Nanoemulgel As A Novel Carrier for Topical Drug Delivery System: A Brief Review

Abstract

Nanoemulgel is an excellent delivery method for lipophilic medicines. Nanoemulgel refers to an emulsion that has gelled with the help of a gelling agent. Immiscible liquids can be spread as droplets within another liquid to create o/w or w/o variants. Hydrogel-based nanoemulsion systems, also known as nanoemulgels, use a homogeneous hydrogel matrix to enhance skin penetration of nanoemulsion droplets (10-200 nm in size). This alternate delivery method is effective for treating a wide range of disorders due to its high drug loading, enhanced bioavailability, and controllable release. Nanoemulgel formulations have been effective in treating inflammation caused by rheumatoid arthritis, psoriasis, fungal infections, acne, and pimples. Nanoemulgel is anticipated to become the standard for topical delivery of lipophilic medications in the future. Applying nanoemulgels alters the skin's composition, which increases the drug's capacity to pass through the epidermis. Nanoemulgels are characterized by a high water content, bioadhesive qualities, high biocompatibility, biodegradability, and the capacity to form deposits that enable drugs to gradually elute into surrounding tissues while sustaining a high local concentration for a prolonged period of time. This brief review covers the components, formulation methods, characterization, factors affecting drug absorption. Despite a few drawbacks, nanoemulgel formulations are viable and promising options for topical delivery of lipophilic medications in the future.

Keywords

Introduction

Fig 1: Structure of nanoemulgel

Nano-Emulgel:

Components:

The main components of nanoemulgel are as follows:

Oil: The choice of the oil phase is a crucial factor for stabilizing a nanoemulsion, as it enables the highest possible drug solubilization⁹. Typically, the oil with the greatest solubilizing capacity for the specific drug candidate is chosen as the oily phase in nanoemulsion formulations to maximize drug loading. Additionally, a combination of oils can be used to enhance the solubilization of the drug like Clove oil, olive oil, castor oil, coconut oil¹⁰.

Surfactants: The amphiphilic nature of surfactants allows them to disperse two immiscible phases, lowering interfacial tension and forming a stable film that can deform around droplets with optimal curvature¹¹. Surfactants also enhance skin permeation by temporarily binding to keratin filaments, leading to corneocyte disruption and altering the diffusion coefficient of the stratum corneum¹². The penetration of various drugs through the skin is influenced by the concentration of the surfactant mixture, with higher surfactant concentrations significantly improving the permeation of hydrophilic drugs. Most frequently used surfactants are Tween 80, Span 80, Polyethylene glycol etc¹³.

Co-surfactants: Cosurfactants can work alongside surfactants to aid the emulsification process by breaking up the interfacial film, and they may also assist in oil solubilization¹⁴. Commonly used cosurfactants in the formulation of nanoemulsions and nanoemulgels include propylene glycol, PEG 400, ethanol, transcutol P, carbitol, among others, based on their physicochemical properties¹⁵. Research indicates that as the concentration of cosurfactant increases, the nanoemulsion region in the phase diagram shrinks¹⁶.

Aqueous solvents: Aqueous solvents act as the aqueous phase in emulsion preparation. Worldwide widely used aqueous solvents are ethanol and water.

Gelling agents: Carbapol 934, Carbapol 940, and hydroxypropyl methylcellulose (HPMC) are commonly used as gelling agents in nanoemulgel formulations. They enhance the formulation's thickness and may interact with surfactants to adjust its viscosity¹⁷. These agents are incorporated into nanoemulsions to transform their physical state from liquid to gel, addressing issues such as low spreadability, low viscosity, and poor skin retention associated with nanoemulsions.

Penetration enhancers: Using penetration enhancers is one of the most effective ways to increase transport efficiency through the skin and its underlying layers. As a key component of conventional drug delivery systems, penetration enhancers are frequently employed in topical nanoemulgels. They generally work by interacting with skin components, leading to a temporary and progressive increase in skin permeability.¹⁸

Preservatives: Preservatives are chemicals used to prevent microbiological degradation and prolong the shelf life of a product. Commonly used preservatives include methylparaben, propylparaben, benzalkonium chloride, and phenoxyethanol¹⁹.

METHOD OF PREPARATION:

Preparation of Nanoemulsion:

The medication, cosurfactant, and surfactant are dissolved based on their solubility in the chosen aqueous or oil phase. Both phases are heated separately, and once they cool to room temperature, they are combined by gradually adding one to the other while stirring continuously²⁰. Nanoemulsions can be formulated using both low and high-energy methods. Examples of low-energy techniques include self-emulsification, phase inversion (such as phase inversion temperature (PIT) and phase inversion composition (PIC), emulsification, and solvent diffusion. On the other hand, high-energytechniques include ultrasonication, microfluidization, and high-pressure homogenization. Low-energy methods are preferred overhigh-energy ones because they are more efficient and do not require complex equipment²¹. The high-energy method decreases the size of both phases by generating intense disruptive forces using mechanical equipment. However, this process may lead to overheating of the formulation's components, making the emulsion thermodynamically unstable and unsuitable for heat-sensitive medications²².

Preparation of Nanoemulgel:

The preparation of gelling media requires dissolving gelling agents in an aqueous solution until full swelling occurs. To achieve this, the chosen polymer is dispersed in pure water while being continuously stirred using mechanical methods under controlled conditions for a specific duration and at a constant rate. Once complete swelling is achieved, the gel base is adjusted to the desired pH for effective delivery to the topical system. An o/w nanoemulsion solution forms a gel when a gelling agent is added due to the agent's thixotropic properties, allowing the formulation to shift from gel to liquid under shear force without altering its volume. Any of the previously mentioned methods can be used to create the nanoemulsion, which can then be transformed into a nanoemulgel by incorporating a gel base. To integrate the nanoemulsion into the gel matrix, the gel and nanoemulsion are mixed at a fixed ratio and stirred continuously to ensure uniformity²³.

High-Pressure homogenization method:

High-pressure homogenizers provide significant energy and create a uniform flow to achieve the smallest particle sizes, making them the most commonly used method for preparing nanoemulsions. These homogenizers generate highly disruptive forces that produce nanoemulsions with extremely fine particle sizes, as small as 1 nm. The coarse emulsion is forced through a small orifice under high pressure (ranging from 500 to 5,000 psi), during which several forces—such as intense turbulence, hydraulic shear, and cavitation—work together to reduce droplet size. The particle size of nanoemulsions produced by high-pressure homogenizers depends on the sample composition, the type of homogenizer, and operating conditions like energy intensity, duration, and temperature. Increasing homogenization intensity reduces droplet size, but in some cases, such as when biopolymers are used as emulsifiers, excessive homogenization can actually increase particle size. For this reason, small-molecule surfactants are preferred as emulsifiers in high-pressure homogenizers, as they are more effective than biopolymers for producing nanoemulsions. High-pressure homogenization is widely used in the creation of nanoemulsions for food, pharmaceutical, and biotechnological applications²⁴.

Microfluidization method:

Microfluidization is a micro-scale mixing technology that utilizes a device called a microfluidizer. In this process, fluids are forced through microchannels under high pressure (ranging from 500 to 20,000 psi). These microchannels enable mixing at the microscopic level²⁵. The aqueous and oil phases of the macroemulsion are combined and then passed through the microfluidizer. As the macroemulsion moves through the microchannels under high pressure, it reaches the interaction chamber, where two streams of the macroemulsion collide at high speed. This collision generates forces such as shearing, cavitation, and impact, which help create stable nanoemulsions²⁶.

Ultrasonication method:

This process produces a nanoemulgel using ultrasonic waves. After combining the hydrophilic matrix with the oil phase, high-frequency ultrasonic waves are applied to the mixture. The ultrasonic energy breaks down the oil phase into nanosized droplets, which are then uniformly dispersed throughout the gel matrix.

Solvent evaporation method:

This method involves using a water-miscible solvent to dissolve both the oil phase and the hydrophilic matrix. The solvent is then evaporated under reduced pressure, resulting in a nanoemulgel with nanosized oil droplets dispersed within the gel matrix²⁷.

Self-emulsification method:

This method utilizes a self-emulsifying drug delivery system (SEDDS) to produce a Nanoemul gel in situ. SEDDS consists of a blend of oil, surfactants, and co-solvents that can spontaneously emulsify upon contact with water. When combined with a hydrophilic gel matrix, it results in the formation of a Nanoemul gel.

High energy emulsification method:

This method requires high-energy input to create small droplets of the dispersed phase (oil) within the continuous phase (water). Techniques like sonication, high-pressure homogenization, and microfluidization are commonly used to achieve this. A gelling agent, such as a polymer or surfactant, can then be introduced to the resulting emulsion, transforming it into a gel.

Phase inversion temperature (PIT) method:

This process utilizes a thermosensitive surfactant that transitions from a water-soluble state to an insoluble one at a specific temperature. By altering the system's temperature, the surfactant can trap the dispersed phase, forming a gel-like structure.

Coacervation method:

This method involves using two or more polymers that separate into different phases when exposed to an electrolyte or a shift in pH, resulting in a gel-like structure. The dispersed phase can then be incorporated into the gel through techniques such as high-energy emulsification²⁸.

Sol-gel method:

This method utilizes a sol-gel transition system, where a gel forms through the aggregation of particles or polymers in a solvent. This can be accomplished by introducing a crosslinking agent or a thermosensitive polymer to the emulsion, which induces gel formation under specific conditions or at a certain temperature⁶.

Electrostatic complexation method:

This approach uses oppositely charged polymers or surfactants to form a stable emulsion, which can later be converted into a gel by adding a crosslinking or gelling agent⁶.

Characterization of Nanoemulgel:

Droplet size:

Nanoemulgels, with average droplet sizes of less than 200 nm, provide considerable benefits for improving drug delivery. The formulation's ingredients, especially surfactants and co-surfactants at higher concentrations, are crucial in enhancing drug penetration. The nanoscale droplet size increases the available surface area for drug release, which in turn speeds up the drug release rate. In addition, droplet size is a key factor in determining the stability of nanoemulgel formulations. To support these conclusions, extensive studies on the interactions between active ingredients and the nanoemulgel matrix, along with thorough clinical trials, are necessary²⁹.

Zeta potential:

Nanoemulsions carry an electrical charge due to the presence of various surfactants in their formulation. A higher zeta potential increases the repulsive forces between droplets, thereby improving the stability of the formulation. For example, emulsion droplets are prevented from clustering when the zeta potential is high. The surface charge can be modified with a charge-altering agent, where the zeta potential becomes positive if a positively charged modifier is used, and negative if a negatively charged one is applied. Thus, anionic or cationic surfactants play a key role in maintaining emulsion stability³⁰.

Viscosity:

The emulgel formulation provides numerous benefits compared to conventional emulsions, mainly due to the incorporation of gelling agents that improve stability by raising the viscosity of the aqueous phase. Viscosity testing is essential for assessing the consistency and thickness of the final emulgel product. The concentration of the gelling agent is a key factor in determining the viscosity, with higher concentrations leading to a direct increase in the formulation's viscosity³¹. Nanoemulgel was specifically created to overcome the low viscosity of nanoemulsions, which restricts their effectiveness in topical uses³². Important factors like particle size, surface charge, and viscosity are vital for the efficient delivery of active ingredients through the skin³³.

Rheological Properties:

Rheological studies focus on analyzing the flow and deformation of materials when subjected to external stress or force. These analyses help determine how different excipients, like oils, surfactants, and gelling agents, influence the flow behavior of a formulation. Changes in viscosity and flow properties can impact factors such as stability, spreadability, drug release, and other in vivo outcomes. For example, the shear-thinning behavior of a formulation forms a thin layer on the skin, enhancing permeability, while a more viscous formulation limits permeation. Therefore, rheological properties are crucial in the development of NEGs and can be measured using various viscometers, like the Brookfield viscometer or rheometers³⁴.

pH:

The pH indicates the acidity or alkalinity of a formulation. For topical products, an excessively high or low pH can lead to negative effects on the skin, such as irritation or allergic reactions. pH also influences the drug's stability and its release from the formulation. Ideally, the pH of the formulation should align with the skin's natural pH, typically between 4 and 7. Digital pH meters are commonly used to measure pH levels³⁵.

Spreadability:

Spreadability measures how uniformly the NEG spreads across the skin, ensuring even distribution of the dosage form and avoiding uneven dosing that could affect efficacy. The viscosity of the nanoemulgel significantly influences its spreadability. Currently, there is no standardized procedure for evaluating spreadability, but the parallel plate method (also known as the slide and drag technique) is widely used due to its simplicity and adaptability. In this method, the sample is placed in the center of a marked glass slab, with another slab placed parallel above it. A specific weight is applied and left for a set period. Spreadability is then calculated using the following formula:

Spreadability (S) = M L/T

where M is the weight on the upper glass slab, L is the length of the slabs, and T is the time taken to separate them³⁶.

In-Vitro Release Test (IVRT):

The effectiveness and safety of the active pharmaceutical ingredient (API) are linked to its release from the dosage form. In vitro release testing (IVRT) is a method used to evaluate the quality of drug products. According to the FDA, IVRT studies for semi-solid dosage forms are performed using either a vertical diffusion cell or an immersion cell. The vertical diffusion cell consists of donor and receptor chambers separated by a receptor membrane. The dosage sample is placed in the donor chamber, while the receptor chamber holds a buffer or hydro-alcoholic solution, chosen based on the API's solubility, sink conditions, and stability. A receptor membrane, similar to skin, is selected for its appropriate pore size, high permeability, and inertness toward the API. If needed, the membrane is saturated with release media. For topical products, the temperature of the media is maintained around 32 °C ± 1 °C, and for mucosal membrane products, it is kept at 37 °C ± 1 °C. A Teflon-coated magnetic stirrer is used to stir the receptor media. The immersion cell model includes a reservoir-like cell body covered with a membrane, sealed with a leakproof cap that prevents dosage form leakage. The cap has an opening at the top and should be positioned so the membrane contacts the dosage form at the bottom and the release media at the top. This setup is used with a USP-2 apparatus, where the immersion cell is placed in a flat-bottomed dissolution vessel with a typical volume of 150–200 mL. A mini spin-paddle is employed to stir or agitate the media³⁷.

Bio-Adhesive Property:

Bio-adhesive strength measures the force needed to detach a drug delivery system from a biological surface, a key factor for topical dosage forms requiring extended contact. This test is commonly conducted using rat or pig skin, with pig skin being preferred due to its similarity to human skin. While various methods exist to assess bio-adhesive strength, none are FDA-approved. One method involves using a texture analyzer, where both the movable upper probe and the stationary lower base plate are covered with skin. The dosage form is placed on the skin-covered base plate, and the upper probe is lowered to contact the lower plate for at least a minute. The probe is then gradually raised until the skin sheets separate, and the instrument measures the force required for separation, represented as the area under the force-distance curve³⁸.

Factors Affecting Topical Absorption of Drugs:

Physiological factors:

• The lipid content of the skin acts as a barrier to drug absorption, and reducing this barrier enhances drug penetration.
• The thickness of various skin layers affects the penetration rate, with thicker layers resulting in slower penetration. For example, the palms and soles have higher diffusion rates compared to other areas.
• Skin pH.
• Hydration of skin.

Physicochemical factors:

• Partition coefficient- higher log p value gives rise to absorption.
• Effect of vehicles- hydro alcoholic gel provides the most efficient absorption through skin.
• Degree of ionization⁸.

CONCLUSION:

Topical nanoemulgels have emerged as a superior option for effective and convenient drug delivery. With their gel-like and non-greasy characteristics, these formulations enhance patient compliance. Unlike traditional formulations with oily bases, nanoemulgels offer improved drug release. By integrating nanoemulsions into a gel matrix, the system achieves controlled dual-release, solving issues like creaming and phase separation found in classical emulsions, while also improving spreadability. Nanoemulsion-loaded gels have demonstrated greater efficacy in treating certain topical conditions. In the future, nanoemulsion-gel formulations could provide a more reliable method for delivering hydrophobic drugs. Many drugs used in treating skin conditions are hydrophobic, and nanoemulgels can effectively deliver these by incorporating the drug into the oil phase of the nanoemulsion, which is then combined with the gel base. Despite a few limitations, nanoemulgels are likely to become a key method for topical delivery of lipophilic drugs.

REFERENCES

1. Donthi MR, Munnangi SR, Krishna KV, Marathe SA, Saha RN, Singhvi G, Dubey SK. Formulating ternary inclusion complex of sorafenib tosylate using ?-cyclodextrin and hydrophilic polymers: physicochemical characterization and in vitro assessment. AAPS PharmSciTech. 2022 Sep 15;23(7):254.
2. Solans C, Izquierdo P, Nolla J, Azemar N, Garcia-Celma MJ. Nano-emulsions. COCIS. 2005 Oct 1;10(3-4):102-10.
3. Gao F, Zhang Z, Bu H, Huang Y, Gao Z, Shen J, Zhao C, Li Y. Nanoemulsion improves the oral absorption of candesartan cilexetil in rats: performance and mechanism. JCR. 2011 Jan 20;149(2):168-74.
4. Donthi MR, Munnangi SR, Krishna KV, Saha RN, Singhvi G, Dubey SK. Nanoemulgel: a novel nano carrier as a tool for topical drug delivery. Pharm. 2023 Jan 3;15(1):164.
5. Malay NJ, Chandresh PP, Bhupendra GP. Nanoemulgel innovative approach for topical gel based formulation. RRHOAJ. 2018 Feb 15.
6. Lodha D, Kardile A, Raut V, Mahadik M, Lad S,  Review On Nanoemulgel. IJCRT. 2017 May;11(5):1-10.
7. Reethu Shree S, Nesalin JA, Gopinath E, Ganesh NS, Chandy V. NANOEMULGEL: AN EMERGING PLATFORM FOR TRANSDERMAL DRUG DELIVERY.
8. Valarmathy S, Devi Damayanthi R, Chella Kumari SD, Surya S, Vidhya PS, Durga GKV. Nanoemulgel :A Comprehensive Review for Topical Drug Delivery. IJPPR.2024 Feb;30(2):271-86.
9. Mangale MR, Pathak SS, Mene HR, More BA. Nanoemulsion: As Pharmaceutical Overview. Int J Pharm Sci Rev Res.2015 July-Aug;33(1):244-252.
10. Kaur G, Bedi PMS, Narang JK (2017) Topical Nanoemulgel: A Novel Pathway for Investigating Alopecia. J Nanomed Nanotechnol 8: 472. doi: 10.4172/2157-7439.1000472.
11. Muzaffar FA, Singh UK, Chauhan L. Review on microemulsion as futuristic drug delivery. Int J Pharm Pharm Sci. 2013;5(3):39-53.
12. Gupta A, Eral HB, Hatton TA, Doyle PS. Nanoemulsions: formation, properties and applications. Soft matter. 2016;12(11):2826-41.
13. Azeez AR, Alkotaji M. Nanoemulgel as a recent drug delivery system. Military Medical Science Letters/Vojenské zdravotnické Listy. 2022 Apr 1;91(2).
14. Rizwan M, Azeem A, Aqil M, Talegaonkar S, Khar RK, Ahmad FJ, et al. Nanoemulsion components screening and selection: A technical note. AAPS PharmSciTech. 2009;10:69-76. DOI: 10.1208/s12249-008-9178-x.
15. Jeengar MK, Rompicharla SV, Shrivastava S, Chella N, Shastri NR, Naidu VG, Sistla R. Emu oil based nano-emulgel for topical delivery of curcumin. Int. J. Pharm. 2016 Jun 15;506(1-2):222-36.
16. Shafiq S, Shakeel F, Talegaonkar S, Ahmad FJ, Khar RK, Ali M. Development and bioavailability assessment of ramipril nanoemulsion formulation. Eur. j. pharm. Biopharm. 2007 May 1;66(2):227-43.
17. Dhawan B, Aggarwal G, Harikumar SL. Enhanced transdermal permeability of piroxicam through novel nanoemulgel formulation. Int. J. Pharm. Investig. 2014 Apr;4(2):65.
18. Mohamed MI. Optimization of chlorphenesin emulgel formulation. The AAPS journal. 2004 Sep;6:81-7.
19. Kumar L, Verma R. In vitro evaluation of topical gel prepared using natural polymer. Int. J. Drug Deliv. 2010 Jan 1;2(1):58-63.
20. Kumar M, Bishnoi RS, Shukla AK, Jain CP. Techniques for formulation of nanoemulsion drug delivery system: a review. Prev. Nutr. Food Sci.; PNF. 2019 Sep;24(3):225.
21. Gonçalves A, Nikmaram N, Roohinejad S, Estevinho BN, Rocha F, Greiner R, McClements DJ. Production, properties, and applications of solid self-emulsifying delivery systems (S-SEDS) in the food and pharmaceutical industries. Colloids and Surfaces A: Physicochemical and Engineering Aspects. 2018 Feb 5;538:108-26.
22. Aswathanarayan JB, Vittal RR. Nanoemulsions and their potential applications in food industry. Front. sustain. food syst. 2019 Nov 13;3:95.
23. Rai VK, Sharma A, Thakur A. Quality control of nanoemulsion: by PDCA cycle and 7QC tools. Curr. Drug Deliv. 2021 Nov 1;18(9):1244-55.
24. Kumar M, Bishnoi RS, Shukla AK, Jain CP. Techniques for formulation of nanoemulsion drug delivery system: a review. Prev. Nutr. Food Sci.; PNF. 2019 Sep;24(3):225.
25. Qadir A, Faiyazuddin MD, Hussain MT, Alshammari TM, Shakeel F. Critical steps and energetics involved in a successful development of a stable nanoemulsion. J. Mol. Liq. 2016 Feb 1;214:7-18.
26. Jafari SM, He Y, Bhandari B. Production of sub-micron emulsions by ultrasound and microfluidization techniques. J. Food Eng. 2007 Oct 1;82(4):478-88.
27. Bhatt P, Madhav S. A detailed review on nanoemulsion drug delivery system. Int. J. Pharm. Sci. Res. 2011 Oct 1;2(10):2482.
28. Morsy MA, Abdel-Latif RG, Nair AB, Venugopala KN, Ahmed AF, Elsewedy HS, Shehata TM. Preparation and evaluation of atorvastatin-loaded nanoemulgel on wound-healing efficacy. Pharm. 2019 Nov 13;11(11):609.
29. Ulayya HF, Wikantyasning ER. Literature Review: Formulation and Characterization of Nanoemulgel for Anticellulite Treatment. Pharmacon: Jurnal Farmasi Indonesia. 2024 Dec 31:176-87.
30. Chen X, Jaiswal A, Costliow Z, Herbst P, Creasey EA, Oshiro-Rapley N, Daly MJ, Carey KL, Graham DB, Xavier RJ. pH sensing controls tissue inflammation by modulating cellular metabolism and endo-lysosomal function of immune cells. Nat. Immunol. 2022 Jul;23(7):1063-75.
31. Ulfa R, Firmansyah F, Khairunnisa F, Lestari P. A Literature Review on the Formulation, Characterization, and Stability of Cinnamomum burmannii Emulgel Extract as an Antioxidant and Sunscreen. Jurnal Ilmu Farmasi dan Farmasi Klinik. 2024 Jun 28;21(1):48-55.
32. Sengupta P, Chatterjee B. Potential and future scope of nanoemulgel formulation for topical delivery of lipophilic drugs. Int. J. Pharm. 2017 Jun 30;526(1-2):353-65.
33. Taha M, Alhakamy NA, Md S, Ahmad MZ, Rizwanullah M, Fatima S, Ahmed N, Alyazedi FM, Karim S, Ahmad J. Nanogels as potential delivery vehicles in improving the therapeutic efficacy of phytopharmaceuticals. Polym. 2022 Oct 3;14(19):4141.
34. Anand K, Ray S, Rahman M, Shaharyar A, Bhowmik R, Bera R, Karmakar S. Nano-emulgel: emerging as a smarter topical lipidic emulsion-based nanocarrier for skin healthcare applications. Recent patents on anti-infective drug discovery. 2019 May 1;14(1):16-35.
35. Jose M, Bronckaers A, Kumar RS, Reenaers D, Vandenryt T, Thoelen R, Deferme W. Stretchable printed device for the simultaneous sensing of temperature and strain validated in a mouse wound healing model. Sci. Rep. 2022 Jun 16;12(1):10138.
36. Djiobie Tchienou Ge, Tsatsop Tsague Rk, Mbam Pega Tf, Bama V, Bamseck A, Dongmo Sokeng S, Ngassoum Mb. Multi-response optimization in the formulation of a topical cream from natural ingredients. Cosmetics. 2018 Jan 5;5(1):7.
37. Kanfer I, Rath S, Purazi P, Mudyahoto NA. In vitro release testing of semi-solid dosage forms. Dissolut. Technol. 2017 Aug 1;24(3):52-60.
38. Amorós-Galicia L, Nardi-Ricart A, Verdugo-González C, Arroyo-García CM, García-Montoya E, Pérez-Lozano P, Suñé-Negre JM, Suñé-Pou M. Development of a standardized method for measuring bioadhesion and mucoadhesion that is applicable to various pharmaceutical dosage forms. Pharm. 2022 Sep 21;14(10):1995.
