STRATEGIES FOR GLIPIZIDE IN SITU GELS

Developing an effective gastroretentive in situ gel system for glipizide requires precise formulation strategies to ensure prolonged gastric residence, consistent gelation, and controlled drug release ^[24]. Key considerations include:

1. Optimization of Polymer Concentration

• The choice and concentration of polymers such as gellan gum, sodium alginate, or poloxamer 407 directly influence the viscosity, gel strength, and drug diffusion rate.
• An optimal balance is necessary: too low may lead to weak gelation, while too high may hinder pourability and drug release ^[25].

2. Selection and Use of Gelling Agents

• Ion-induced gelation is commonly employed using:
  • Calcium carbonate (CaCO?): Slowly releases calcium ions, promoting gradual and sustained gelation.
  • Calcium chloride (CaCl?): Provides immediate and strong ionic crosslinking for quick gelation.
• The amount and form of calcium source affect the rate and uniformity of gel formation ^[26].

3. pH Adjustment

• Ensuring that the formulation gels specifically in the acidic pH of the stomach (~1.2) is critical.
• An acidic pH promotes gelation in pH-sensitive polymers, such as Carbopol, and helps maintain drug solubility and stability.
• Buffers or acidifiers may be added to maintain appropriate pH for triggering gelation post-administration ^[27].

Drug Loading and Compatibility

• Uniform dispersion of glipizide within the gel matrix is essential for consistent dosing and reproducible release profiles.
• Drug-polymer interactions must be studied to avoid precipitation, crystallization, or incompatibility that may affect performance.

These formulation strategies play a vital role in achieving the desired gastroretentive behavior, mucoadhesion, and therapeutic efficiency of glipizide in situ gel systems ^[28].

EVALUATION PARAMETERS OF GLIPIZIDE IN SITU GELS

Through evaluation of in situ gel formulations is essential to ensure their performance, stability, and therapeutic efficiency. The following parameters are commonly assessed:

IN VITRO GELATION STUDY

This study evaluates the ability of in situ gel formulations to undergo sol-to-gel transition under simulated gastric conditions, typically using simulated gastric fluid (pH ~1.2). Gelation may be triggered by pH change (e.g., Carbopol), ionic interaction (e.g., gellan gum, sodium alginate), or temperature shift (e.g., poloxamer 407) ^[29].

For ion-activated systems, divalent cations like Ca²? (from calcium chloride or calcium carbonate) promote gel formation via ionic cross-linking ^[30].

Gelation is assessed based on:

• Time required for gelation
• Gel clarity and strength
• Stability of the formed gel

VISCOSITY AND RHEOLOGICAL BEHAVIOR

This parameter assesses the flow characteristics of the formulation before and after gelation using a viscometer or rheometer. Ideal in situ gels show pseudoplastic (shear-thinning) behavior, allowing easy administration and strong gel formation in the stomach ^[31]. Viscosity directly influences pourability, Spreadability, and gastric retention, making it a critical factor in formulation performance ^[32].

FLOATING ABILITY AND GEL STRENGTH

Floating ability is assessed by measuring floating lag time and total floating duration in simulated gastric fluid, crucial for prolonged gastric retention. Gel strength is evaluated using a texture analyzer or penetration test, ensuring the gel can withstand gastric motility and sustain drug release. Together, these parameters enhance gastric retention and ensure localized, controlled drug delivery ^[33].

IN VITRO DRUG RELEASE AND KINETIC MODELING

Drug release is evaluated using a USP dissolution apparatus, and results are analysed using kinetic models like Zero-order, First-order, Higuchi, and Korsmeyer-Peppas. This helps determine the release rate and mechanism, assessing the formulation’s capability for sustained drug delivery ^[34].

IN VIVO STUDIES

In vivo studies are essential for evaluating the pharmacokinetic profile and therapeutic efficacy of glipizide in situ gel formulations. These studies are typically carried out in appropriate animal models or human volunteers to determine key pharmacokinetic parameters such as Cmax (maximum plasma concentration), Tmax (time to reach Cmax), and AUC (area under the plasma concentration-time curve). The performance of the in-situ gel is compared with that of conventional glipizide dosage forms to assess improvements in drug delivery. Enhanced bioavailability, prolonged drug action, and reduced dosing frequency are primary indicators of formulation success ^[35]. These studies help establish the effectiveness of the gel in sustaining drug release and improving patient compliance. Additionally, therapeutic outcomes such as blood glucose regulation are monitored to confirm clinical efficacy. Overall, in vivo evaluations are crucial for translating in vitro performance into real-world therapeutic benefits ^[36].

FUTURE PERSPECTIVES

The development of glipizide in situ gels presents numerous opportunities for innovation in drug delivery. One promising direction is the formulation of combination therapies, such as co-delivery with metformin, to improve glycaemic control in type 2 diabetes. Furthermore, advances in smart in situ gels—responsive to multiple physiological stimuli like pH, temperature, or glucose levels—could enable controlled, site-specific drug release tailored to patient needs. Future research should also focus on clinical trials to establish long-term efficacy, safety, and patient compliance. In addition, this delivery platform can be extended to other drugs with narrow absorption windows, low solubility, or requiring sustained gastric residence, making it a versatile strategy in oral drug delivery.

CONCLUSION

Glipizide in situ gels represent a promising gastroretentive drug delivery system that enhances bioavailability, ensures prolonged therapeutic action, and enables reduced dosing frequency. With optimized formulation strategies and comprehensive evaluation, these systems can significantly improve the management of diabetes by providing sustained and targeted drug release. As research advances, further clinical validation will be crucial to confirm their safety and efficacy, paving the way for personalized therapies and potential combination treatments. This innovative approach holds strong potential for broader application in oral delivery of drugs with similar absorption characteristics.

ACKNOWLEDGEMENT

I conveyed special thanks to my guide, faculty, and department for their valuable support and guidance.

CONFLICT OF INTEREST

All authors, including the guide and co-guide, declare that there are no conflicts of interest related to the publication of this review article.

REFERENCES

1. Kolawole OM, Cook MT. In situ gelling drug delivery systems for topical drug delivery. European Journal of Pharmaceutics and Biopharmaceutics 2023;184:36–49.
2. Ankit Arun Kumar Jaiswal HSCABKDrAB. Design And Characterization Of In Situ Gel Formulations. International Journal of Pharmaceutical Sciences [Internet] 2024 [cited 2025 Apr 17];2:720. Available from: https://www.ijpsjournal.com/article/Design+And+Characterization+Of+In+Situ+Gel+Formulations
3. Sapavatu SN, Jadi RK. Formulation development and characterization of gastroretentive drug delivery systems of loratadine. International Journal of Applied Pharmaceutics 2019;11(6):91–9.
4. Padmasri B, Nagaraju R, Prasanth D. A comprehensive review on in situ gels. International Journal of Applied Pharmaceutics 2020;12(6):24–33.
5. Himashree P, Sengar AS, Sunil CK. Food thickening agents: Sources, chemistry, properties and applications - A review. Int J Gastron Food Sci 2022;27:100468.
6. Kaleem MA, Alam MZ, Khan M, Jaffery SHI, Rashid B. An experimental investigation on accuracy of Hausner Ratio and Carr Index of powders in additive manufacturing processes. Metal Powder Report 2021;76:S50–4.
7. El-Dakroury WA, Zewail MB, Amin MM. Design, optimization, and in-vivo performance of glipizide-loaded O-carboxymethyl chitosan nanoparticles in insulin resistant/type 2 diabetic rat model. J Drug Deliv Sci Technol 2023;79.
8. Aklima A, Baral PK, Amin MT, Emon TI, Hossain MS. Formulation and Quality Optimization of Effervescent Tablet of Glipizide: An Approach to Comfort Anti-Diabetic Medication. Modern Health Science 2020;3(2):p14.
9. Aslani A, Fattahi F. Formulation, characterization and physicochemical evaluation of potassium citrate effervescent tablets. Adv Pharm Bull 2013;3(1):217–25.
10. Beakawi Al-Hashemi HM, Baghabra Al-Amoudi OS. A review on the angle of repose of granular materials. Powder Technol 2018;330:397–417.
11. Mandal UK, Chatterjee B, Senjoti FG. Gastro-retentive drug delivery systems and their in vivo success: A recent update. Asian J Pharm Sci 2016;11(5):575–84.
12. Omidian H. Gastroretentive drug delivery systems: A holy grail in oral delivery. Drug Discov Today 2025;30(4).
13. Das S, Kaur S, Rai VK. Gastro-retentive drug delivery systems: a recent update on clinical pertinence and drug delivery. Drug Deliv Transl Res 2021;11(5):1849–77.
14. Lopes CM, Bettencourt C, Rossi A, Buttini F, Barata P. Overview on gastroretentive drug delivery systems for improving drug bioavailability. Int J Pharm 2016;510(1):144–58.
15. (PDF) Floating In Situ Gels for Gastroretentive Drug Delivery Systems (GRDDS): Advances, Mechanisms, and Therapeutic Potential [Internet]. [cited 2025 May 16];Available from: https://www.researchgate.net/publication/386134495_Floating_In_Situ_Gels_for_Gastroretentive_Drug_Delivery_Systems_GRDDS_Advances_Mechanisms_and_Therapeutic_Potential
16. Sen O, Manna S, Nandi G, Jana S, Jana S. Recent advances in alginate based gastroretentive technologies for drug delivery applications. Med Nov Technol Devices 2023;18.
17. Gomes D, Batista-Silva JP, Sousa A, Passarinha LA. Progress and opportunities in Gellan gum-based materials: A review of preparation, characterization and emerging applications. Carbohydr Polym 2023;311.
18. Lalebeigi F, Alimohamadi A, Afarin S, Aliabadi HAM, Mahdavi M, Farahbakhshpour F, et al. Recent advances on biomedical applications of gellan gum: A review. Carbohydr Polym 2024;334.
19. Rahman MM, Shahid MA, Hossain MT, Sheikh MS, Rahman MS, Uddin N, et al. Sources, extractions, and applications of alginate: a review. Discover Applied Sciences 2024;6(8).
20. Jadach B, ?wietlik W, Froelich A. Sodium Alginate as a Pharmaceutical Excipient: Novel Applications of a Well-known Polymer. J Pharm Sci 2022;111(5):1250–61.
21. Khan BA, Ali A, Hosny KM, Halwani AA, Almehmady AM, Iqbal M, et al. Carbopol emulgel loaded with ebastine for urticaria: development, characterization, in vitro and in vivo evaluation. Drug Deliv [Internet] 2022 [cited 2025 Apr 17];29(1):52–61. Available from: https://www.tandfonline.com/doi/abs/10.1080/10717544.2021.2015483
22. Moura S, Noro J, Cerqueira P, Silva C, Cavaco-Paulo A, Loureiro A. Poloxamer 407 based-nanoparticles for controlled release of methotrexate. Int J Pharm 2020;575.
23. Tundisi LL, Mostaço GB, Carricondo PC, Petri DFS. Hydroxypropyl methylcellulose: Physicochemical properties and ocular drug delivery formulations. European Journal of Pharmaceutical Sciences 2021;159.
24. Ankit Arun Kumar Jaiswal HSCABKDrAB. Design And Characterization Of In Situ Gel Formulations. International Journal of Pharmaceutical Sciences [Internet] 2024 [cited 2025 Apr 17];2:720. Available from: https://www.ijpsjournal.com/article/Design+And+Characterization+Of+In+Situ+Gel+Formulations
25. Pai SM, Shah KA, Sunder S, Albuquerque RQ, Brütting C, Ruckdäschel H. Machine learning applied to the design and optimization of polymeric materials: A review. Next Materials 2025;7.
26. Raeisi Estabragh MA, Sajadi Bami M, Dehghannoudeh G, Noudeh YD, Moghimipour E. Cellulose derivatives and natural gums as gelling agents for preparation of emulgel-based dosage forms: A brief review. Int J Biol Macromol 2023;241.
27. Ji Z, Liu H, Yu L, Duan Q, Chen Y, Chen L. pH controlled gelation behavior and morphology of gelatin/hydroxypropylmethylcellulose blend in aqueous solution. Food Hydrocoll 2020;104.
28. J? Penn M, Hennessy MG. Optimal loading of hydrogel-based drug-delivery systems. Appl Math Model 2022;112:649–68.
29. Chen Q, Ji H, Wang Z, Wang Y, Wang X, Chen Z. Effects of different charged polysaccharides on the gelation properties and in vitro digestibility of potato protein gel: Insight into underlying mechanisms. Food Hydrocoll 2025;164.
30. Shen T, Yang Z. In vivo and in vitro evaluation of in situ gel formulation of pemirolast potassium in allergic conjunctivitis. Drug Des Devel Ther 2021;15:2099–107.
31. Milián D, Roux DCD, Caton F, El Kissi N. Rheological behavior of gel polymer electrolytes: yield stress and viscoelasticity. Rheol Acta 2022;61(6):401–13.
32. Ghebremedhin M, Seiffert S, Vilgis TA. Physics of agarose fluid gels: Rheological properties and microstructure. Curr Res Food Sci 2021;4:436–48.
33. Yadiki KK, Kokatanur U, Dandagi PM, Hulyalkar S. Formulation and Evaluation of Floating Oral in situ Gel of  Liquorice Extract. Indian Journal of Pharmaceutical Education and Research 2024;58(1s):167–75.
34. Botros SR, Hussein AK, Mansour HF. A Novel Nanoemulsion Intermediate Gel as a Promising Approach for Delivery of Itraconazole: Design, In Vitro and Ex Vivo Appraisal. AAPS PharmSciTech 2020;21(7).
35. Yasser M, El Naggar EE, Elfar N, Teaima MH, El-Nabarawi MA, Elhabal SF. Formulation, optimization and evaluation of ocular gel containing nebivolol Hcl-loaded ultradeformable spanlastics nanovesicles: In vitro and in vivo studies. Int J Pharm X 2024;7.
36. Liu Y, Chen X, Chen X, Chen J, Zhang H, Xu H, et al. Preparation and in vivo and ex vivo studies of sirolimus nano-in-situ gel ophthalmic formulation. J Nanobiotechnology 2024;22(1).
